Remarks: SET-5 、 SET-6 、 SET-7 、 SET-8 、
SET-9means year,month,day,hour,minute(This is
optional )
9. Check & Adjustment
9.1 Check & Adjustment of Plate Vial
Check
① Rotate the instrument horizontally by loosening the Horizontal
Clamp Screw and place the plate vial parallel with the line
connecting leveling screw A and B, and then bring the bubble to
the center of the plate vial by turning the leveling screws A and B.
②Rotate the instrument 180° （200g）around its vertical axis.
Observe the bubble of plate vial. Fellow the steps below to adjust
it if the bubble is not in the center.
