RC8021W-ADT Wireless Indoor Camera Installation Guide
Physical Details – RC8021W-ADT

Front

Lens
Power LED
Network LED
Reset Button
IMPORTANT
2
Figure 1: Front Panel
Fixed focus
On (green) – Power on
Off – Power off
Blinking (green) – The Power LED blinks during power up.
(This can take up to 20 seconds.)
On (green) – LAN connection is detected
Off – LAN connection is not detected
Blinking (green) – Data is being transmitted or received
On (amber) – The WPS is not processing data
With the wireless camera powered on, insert a pin or
paperclip into the small opening and hold in place for at
least ten seconds to reset the communication
configuration settings.
The Reset button changes the wireless camera
communication configuration settings and should only
be used under the direction of ADT Support.
ADT Pulse Interactive Solutions
®
