②Aim at the Target A
Press 0SET（one time）to
set the reading of A as:
0°00'00"
③Aim at the Target B by
Horizontal Tangent and
Clamp Screws.
Press ENT（one time）to
remain the horizontal angle
and it will be saved
④Aim at the Target A
again
Press 0SET (one time）to
set the reading of
as:0° 00'00".(It begins the
first remeasurement.)
⑤Aim at the Target B
again by
Tangent and Clamp Screws
Press ENT（one time）to
remain and
A
n-1:the beginning of the angle
Horizontal
n-0: the ending of the angle
T-0 ～ T-8:
save the remeasurement
info@smartmaxgeosystems.com
08-01-02 12：00
n - 1
H
0°00'00"
：
R
08-01-02 12：00
n - 1
H
0°00'00"
：
R
08-01-02 12：00
n - 0
H
20°00'01"
：
R
the
T-0
T-1
T-2
times of
