SMART MAX GEOSYSTEMS CO.,LTD
www.smartmaxgeosystems.com
1.Take away the eyepiece, fit on the diagonal eyepiece, and
locked.
2. Leveling the instrument, then power on.This must be done on a
fiducial point.
3. Circumgyrate the telescope to make the vertical angle to
0°00'00",turn the laser on.Then move the foucsing screw to make
the facula minimum,loosenthe horizontal clamp screw, move the
telescope,the geometry center of the facula's movig track is the
Vertical Direction.

7.4 Level Measurement

1. Leveling the instrument, then power on..
2. Lock the telescope after it is on the horizontal direction,aim at
the target carefully.Turn on the laser,the red laser line can be used
as level line.

8. Parameter Setting Up

8.1 Enter into Setting up Parameter

Operation Procedure
¤
①Press
and then press
ENT when in the angle
measurement mode to
info@smartmaxgeosystems.com
Display
08-01-02 12：00
SET-1
OFF
23
