Reference Section
Table 36 - PowerFlex 755 Embedded EtherNet/IP Port 13 Parameter Settings
No. Drive User
Parameter Setting
Name
33 Port Number 13
36 BOOTP 0
38 IP Addr Cfg 1 192
39 IP Addr Cfg 2 168
40 IP Addr Cfg 3 1
41 IP Addr Cfg 4 xxx
42 Subnet Cfg 1 255
43 Subnet Cfg 2 255
44 Subnet Cfg 3 255
42 Subnet Cfg 4 0
Leave the remainder of the Embedded EtherNet/IP (Port 13) parameters at their default settings.
Set the Start, Stop, and Speed Reference Commands via the EtherNet/IP Adapter
By default, the Start and Stop commands are enabled over the EtherNet/IP adapter. To set the speed reference via the
EtherNet/IP adapter, set parameter 545 [Spd Ref A Sel]. See
Table 37 - Speed Reference Parameter Setting
No. Drive User
Parameter Setting
Name
545 Spd Ref A Sel 877
56
Default Value/Options
0
1 0 = Disabled
1 = Enabled
0
Default Value/Options
871 P871 = Port 1 HIM reference
P877 = Port 13 reference
Rockwell Automation Publication 750-QS001A-EN-P - March 2015
Notes
A reset of the adapter is required. Reset the adapter by power cycling the drive or by using
the HIM's Reset Device function located in the drive's DIAGNOSTIC folder.
Example IP Address.
Set to desired value.
Table 37.
Notes
Selects the source parameter number for the speed reference while in "Auto" (typical)
mode. Reference value from port devices. For a speed reference from a communication
network, set this parameter to Port 0 and select P871...877 [Port_n_Reference] as
appropriate.
Important Example: 20-COMM-E, EtherNet/IP Communication Adapter = Dint for speed
reference multiplied by 1,000 (60 Hz = 60,000 and 1750 RPM = 1,750,000).
