Return-to-Home (RTH)

Return-to-Home (RTH) function brings the aircraft back to the last recorded Home Point. There are three
types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH. This section describes these three scenar-
ios in detail.
Home Point
Aircraft can sense and avoid obstacles when Forward Vision System is enabled and the lighting
conditions are sufficient. The aircraft will automatically climb to avoid an obstacle and fly to the
Home Point at the new altitude.
Forward Vision System can be enabled during flight or RTH only.
Failsafe RTH
If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH
will be automatically activated if the remote controller signal is lost for a specified amount of time (3
seconds when using the remote controller and 20 seconds when using Wi-Fi). Return-to-Home can be
cancelled by the pilot, allowing them to regain control when the remote controller signal connection is re-
established.
1 Record Home Point
4 Signal Lost for Extended Time
×
Aircraft cannot return to the Home Point when the GPS signal is weak ( [
unavailable.
The aircraft cannot avoid obstruction during Failsafe RTH if Forward Vision System is disabled.
It is important to set a suitable Failsafe altitude before each flight. Launch the DJI GO app, enter
"Camera" and tap
User cannot control the aircraft while it is ascending to its failsafe altitude. However, user can
press RTH button to exit the ascent and regain control.
GPS
If a strong GPS signal was acquired before takeoff, the Home Point is
the location from which the aircraft launched. The GPS signal strength
is indicated by the GPS icon (
blink rapidly when the home point is recorded.
2 Confirming Home Point
5 RTH (adjustable altitude)
×
Failsafe Altitude
to set the Failsafe Altitude.
Description
Height over HP>Failsafe Altitude
Elevate to Failsafe Altitude
Height over HP<=Failsafe Altitude
Mavic Pro User Manual
). The aircraft status indicator will
3 Remote Controller Signal Lost
×
6 Landing (after user confirmed landing)
×
Hovering at 2 meters above
the Home Point
] displays grey) or
©
