5110831/05
INSTALLER AND OWNER GUIDE
Model 808
Electric Heater
Fitted with one of the following fascia
Aura,
Aura 2,
Blenheim,
Camden,
Debut,
Flare,
Homeflame Traditional,
Sonnet.
or
This guide is intended to help you install and care for your Baxi Fires Division electric
heater. Please read carefully before installing and using your heater. However, if further
information is required, our Baxi Fires Division Technical Helpline will be pleased to
help.
Telephone 08706 061 065 (National call rates apply in the United Kingdom)
In the Republic of Ireland call 0044 8706 061 065
Important: Please keep your guide in a safe place for future reference
© Baxi Heating U.K. Ltd.
