5108604/04
OWNER GUIDE
Classic 2
Model 719
(GC No. 32-032-53)
INSET LIVE FUEL EFFECT GAS FIRE
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 0595221 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
Manufactured exclusively for British Gas & Scottish Gas by Valor Heating
For Service Phone 0845 950 0400
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference
This guide to be left with the owner
© Baxi Heating U.K. Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic 2 719 and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi Classic 2 719

Summary of Contents for Baxi Classic 2 719

  • Page 1 For Service Phone 0845 950 0400 This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference This guide to be left with the owner © Baxi Heating U.K. Ltd.
  • Page 2 OWNER GUIDE Safety First. This gas fire is CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence at the heart of every fire. This fire has been manufactured to the highest standards of quality and excellence and are manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.

  • Page 3: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Section Page SAFETY APPLIANCE DIMENSIONS GAS CONSUMPTION OPERATING YOUR FIRE The Oxysafe flame sensing and flue blockage safety system. To light the fire. To turn the fire off. Lighting with a taper. CLEANING YOUR FIRE Metal Parts Ceramic fuel effect and rear wall.

  • Page 4: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.

  • Page 5: Appliance Dimensions

    OWNER GUIDE automatically shut off the gas supply to the fire, if for any reason , the flame goes out) Do get advice about the suitability of any wall covering near your fire. Soft wall coverings (e.g. embossed vinyl, etc.) which have a raised pattern are easily affected by heat.

  • Page 6: Gas Consumption

    OWNER GUIDE GAS CONSUMPTION Model 719 Has a maximum natural gas input of 6.0kW (Gross) Has a maximum natural gas output of 3.5kW Has a minimum natural gas input of 2.7kW (Gross) Has a minimum natural gas output of 1.3kW Model 719 when converted using kit number 0595221 Has a maximum propane gas input of 6.1kW (Gross) Has a maximum propane gas output of 3.6kW...

  • Page 7: To Light The Fire

    OWNER GUIDE To light the fire. The slide control is shown in figure 2. 1. Slide the control button to the bottom (ignition) position marked . In this position, the electronic ignition system should cause a series of sparks which should light the pilot. Within four seconds of the pilot igniting, the main burner should light at its minimum setting.

  • Page 8: To Turn The Fire Off

    OWNER GUIDE To turn the fire off. Slide the button up past the high heat position to the "O" position. Both the main burner and the pilot should go out. While cooling, the coals may make some crackling noises. This is quite normal. Lighting with a taper.

  • Page 9: Burner

    OWNER GUIDE bed refitting instructions. Burner. The burner surface can be carefully cleaned to remove any loose particles after taking off the coals. Make sure that no particles are pushed into the burner holes. FUEL BED REFITTING The position of the fuel bed ceramic pieces is important. Do not alter the position of the fuel bed ceramic pieces from that shown in this section of the owner guide.
  • Page 10 OWNER GUIDE 3. Place a type “A” coal between the front and rear base coals with the letter “A” upright and so that the coal is against the left side of the firebox. See figure 6. 4. Place a type “B” coal between the front and rear base coals as shown in Figure 6.

  • Page 11: Maintenance

    OWNER GUIDE MAINTENANCE Battery replacement. The igniter unit uses a 9V PP3 battery. To replace the battery remove the firefront casting / front cover casting. 1. Remove and discard the battery from the ignition block located below the burner tray at the left side. 2.

  • Page 12: Owner Replaceable Parts

    OWNER GUIDE Owner replaceable parts Description Part No Ceramic rear wall 0579399 Front coal 5108541 Rear base coal 5108542 Pack of loose coals 0582839 When fitting replacement parts, follow the instructions contained in this guide. It is important that only approved parts are used for maximum safety. Page 12...
