Page 2: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 3: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 4: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 5: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup °... -
Page 6: Specifications
Introduction Specifications Processor Options Keyboard Intel® Core™ i7 Processor “WinKey” keyboard (with embedded numeric keypad) i7-4750HQ (2.0GHz) Pointing Device 6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 47W Built-in Touchpad Core Logic Latest Specification Information Interface The specifications listed here are correct at the Intel®... - Page 7 Introduction Communication Built-In Gigabit Ethernet LAN 1.0M HD PC Camera Module WLAN/ Bluetooth Half Mini-Card Modules: (Factory Option) Intel® Centrino® Advanced-N 6235 Wireless LAN (802.11a/g/n) + Bluetooth 4.0 (Factory Option) Intel® Centrino® Advanced-N 6205 Wireless LAN (802.11a/g/n) (Factory Option) Third-Party Wireless LAN (802.11b/g/n) (Factory Option) Third-Party Wireless LAN (802.11b/g/n) + Bluetooth 4.0 Environmental Spec...
-
Page 8: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-in PC Camera (Optional) 2. PC Camera LED 3. Built-In Microphone 4. LCD 5. Power Button 6. Keyboard 7. Touchpad & Buttons 1 - 4 External Locator - Top View with LCD Panel Open... -
Page 9: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator FRONT VIEW Figure 3 Right Side View 1. Headphone-Out RIGHT SIDE VIEW Jack 2. Microphone-In Jack 3. USB 3.0 Port 4. 1 * Powered (AC/ DC) USB 3.0 Port 5. -
Page 10: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent/Fan Intake/ Outlet 2. DC-In Jack LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. Mini Display Port 5. HDMI-Out Port Figure 5 REAR VIEW Rear View 1. -
Page 11: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent/Fan Intake/ Outlet 2. Speakers Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7... -
Page 12: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 13: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 14: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove screws from the bottom cover (Figure 1a a. Remove the screws. 3. Lift the bottom cover from point (Figure 1b b. Remove the bottom cov- 4. -
Page 15: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal (cont’d.) or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. -
Page 16: Removing The Keyboard
Disassembly Removing the Keyboard Figure 3 Keyboard Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. Lift the center cover at point toward the direction of the arrow (Figure 4a). a. Lift the center cover. 3. - Page 17 Disassembly 6. Carefully lift up the keyboard off the computer (Figure 5d). Figure 4 7. Remove the keyboard shielding plate up and off the bottom case (Figure 5e). Keyboard Removal 8. Reverse the process to install a new keyboard. (cont’d.) d.
-
Page 18: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L (Up to 1600 MHz). The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB and 2048MB DDRIII Modules. -
Page 19: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 6 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard and keyboard ribbon cable under the Wire- less LAN module (Figure...
