Autotune
1. Access parameter 70 [Autotune].
• Press the PAR# soft key.
• Enter 70.
• Press the ENTER soft key.
2. Press the EDIT soft key and use the
Stopped
0.000 Hz
Port 00 Dev Param
Autotune
Ready 0
ESC PAR#
Parameter Screen
3. Press the Start
"Autotuning" replaces "Stopped" while the drive is tuning. After Autotune routine is done, "Ready 0" appears in
parameter 70 [Autotune] and the top line again displays "Stopped".
Autotuning
Port 00 Dev Param
Autotune
Static Tune 2
ESC PAR#
In Progress Screen
4. The Autotune routine is complete.
5. Press the ESC soft key to exit Autotune.
or
▼
Stopped
AUTO
0.000 Hz
F
70
Edit Autotune
Static Tune 2
0 << 2
EDIT ESC
Edit Screen
key.
Stopped
AUTO
0.000 Hz
F
70 Port 00 Dev Param
Autotune
TEXT ESC
Result Screen
Rockwell Automation Publication 750-QS001A-EN-P - March 2015
Step 3: Power Up, Configure the Drive, and Spin the Motor Shaft
soft keys to select "Static Tune 2."
AUTO
F
ENTER
AUTO
F
70
Ready 0
PAR# TEXT
