  • Page 1: Table Of Contents

    Weight Integration Features SureLock II™ Integrated Weight Release System Maximum Weight Capacity Loading Weight into the SureLock II™ Pouches Installing the SureLock II™ Weight Pouches on your BC Releasing SureLock II™ Weight Pouches Non-releasable Weight © 2012 Aqua Lung International...

  • Page 2: Copyright Notice

    Aqua Lung. It may not be distributed through the internet or computer bulletin board systems without prior consent in writing from Aqua Lung.

  • Page 3: Safety Information

    This manual provides essential instruction for the proper fitting, adjustment, inspection and care of your new BC. Because Aqua Lung BC’s utilize patented technology, it is very important to take the time to read these instructions in order to understand and fully enjoy the features that are unique to your specific model.
  • Page 4 Factory prescribed service for this BC must be performed at least once annually by a factory trained technician who is employed by an Authorized Aqua Lung Dealer or Distributor. Annual service consists of a complete overhaul of the power inflator, and a general air leak inspection of the bladder and valve connections.
  • Page 5 If you have any questions regarding your Buoyancy Compensator or the information found in this manual, please contact your regional Aqua Lung Dealer or Distributor. Distributor information is available on the Aqua Lung website at: www.aqualung.com...

  • Page 6: Dealer Inspection And Service

    NOTE: It is important to obtain prescribed dealer service for your BC at least once annually, from an Authorized Aqua Lung Dealer or Distributor, your personal safety and the mechanical integrity of your BC depends on it. © 2012 Aqua Lung International...

  • Page 7: Annual Service And Inspection Record

    English Home ANNUAL SERVICE AND INSPECTION RECORD Purchase Date: Store Name: Country: BC Model: Serial Number: DATE DEALER NAME CITY, STATE COUNTRY TECH INITIALS © 2012 Aqua Lung International...

  • Page 8: Warranty Information

    Aqua Lung warrants to the original purchaser for the useful life of the product, from the date of purchase, that the product will be free from defects in materials and workmanship, provided that it receives normal use, proper care and prescribed dealer service subject to the limitations listed below.
  • Page 9 This warranty gives you specific legal rights. You may have rights which vary from state to state and country to country. AQUA LUNG DISCLAIMS AND EXCLUDES ANY LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES IN THE U.S. AND CERTAIN FOREIGN COUNTRIES DO NOT ALLOW EXCLUSIONS OR LIMITATIONS OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS MAY NOT APPLY TO YOU.

  • Page 10: Basic Setup

    Home BASIC SETUP Aqua Lung recommends that you bring your buoyancy compensator, together with your regulator, to your authorized dealer for the installation of the MP inflator hose and other accessories. The retailer can also answer any questions you may have pertaining to the information in this manual.

  • Page 11: Attaching The Mp Hose To The First Stage

    3. Check to ensure the o-ring is present and in good condition. Screw the threaded end of the hose into the port and tighten to 40 in-lbs (4.5 Nm) with a 9/16” wrench. © 2012 Aqua Lung International...

  • Page 12: Routing & Attaching The Mp Inflator Hose (I3 Inflator)

    3. Remove the dust cap on the quick disconnect plug on the i3 control unit. NOTE: Keep the dust cap on while not in use. 4. Grab the hose grip between your thumb and forefinger, then slide the sleeve back. © 2012 Aqua Lung International...
  • Page 13 M/ML/L - 33 inches (84 cm) (pn 44833) - White XL - (Dimension i3 and Axiom i3 only) 36 inches (91.5 cm) (pn 44836) - Blue XXL - (Axiom i3 only) 40 inches (101.5 cm) (pn 44840) - Lt Gray © 2012 Aqua Lung International...

  • Page 14: Griplock™ Cylinder Band Components

    Insert the open end of the cylinder band into the large opening of the bail, around the slide bar and out the small opening of the bail. Secure the hook and loop on the band to hold the bail in place. © 2012 Aqua Lung International...

  • Page 15: Adjusting The Griplock™ Cylinder Band

    B. Al 80 cf (7.25 in/184 mm) C. Smaller cylinder 2. Adjust the macro adjustment for the proper cylinder size. 3. Secure the excess webbing under the trim pocket (if equipped) after cylinder size is selected. © 2012 Aqua Lung International...

  • Page 16: Securing The Griplock™ Cylinder Band

    BC straight, parallel with the cylinder. NOTE: Over-tightening the valve strap can result in the BC being drawn in towards the cylinder which may be uncomfortable to wear. © 2012 Aqua Lung International...
  • Page 17 The pre-locked position ensures your fingers do not get caught in the lever. 4. Push the lever down into the locked position. Verify the lever is secured in the locked position. Once the cylinder band is set up, further adjustment is typically not needed. © 2012 Aqua Lung International...

  • Page 18: Donning And Adjustment Procedures

    4. While your dive buddy lifts and holds the BC/cylinder behind you, place your arms through the BC torso straps as if you were putting on a jacket. © 2012 Aqua Lung International...
  • Page 19 Adjusting the shoulder straps too tightly will transfer the cylinder weight from the hips to the shoulders, restricting your arm movement and decreasing comfort. 8. If necessary, readjust the waistband and waist buckle so that they are comfortably snug, but not restricting. © 2012 Aqua Lung International...

  • Page 20: Adjusting The Rail System

    The chest strap is on an adjustable rail system. Adjust the chest strap up or down on the rail system by pushing in on the spring release, slide the chest strap to the desired position and release the spring to lock in place. © 2012 Aqua Lung International...

  • Page 21: Weight Integration Features

    Refer to the model-specific label, usually found in the pocket of your BC, to find the designated lift capacity, and load weight pouches accordingly (see photo above). © 2012 Aqua Lung International...

  • Page 22: Loading Weight Into The Surelock Ii™ Pouches

    Your BC may not be able to float by itself on the surface if your BC is loaded with weight at or near its maximum buoyancy. In water weight of cylinders and other equipment may contribute to negative buoyancy of your full set of SCUBA equipment. Soul i3 BC Weight Capacity Chart Soul i3 BC Size...
  • Page 23 Loading Weight into the SureLock II™ Weight Pouches Aqua Lung recommends that each pouch is loaded with equal amounts of weight for optimum balance, preventing the tendency to roll to one side during the dive. Also, it is strongly recommended that each...
  • Page 24 Loading Soft Weight into the SureLock II™ Weight Pouches Aqua Lung recommends block weights be used in the SureLock II weight pouch for the best fit and ease of insertion. Soft weights may be used, but it is critical that the weights be loaded and secured correctly.
  • Page 25 INSTALLING THE SURELOCK II™ WEIGHT POUCHES ON YOUR BC CAUTION: Aqua Lung strongly recommends that you do not attempt to don your BC when it is fully loaded with weight. You may otherwise risk injury due to muscle strain or a temporary loss of balance.
  • Page 26 To avoid injuring other divers, always look below you before dropping weight. NOTE: In addition to becoming familiar with the weight system yourself, it is very important to explain its function to your dive buddy so that he/she is equally familiar with it. © 2012 Aqua Lung International...
  • Page 27 (trim) pockets after the BC has been secured to the cylinder. The non-releasable weight pockets are designed to hold single rectangular weight blocks. To avoid accidental loss of weight, Aqua Lung strongly advises against using small bullet-shaped weights and shot weight.
  • Page 28 Control Unit inoperable. You may otherwise be unable to achieve positive buoyancy in an emergency, which could lead to serious injury or death. © 2012 Aqua Lung International...
  • Page 29 3. Push the mouthpiece against your lips and exhale into the mouthpiece. Immediately after exhaling, move the mouthpiece away from your lips to keep the air from escaping the BC. © 2012 Aqua Lung International...
  • Page 30 1. Using your index finger as a guide, begin folding the oral inflator hose, bending once under the hook & loop closure. 2. Continue to fold the hose together until it is positioned between the hook and loop closure. © 2012 Aqua Lung International...
  • Page 31 3. Hose should fit evenly and flat under the hook & loop closure. 4. Secure the oral inflator snugly with the hook & loop closure. WARNING: Incorrect oral inflator storage could result in failure to deploy. © 2012 Aqua Lung International...
  • Page 32 Flat E-Valves simultaneously to allow air to escape the BC regardless of your body position. Deflate the BC in short bursts until you become neutrally buoyant. WARNING: Avoid using excessive torque when pressing the lever for the i3 control unit. © 2012 Aqua Lung International...
  • Page 33 In order to dump air as quickly as possible, always use the dump valve at the highest point in the water column. Deflation via the Flat E-Valve located on the upper right shoulder is only effective in the horizontal position. © 2012 Aqua Lung International...
  • Page 34 Most training agencies recommend that you descend in an upright feet- first position, in order to maintain a slower controlled descent. This is especially true if you experience difficulty equalizing your ears, or if you are descending in low visibility conditions. © 2012 Aqua Lung International...
  • Page 35 BC knives available from Aqua Lung. For information on available knife models, consult an Authorized Aqua Lung Dealer or Distributor. To attach or remove the knife and sheath from the BC, refer to the instructions provided with the knife.
  • Page 36 Your BC features an Octo Pocket located on the inside of one or both of the BC lobes which allows you to easily place your octopus (alternate air source) in a highly visible, easy to access location. Fold the hose back on itself and insert downward into the pocket. © 2012 Aqua Lung International...
  • Page 37 The excess weight of some double cylinders may also lead to structural failure of the wrapture harness. Such an event while diving may separate you from your primary air source, and could lead to serious injury or death. © 2012 Aqua Lung International...
  • Page 38 WARNING: If you can hear any leaks, or if the bladder begins to deflate within 5-10 minutes, DO NOT attempt to use the BC until it has received service from an Authorized Aqua Lung Dealer or Distributor. 4. Make a final check of the cylinder band’s tension to ensure that it has not loosened due to stretching.
  • Page 39 After rinsing, inflate the BC, and allow it to dry inside and out. Store the BC partially inflated, away from direct sunlight and in a clean, dry area. Do not store the BC in an enclosed space, such as a car trunk, where temperatures may fall below 0ºF (-18ºC) or rise above 120ºF (49ºC). © 2012 Aqua Lung International...
