Specifications - Panasonic Mini USB Connectors AXJ4 Specifications

SPECIFICATIONS

1. Characteristics
Item
Rated current
Rated voltage
Contact resistance
Electrical
Insulation resistance
characteristics
Breakdown voltage
Electrostatic capacity
Composite insertion
force (initial)
Mechanical
characteristics
Composite removal
force (initial)
Ambient temperature
Storage temperature
Vibration resistance
Impact resistance
Heat resistance
(mated)
Environmental
Low temperature
characteristics
resistance (mated)
Humidity resistance
(mated)
Temperature cycle test
(mated)
Saltwater spray
resistance (mated)
Hydrogen sulfide
Reflow soldering
Soldering
temperature
Manual soldering
resistance
2. Material and surface treatment
Part name
Resin-molding portion
Contact
Metal parts
Shell
Pickup tape
Matsushita Electric Works, Ltd.
Specifications
1.0A
30V DC/AC
Max. 50mΩ
Min. 100MΩ
100V AC (Dielectric breakdown must not occur during a 1 min.
application)
Max. 2pF
Max. 35N
{3.57kgf}
Min. 7N {0.714kgf}
–55°C to 85°C
–55°C to 85°C (–40°C to 50°C for packaging materials)
Discontinuity: Max. 1µs
Contact resistance: Max. 50mΩ
Appearance: No abnormality
Discontinuity: Max. 1µs
Contact resistance: Max. 50mΩ
Appearance: No abnormality
250 hours
Contact resistance: Max. 50mΩ
Withstand voltage: 100V AC dielectric breakdown must not
occur during a one-minute application.
Insulation resistance: Min. 100MΩ
Appearance: No abnormality
96 hours
Contact resistance: Max. 50mΩ
Withstand voltage: 100V AC dielectric breakdown must not
occur during a one-minute application.
Insulation resistance: Min. 100MΩ
Appearance: No abnormality
7 cycles
Contact resistance: Max. 50mΩ
Withstand voltage: 100V AC dielectric breakdown must not
occur during a one-minute application.
Insulation resistance: Min. 100MΩ
Appearance: No abnormality
10 cycles
Contact resistance: Max. 50mΩ
Withstand voltage: 100V AC dielectric breakdown must not
occur during a one-minute application.
Insulation resistance: Min. 100MΩ
Appearance: No abnormality
48 hours
Contact resistance: Max. 100mΩ
Appearance: No abnormality
96 hours
Contact resistance: Max. 100mΩ
Appearance: No abnormality
Peak temperature: Max. 260°C
300±10°C: Max. 5 s
350±10°C: Max. 3 s
Material
Heat-resistant resin (UL94V-0)
Copper alloy
Copper alloy
Heat-resistant resin
EIA-364-23
(Inductive resistance to wire is not included)
EIA-364-21
Using 100V DC megger
EIA-364-20
Detection current: 1mA
EIA-364-30
(Measure it between the adjacent terminals of the unmated
connector at a frequency of 1 kHz.)
EIA-364-13
Insert and remove a plug at a speed of 12.5 mm/min.
No freezing or condensation in low temperatures
No freezing or condensation in low temperatures
EIA-364-28
Apply vibration in three directions including the mating axis
that are perpendicular to one another for 15 minutes
respectively with a 100 mA DC current applied.
Cord length: 100mm Fix the cord end.
EIA-364-27
Acceleration: 294m/s
Duration: 11 ms,
Application directions: 6 surfaces (X, Y, and Z directions)
Number of applications: 3 times respectively (Total: 18 times)
Cord length: 100mm Fix the cord end.
EIA-364-17
Temperature: 85±2°C
Temperature: –55±2°C
EIA-364-31 Method III
Sequence
1. –55±3°C, 30 minutes
2. ~, Max. 5 minutes
3. 85±2°C, 30 minutes
4. ~, Max. 5 minutes
Bath temperature: 35±2°C
Saltwater concentration: 5±1%
Wash the connector with water at room temperature after the
test, and then dry it at room temperature.
Temperature :40±2°C
Humidity: 75 to 80%
Gas concentration: 3±1ppm
Surface treatment
Contact portion: Ni plating on base, Au plating on surface
Terminal portion: Ni plating on base, Sn plating on surface
Ni plating on base, Sn plating on surface
AXJ4
Conditions
2 (30G)
—
—
http://www.mew.co.jp/ac/e/
