Curve
RADIANT FLAME EFFECT GAS FIRE
User Instructions
Model No's FCRR**RN is for use on Natural Gas (G20) at a supply
pressure of 20 mbar in G.B. / I.E.
NB: "**" refers to fascia variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Curve FCRR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Flavel Curve FCRR Series

  • Page 1 Curve RADIANT FLAME EFFECT GAS FIRE User Instructions Model No’s FCRR**RN is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E. NB: “**” refers to fascia variant...
  • Page 2: Installation Information

    INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed in accordance with the rules in force only by a competent (e.g. CORGI Registered) Installer in G.B, and in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998.
  • Page 3: Important Safety Information

    ABOUT YOUR NEW FLAVEL “CURVE” GAS FIRE The Flavel “Curve” radiant gas fire incorporates a unique and highly developed grooved radiant panel. The use of durable ceramic material in the construction of the radiant panel ensures long and trouble free operation.
  • Page 4: Spillage Monitoring System

    SPILLAGE MONITORING SYSTEM This appliance is fitted with a spillage monitoring system which shuts down the fire if the evacuation of combustion products from the fire is affected by a partially or fully blocked flue pipe. If this system operates the fire will go out. If this occurs, leave the fire for at least three minutes then follow the lighting procedure as described in the previous section.
  • Page 5 OPERATING THE FIRE USING THE REMOTE CONTROL HANDSET The control valve is positioned on the left hand side of the fire when viewed from the front. Remove the controls cover as shown on previous page To operate the appliance automatically via the remote control handset, ensure that the on / off switch is switched to the “on”...
  • Page 6 Fig. 4 “LED” handset light “UP” button “DOWN” / “STANDBY” “STAR” / “OFF” button button The fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily.
  • Page 7 REMOVAL & RE-FITTING THE “CURVE” FASCIA The “Curve” fascia is fitted to the product by hooking the top edge of the fascia over the mounting brackets as shown in Fig. 5 below, then securing with two screws on the bottom face of the trim as shown in Fig.
  • Page 8 CLEANING - WARNING Before attempting any cleaning operation ensure that the fire has been allowed to fully cool. CLEANING THE STAINLESS STEEL AND PAINTED METAL PARTS The “Curve” fascia that was supplied with this product must only be cleaned with a clean, damp cloth.
  • Page 9: User-Replaceable Parts

    USER REPLACEABLE PARTS We do not recommend any parts on this appliance are replaced by anyone other than a CORGI registered engineer. Due to our policy of continual improvement and development the exact accuracy of descriptions and illustrations cannot be guaranteed. Part No.
