Upright Freezer

SINGLE DOOR SERIES

USER MANUAL

MDRU385MTE46

Warning notices: Before using this product, please read this manual carefully and keep it for future reference.

The design and speciﬁcations are subject to change without prior notice for product improvement.

Consult with your dealer or manufacturer for details.

The diagram above is just for reference. Please take the appearance of the actual product as the standard.

Need help?

Do you have a question about the SINGLE DOOR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea SINGLE DOOR Series

Page 1 Upright Freezer SINGLE DOOR SERIES USER MANUAL MDRU385MTE46 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and speciﬁcations are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details.
Page 3 THANK YOU LETTER Thank you for choosing Midea! Before using your new Midea product, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance ers in a safe way.
Page 4 SPECIFICATIONS Product model MDRU385MTE46 Fresh Food Storage Compartment Volume Frozen Food Storage Volume 272L Defrosting Type Auto-defrost Temperature Rise Time Freezing Capacity 12.4kg/24h Rated Voltage 220-240V~ Rated Current 0.5A Overall Dimension (H x W x D) 1850x595x618mm...
Page 5 PRODUCT OVERVIEW Names of components shelf Two-star compartment Drawer Door tray ATTENTION The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor.
Page 6 PRODUCT INSTALLATION Install Instruction For refrigerating appliances with climate class • Depending on the climate class, This refrigerating appliance is intended to be used at ambient temperatures range as specified following table. • The climate class can be found on the rating plate. The product may not operate properly at temperatures outside of the specific range.
Page 7 Space requirement diagram (when the door is open and when the door is closed) 135 ° Width Depth Overall Width Depth doors open doors open Height 1850 1017 1025 Notice: All dimensions in mm...
Page 8 Door handle installation List of tools fo be provided by the user Cross screwdriver step 1. Remove the screw hole caps from the door, and use cross screwdriver to fix screw into the screw hole tightly. 2. Assemble the screw hole caps on the screw hole of handle. 3.
Page 9 Door right-left change（optional） Based on the location where you plan to use your refrigerator, you may find it more convenient to reverse the position of the door. CAUTION CAUTION: To avoid injury to yourself or your property, we recommend that someone assist you during the door reversal process.
Page 10 step 1. Power off the refrigerator, and remove all objects from door trays. 2. Dismantle the screw hole caps ,screws and handle, and remove the plastic screw hole caps from the other side. 3. Dismantle the upper hinge cover, screws and upper hinge, and remove the hole cover from the other side.
Page 11 door signal line door upper cover sleeve pipe sleeve pipe stopper stopper screw 6. Take out the left top hinge , left top hinge cover from accessories package,place the door on bottom hinge ,and mount left top hinge.Connect signal line terminal with signal line terminal , mount top hinge cover and hole cover.
Page 12 Placement • Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the refrigerator; tear off the protective film on the doors and the refrigerator body. • Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent rust or reduction of insulating effect.
Page 13 Connecting the appliance • After transportation, please let the product stay for more than 2 hours before turning on the power, otherwise it will lead to a decrease in cooling capacity or a damage to the product. • Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4 hours in summer when the ambient temperature is high.
Page 14 OPERATION INSTRUCTIONS Control panel ATTENTION The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor. Temperature icons Temperature seting button and the setting temperature is 8 or -16℃ Fridge/Freezer switch button Standby button the setting temperature is 6 or -18℃...
Page 15 When the fridge power is on • All temperature icons shine within 3s after power on, for power on at the first time, the default set temperature is -20℃. • After that every time you start the fridge, it will run in accordance with set t temperature before last power off.
Page 16 Fridge/Freezer conversion • Press the botton for 3 seconds to achieve Fridge/Freezer conversion, the corresponding temperature icons shine. Standby function • Long press the standby buton for 10 seconds to set the standby function. Temperature setting • The temperature setting will be changed once you press button .
Page 17 Target Compartments Order storage Appropriate food TYPE temp. [°C] Eggs, cooked food, packaged food, fruits and Fridge +2 ∼ +8 vegetables, dairy products, cakes, drinks and other foods are not suitable for freezing. Seafood(fish, shrimp, shellfish), freshwater aquatic products and meat products (***)*-Freezer ≤...
Page 18 CLEANING AND MAINTENANCE Overall cleaning • Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. • Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent.
Page 19 Cleaning of glass shelf • As the innermost part of the refrigerator liner where contacting the shelves has a backstop, you shall raise the shelves upward, then you can be able to take it out. • Adjust or clean the shelves according to your requirement.
Page 20 TROUBLESHOOTING The following simple issues can be handled by the user. Please call the after-sale service department if the issues are not solved. Problem Possible reason • Check whether the appliance is connected to power or whether the plug is in well contact Failed operation •...
Page 21 Problem Possible reason • Remove foreign matters on the door seal Door seal fails to be tight • Heat the door seal and then cool it for restoration (or blow it with an electrical drier or use a hot towel for heating) •...
Page 22 APPENDIX Special for new European standard The ordered parts in the following table can be acquired from Service provider channel Ordered part Provided by Minimum time required for Provision Professional At least 7 years after the last model is Thermostats maintenance personnel launched on the market Temperature...
