Reference Section
Table 5 - Soft Key Label Explanation
Soft Key Label
Name
CLR
Clear
DEL
Delete
EDIT
Edit
END
End
ENTER
Enter
ESC
Escape
EXP
Exponent
FIX
Fix
INFO
Information
INS
Insert
LINK
Link
LOWER
Lower
MOST
Most
PAR#
Parameter Number
PGDN
Page Down
PGUP
Page Up
REF
Reference
RESET
Reset
TEXT
Text
TOP
Top
UPPER
Upper
VIEW
View
ZONES
Zones
36
(Continued)
Function
• Deletes an entire text string.
• Displays the Select Action pop-up box used to clear the selected fault, alarm or event, or the entire fault,
alarm or event queue.
Deletes a highlighted character.
• Accesses a displayed parameter to edit.
• Accesses the Edit Process Display screen.
• Displays the end (least recent) fault, alarm or event in a queue
• Scrolls to the end line of data on the Device Version information screen.
• Displays the next level of a selected menu item.
• Enters new values.
• Performs the intended action.
• Cancels port verification conflict pop-up box during procedure to resolve a conflict.
• Cancels the existing screen and returns to the previous screen.
• Cancels an entry.
• Cancels pop-up Fault Display screen.
• Displays the time zone groups list screen (only when the Date/Time Set Edit Mode screen is shown).
Allows data entry using scientific notation for 32-bit REAL (floating point) values.
Fixes 'Changed' or 'Requires Configuration' port verification conflicts upon powerup.
• Shows additional information about a selected port verification conflict upon powerup.
• Shows additional information about Set Default actions.
Inserts a space to the left of a highlighted character.
Displays a Link Edit pop-up box to link parameters (only PowerFlex 7-Class drives).
Displays the lower 16 bits (bits 0...15) of a 32-bit Bit-type parameter.
Restores most Host or Port device parameters to factory defaults.
Navigates directly to a parameter.
Scrolls down to the next page of data lines on the Device Version information screen.
Scrolls up to the previous page of data lines on the Device Version information screen.
Enters the speed reference for the Host Drive.
Resets the Process screen's displayed monitoring items to the factory default monitoring items.
Edits user-definable text for the device selected.
• Displays the top (most recent) fault, alarm or event in a queue.
• Scrolls to the top line of data on the Device Version information screen.
Displays the upper 16 bits (bits 16...31) of a 32-bit Bit-type parameter.
• Toggles between select screens and views.
• Displays the time stamp screen from a fault, alarm or event queue screen.
Displays the Select Time Zone screen.
Rockwell Automation Publication 750-QS001A-EN-P - March 2015
