BUTTERNUT Manufacturing Co.
Model 10/11
WARNING: INSTALLATION OF THIS PRODUCT NEAR POWER LINES IS DAN-
GEROUS. FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS.
WARNING: AT NO TIME DURING ASSEMBLY, INSTALLATION, ADJUSTMENT
OR OPERATION SHOULD ANY PART OF THIS PRODUCT BE ALLOWED TO
COME INTO CONTACT WITH ELECTRIC POWER LINES, NOR SHOULD THIS
PRODUCT BE INSTALLED IN SUCH A WAY THAT ANY PART OF IT MAY CON-
TACT POWER LINES DURING NORMAL OPERATION OR IN THE EVENT OF
STRUCTURAL FAILURE. FAILURE TO EXERCISE EXTREME CARE IN THIS
MATTER CAN RESULT IN DAMAGE TO PROPERTY, PERSONAL INJURY OR
EVEN DEATH!
As with all directional antennas, care must be taken in the choice of an installation site for your
Butterfly™ beam. Pick a place clear of POWER LINES or other obstructions. It should be
mounted at least 20 to 25 feet above the ground for proper operation. It should also be able to
rotate without hitting anything and should not be near any large masses of metal such as metal
roofs or siding. If you have metal siding or a metal roof, plan to mount your beam 20 feet or
more above it.
Before you start assembling the antenna, read through the instructions so that you will have a
general idea of what you will have to do and what the finished antenna will look like. When you
unpack the box, do so on a surface where you will not lose the small parts. Check the parts
against the parts list so that you will know what each part looks when the instructions call for you
to use it.
831 North Central Avenue Wood Dale Illinois 60191-1219 Telephone 630•238•1854 Facsimile 630•238•1186

CHOOSING AN INSTALLATION SITE

BEFORE YOU START

1
Instructions
V00246-101599
