Valor quantum BR644 VA Owner's Manual

Inset live fuel effect gas fire
Hide thumbs

Advertisement

Quick Links

3003172/02
OWNER GUIDE
Valor Sirius
MODEL BR643 VA
Valor Quantum
MODEL BR644 VA
(GC No. 32-032-34)
INSET LIVE FUEL
EFFECT GAS FIRE
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
WHEN CONVERTED USING CONVERSION KIT NO. 0591149 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31).
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE
REPUBLIC OF IRELAND (IE) ONLY.
We trust that these instructions give sufficient details to enable this appliance to be
installed and maintained satisfactorily. However, if further information is required, our
Valor Technical Helpline will be pleased to help.
Telephone 08706 061 065 (National call rates apply in the United Kingdom)
owner
INSTALLER: Please leave this guide with the
© Valor Heating

Advertisement

loading
Need help?

Need help?

Do you have a question about the quantum BR644 VA and is the answer not in the manual?

Questions and answers

Related Manuals for Valor quantum BR644 VA

Summary of Contents for Valor quantum BR644 VA

  • Page 1 We trust that these instructions give sufficient details to enable this appliance to be installed and maintained satisfactorily. However, if further information is required, our Valor Technical Helpline will be pleased to help. Telephone 08706 061 065 (National call rates apply in the United Kingdom)

  • Page 2: Table Of Contents

    CUSTOMER CARE Thank you for choosing Valor. All Valor gas fires are designed to meet the most stringent quality, performance and safety requirements to provide our customers with many years’ trouble-free service. Your owner guide aims to improve your understanding and appreciation of your Valor gas appliance by providing simple and informative instructions to ensure that you benefit from the excellent performance and features it has to offer.

  • Page 3: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE DIRECTORY Have the fire installed by a competent person.

  • Page 4: Operating Your Fire

    OWNER GUIDE OPERATING YOUR FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use.
  • Page 5 OWNER GUIDE Lighting the Main Burner Once the pilot light is established, the main burner can be lit by depressing and turning the control knob anticlockwise to the “High” position. Selecting the Heat Setting In order to change from one setting to another depress the control knob slightly and turn the knob to the required position.

  • Page 6: Cleaning

    OWNER GUIDE CLEANING To maintain the high performance and quality finish of your Valor appliance, please follow these guidelines: Before attempting to clean the fire, please remember to turn off the fire and wait for the appliance to cool. The fire will retain heat for some time before cleaning can begin.

  • Page 7: Refitting Ceramics

    OWNER GUIDE REFITTING CERAMICS Both models 1. Fit the burner tray trim over the front rim of the burner tray. Push the trim fully down. See figure 2. Figure 2. Burner Tray Trim Fitting Coals to models supplied with a Coal Ceramic Fuel Effect. (For models supplied with a Pebble Ceramic fuel effect see section headed ‘Fitting Pebbles to models supplied with Pebble Ceramic Fuel Effect’).
  • Page 8 OWNER GUIDE 2. Place the front base coal in the firebox with its bottom front locating over the front rim of the firebox. Pull the coal forward so that it locates immediately behind the front rim of the firebox. See figure 4. There are two types of loose coals.
  • Page 9 OWNER GUIDE 6. Place the remaining type “B” coal at the right side of the firebox between the front and rear base coals. The letter “B” should be upright. The coal should touch the right side of the firebox. See figure 8. 7.
  • Page 10 OWNER GUIDE Install the 11 loose pebbles as follows. The underside of each pebble is marked with a letter ‘A’ to ‘K’ and an arrow. The pebbles should be positioned so that the arrows always point towards the back of the fireplace opening.
  • Page 11 OWNER GUIDE 6. Hold pebble ‘D’ upright with the arrow pointing to the top. Place pebble “D” on top of the base front pebble. It should rest against the moulded pebble to its right. (See figure 15). 7. Hold pebble ‘E’ upright with the Figure 15.
  • Page 12 OWNER GUIDE 10. Hold pebble ‘H’ upright with the arrow pointing to the top. Place pebble ‘H’ between the front and rear base pebbles. It should rest in between pebbles ‘C’ & ‘D’ and against the moulded pebble in the rear pebble base.

  • Page 13: Maintenance

     In the United Kingdom servicing can be carried out either by a Valor service engineer or a CORGI registered installer.  If you require your fire to be serviced, please contact Valor Service on 08706 090 081 and quote the following details;...
  • Page 14  When fitting replacement parts, follow the instructions contained in this guide. It is important that only Valor approved parts are used for maximum safety.  In the United Kingdom, for general advice about gas and your gas fire call our Technical Helpline 08706 061 065.
