Rear
Antenna (packaged
separately)
Antenna Mount
Stand Mount
Ethernet Port
Power Port
IMPORTANT
ADT Pulse
Interactive Solutions
®
RC8021W-ADT Wireless Indoor Camera Installation Guide
Figure 2: Rear Panel
Screw the antenna clockwise into the Antenna
Mount until tightened.
Connects the antenna to the RC-8021W Wireless
Indoor Camera.
Use the stand mount to connect the adjustable stand
to the device.
Use the Ethernet port to connect a LAN cable to the
ADT Pulse Gateway.
The 5V power adapter input connects to the wireless
camera power cord.
ADT Pulse does not support audio.
3
