Atomic Projection Alarm
Model: K86326
INTRODUCTION:
The Atomic Projection Alarm features radio-controlled time, indoor and outdoor temperature on a stylish,
colorful, and easy to read display. Time and/or outdoor temperature can be projected on a wall or ceiling.
ATOMIC PROJECTION ALARM
OUTDOOR TEMPERATURE/HUMIDITY TRANSMITTER: TX14
1
Advertisement
Table of Contents
Related Manuals for La Crosse Technology K86326
Summary of Contents for La Crosse Technology K86326
-
Page 1: Introduction
Atomic Projection Alarm Model: K86326 INTRODUCTION: The Atomic Projection Alarm features radio-controlled time, indoor and outdoor temperature on a stylish, colorful, and easy to read display. Time and/or outdoor temperature can be projected on a wall or ceiling. ATOMIC PROJECTION ALARM... -
Page 2: Table Of Contents
TABLE OF CONTENTS: INTRODUCTION ATOMIC PROJECTION ALARM OUTDOOR TEMPERATURE TRANSMITTER TX14 FEATURES INITIAL SETUP POWER THE PROJECTION ALARM A/C ADAPTER BATTERIES INSTALL BATTERIES IN THE OUTDOOR TRANSMITTER WWVB RADIO CONTROLLED TIME WWVB RECEPTION ICON MANUAL SIGNAL SEARCH FUNCTION BUTTONS PROGRAM MENU WWVB RECEPTION ON/OFF TIME ZONE DAYLIGHT SAVING TIME INDICATOR... -
Page 3: Features
FEATURES: Projects time and outdoor temperature Toggles time and outdoor temperature Display time only Display outdoor temperature only （Default----Toggles time and outdoor temperature） Projection rotate with 90 degree increments Atomic Clock: 7 Time-zones:（AST, EST, CST, MST, PST, AKT, HAT） Calendar (Month/date,2000-2099 Default Year 2010) Time (hour/minute) Indoor Temperature Wireless Outdoor Temperature... -
Page 4: Power The Projection Alarm
POWER THE ATOMIC PROJECTION ALARM: The Projection Alarm can be powered by the 5-volt a/c adapter or by 2 AA batteries. A/C power adapter: Insert enclosed 5-volt a/c power adapter into a wall outlet, then into the Atomic Projection Alarm. Battery Compartment 5-Volt a/c adapter... -
Page 5: Wwvb Radio Controlled Time
WWVB RADIO CONTROLLED TIME The NIST radio station, WWVB, is located in Ft. Collins, Colorado and transmits the exact time signal continuously throughout the United States at 60 kHz. The signal can be received up to 2,000 miles away through the internal antenna in the Atomic Projection Alarm. However, due to the nature of the Earth’s Ionosphere, reception is very limited during daylight hours. -
Page 6: Program Menu
Button Press and Release Functions Hold 2 seconds Move through program menu (setup) Enter program menu, set time, SET/°C/°F Select temperature in °C/°F date, etc. (setup) Once: View Alarm ALARM Alarm set Twice: Activate or Deactivate Alarm Search for Sensor +/TEMP 1 step forward (setup) Fast advance (setup) -
Page 7: Daylight Saving Time Indicator
DAYLIGHT SAVING INDICATOR: DST will default to the ON position as most of the country observes the DST change. If you live in an area does not observe the DST change, switch this to the OFF position. 1. DST and ON will flash. 2. -
Page 8: Alarm Set
ALARM SET: Hold the ALARM button for 5 seconds to enter the alarm time set mode. 1. The alarm hour digit will flash. 2. Press and release the +/TEMP or -/TIME buttons to select the hour. 3. Press and release the SET button to set the minutes. The minute digits will flash. 4. -
Page 9: Temperature Trend Icons
TEMPERATURE TREND ICONS: The indoor and outdoor temperature trend indicators are updated every 30 minutes. These trends represent temperature changes over the past three hours. Temperature rising more than 2°F /1°C in the past three hours Temperature has not changed more than 2°F /1°C in the past three hours Temperature falling more than 2°F /1°C in the past three hours The temperature trend indicators are shown next to the indoor temperature and outdoor temperature readings. -
Page 10: Position Outdoor Transmitter
POSITION THE OUTDOOR TRANSMITTER: The remote temperature transmitter should be mounted vertically to avoid damage. WALL MOUNT 1. Choose a location for the transmitter that is within range of the Atomic Projection Alarm and under an overhang for accuracy. 2. Install one mounting screw (not included) into a wall leaving approximately ½ inch (12.7mm) extended.. -
Page 11: Accuracy
Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. -
Page 12: Fcc
Technology, Ltd will pay ground return shipping charges to the owner of the product to a USA address only. The La Crosse Technology, Ltd warranty covers all defects in material and workmanship with the following specified exceptions: (1) damage caused by accident, unreasonable use or neglect (including the lack of reasonable and necessary maintenance);...
