Step 5: Special Considerations

Step 5: Special Considerations
Drive 1 Drive 2 Drive 3
Dynamic Brake
Accel and Decel Rates
Analog Output
Digital Output
Relay Output
Disable HIM Function
HIM CopyCat Function
Motor Overload
Type of Communications Other than EtherNet/IP
18
Drive 4 Drive 5 Description
Dynamic brake resistor connected to BR1 and BR2.
Accel and decel rates are set according to load inertia.
Decel rate can affect the need for dynamic braking.
PowerFlex 753 connected to TB1 terminals Ao0±.
Expansion I/O module connected to Ao0±.
PowerFlex 753 main control board connects to TD1 (TO0) as appropriate.
Expansion I/O module connected to TB1 (TO and TC or T1) as appropriate.
PowerFlex 753 main control board connected to TB2 (R0C and R0NO or
R0NC) as appropriate.
Expansion I/O module connected to TB2 (R0C and R0NO or R0NC) as
appropriate.
Option to restrict logic control (start, jog, direction) via the HIM, if the user
requires to only use other discrete input or communications controlled
start/run, jog, and direction commands.
Option to upload individual parameter sets for the host drive or any of its
connected peripherals into the HIM.
Adjust motor overload protection as appropriate.
Communication options other than EtherNet/IP.
Rockwell Automation Publication 750-QS001A-EN-P - March 2015
Details
page 66
page 68
page 74
page 74
page 75
page 75
page 76
page 76
page 77
page 78
page 82
See the publications in For
More Information on page 6.
