Page 1 Copiatrici - Copiers d-Color MF920 d-Color MF923 SERVICE MANUAL Code: Y112730-2...
Page 3: Table Of Contents
Table of contents Table of contents ............iii Notices and safety information .
Page 4 Fax specifications ..............1-18 Phone network connectivity .
Page 5 Toner meter cycle (TMC) card ........... . 2-58 Toner sensors (Y, C, M, K) on TMC card .
Page 6 Page Counts ..............3-19 Serial Number .
Page 7 TCP/IP ..............3-38 Paper jams .
Page 8 Left cover removal ............. . . 4-4 Right cover removal .
Page 9 Op panel cable ..............4-101 Logo cover .
Page 10 Y112730-2 Service Manual...
Page 11: Notices And Safety Information
Notices and safety information The following laser notice labels may be affixed to this printer. Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1.
Page 12 Avisos sobre el láser Se certifica que, en los EE.UU., esta impresora cumple los requisitos para los productos láser de Clase I (1) establecidos en el subcapítulo J de la norma CFR 21 del DHHS (Departamento de Sanidad y Servicios) y, en los demás países, reúne todas las condiciones expuestas en la norma IEC 60825-1 para productos láser de Clase I (1).
Page 13 Laserilmoitus Tämä tulostin on sertifioitu Yhdysvalloissa DHHS 21 CFR Subchapter J -standardin mukaiseksi luokan I (1) - lasertuotteeksi ja muualla IEC 60825-1 -standardin mukaiseksi luokan I lasertuotteeksi. Luokan I lasertuotteita ei pidetä haitallisina. Tulostimen sisällä on luokan IIIb (3b) laser, joka on nimellisteholtaan 5 mW:n galliumarsenidilaser ja toimii 770 - 795 nanometrin aallonpituuksilla.
Page 14 Avís sobre el Làser Segons ha estat certificat als Estats Units, aquesta impressora compleix els requisits de DHHS 21 CFR, apartat J, pels productes làser de classe I (1), i segons ha estat certificat en altres llocs, és un producte làser de classe I que compleix els requisits d’IEC 60825-1.
Page 15 Y112730-2 Notices and safety information...
Page 16 Y112730-2 Service Manual...
Page 17: Lithium Warning
Lithium warning CAUTION This product contains a lithium battery. THERE IS A RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY AN INCORRECT TYPE. Discard used batteries according to the battery manufacturer’s instructions and local regulations. Safety information • The safety of this product is based on testing and approvals of the original design and specific components.
Page 18 xviii Y112730-2 Service Manual...
Page 19 Sicherheitshinweise • Die Sicherheit dieses Produkts basiert auf Tests und Zulassungen des ursprünglichen Modells und bestimmter Bauteile. Bei Verwendung nicht genehmigter Ersatzteile wird vom Hersteller keine Verantwortung oder Haftung für die Sicherheit übernommen. • Die Wartungsinformationen für dieses Produkt sind ausschließlich für die Verwendung durch einen Wartungsfachmann bestimmt.
Page 20 Informació de Seguretat • La seguretat d'aquest producte es basa en l'avaluació i aprovació del disseny original i els components específics. El fabricant no es fa responsable de les qüestions de seguretat si s'utilitzen peces de recanvi no autoritzades. • La informació...
Page 21: Preface
Preface This manual contains maintenance procedures for service personnel. It is divided into the following chapters: General information contains a general description of the printer and the maintenance approach used to repair it. Special tools and test equipment, as well as general environmental and safety instructions, are discussed.
Page 22 xxii Y112730-2 Service Manual...
Page 23: General Information
1. General information The MF92x series are color laser MFPs that combine print, scan, copy, and fax functions. The MF92x series are the ideal MFPs for presentations, business graphics, line art, and text. They use laser diode electrophotographic technology to deliver remarkable quality print images and text. The scan and copy functions work with A4, letter, and legal (ADF only) size paper.
Page 24: Options And Features
Options and features Certain options are available on selected printer models only. Available options include: • 650-Sheet Duo Drawer—a 550-sheet drawer with a 100-sheet multipurpose feeder (MP Feeder). • Additional memory—One 128, 256, or 512MB memory card may be added. •...
Page 25: Print Quality
Print quality During the life of the printer, components are subject to wear based on usage. Printers continuously operating at or near the maximum duty cycle may require service for replacement of these components to ensure high- quality printing and good performance throughout the life of the printer. Replacement is recommended every 60,000 pages for the fuser and 60,000 pages for the ITU.
Page 26: Operating Modes
Operating modes Mode Description Normal Factory default Quiet Designed for customers where noise levels are a very important factor. • Print quality is maintained at factory default level. • Speed is reduced. Eco-Mode (Off is default): Designed for customers where the environment is a key factor. There are three options;...
Page 27: Dimensions
Dimensions Models Height Width Depth Weight MF920 291 mm (11.5 in.) 424 mm (16.7 in.) 400 mm (15.7 in.) 21 kg (46.2 lbs) MF923 422 mm (16.6 in.) 424 mm (16.7 in.) 416 mm (16.4 in.) 25 kg (54.9 lbs) 550-sheet Duo Drawer 133 mm (5.2 in.) 424 mm (16.7 in.)
Page 28: Power And Electrical Specifications
Power and electrical specifications The following table specified nominal average power requirements for the base printer configurations. All power levels are shown in Watts (W). Maximum current is given in Amperes (A). Printing states MF920 MF923 Average power while printing Continuous copy 480 W 510 W...
Page 29: Acoustics
Acoustics All acoustic measurements are made in accordance with ISO 7779-1999 and reported in conformance with ISO9296:1988-04-15. 1-Meter average sound Operating mode pressure at 4800 CQ MF920 MF923 Printing (simplex mono) 46 dBA 46 dBA Printing (simplex color) 47 dBA 47 dBA Printing (automatic 50 dBA...
Page 30: Media Handling
Media handling Input and output sources Sheet numbers are assuming 20 MF920 MF923 lb. xerographic paper Standard input sources Standard input tray (250-sheet 250 sheets 250 sheets tray) Manual feed slot (1-sheet) 1 sheet 1 sheet Second tray capacity (650- 550 sheets 550 sheets sheet Duo Drawer)
Page 31: Duplex Capability
Duplex capability Duplex Type —Supported Automatic duplex Models MF920 MF923 Media input size specifications —Supported without size sensing —Not supported Input source A4 210 x 297mm 148 x 210mm 182 x 257mm Letter 8.5 x 11 in. Legal 8.5 x 14 in. Executive 7.25 x 10.5 in.
Page 32 —Supported without size sensing —Not supported Input source 10 Envelope 105 x 241mm (4.12 x 9.5 in.) DL Envelope 110 x 220mm (4.3 x 8.7 in.) C5 Envelope 162 x 229mm (6.4 x 9 in.) B5 Envelope Other envelope Length: 98–432mm (3.8–17 in.) Width: 89–297mm (3.5–11.7 in.)
Page 33: Media Input Type Specifications
Media input type specifications —Supported —Not supported Input type Plain paper Card stock Transparency Recycled Glossy Paper-backed labels Bond Envelopes Rough envelopes Letterhead Preprinted Colored paper Light paper Heavy paper Rough or cotton Custom type <x> For MP feeder and manual feeders, the Default Source Menu displays Manual Paper and Manual Env.
Page 34 Weight ranges for each media type Material Type Weight Select 2, 5, 7, 8 Paper Xerographic or 60 to 74. 9 g/m grain long Light Paper 2, 5 business paper (16 to 19.9 lb bond) 75 to 89.9 g/m grain long Plain Paper (20 to 23.8 lb bond) 90.
Page 35: Media Guidelines
Media guidelines Paper characteristics The following paper characteristics affect print quality and reliability. Consider these characteristics when evaluating new paper stock. • Weight—The printer can automatically feed paper weights from 60 to 176 g/m (16 to 47 lb bond) grain long.
Page 36: Selecting Paper
• Do not store anything on top of individual paper packages. Using recycled paper and other office papers As an environmentally conscious company,Olivetti supports the use of recycled office paper produced specifically for use in laser (electrophotographic) printers. • Low moisture content (4–5%) •...
Page 37 Recycled paper, paper of lower weight (<60 g/m [16 lb bond]) and/or lower caliper (<3.8 mils [0.1 mm]), and paper that is cut grain-short for portrait (or short-edge) fed printers may have lower bending resistance than is required for reliable paper feeding. Before using these types of paper for laser (electrophotographic) printing, consult your paper supplier.
Page 38: Digital Imaging Specifications
Digital imaging specifications General specifications ADF Scan speed Simplex ADF - Up to 5 ppm Duplex ADF - Up to 5 ppm (page sides) ADF Document handling ADF input capacity - 50 sheets. ADF output capacity - 50 sheets. ADF document width - 4.9” (125mm) to 8.5”(216mm) ADF document length - 5”...
Page 39: Scan And Copy Specific Specifications
Scan Resolutions • Optical - 600 dpi (Local Twain only) • Enhanced (Olivetti Scan Center) - 1200 X 1200 dpi, 2400 X 2400 dpi, 4800 X 4800 dpi, 9600 X 9600 dpi, 19200 X 19200 dpi Output resolutions • Mono - 600 X 600 dpi •...
Page 40: Fax Specifications
Fax specifications Phone network connectivity Phone networks types supported PSTN or analog PABX (RJ-11) ITU COMPATIBILITY Group 3/ECM Standard Resolution 8 x 3.85 pels/mm (200X100dpi) (204x98) Fine 8 x 7.7 pels/mm (200X200dpi) (204x196) Superfine 11.8 x 11.8 pels/mm(300x300 dpi) (204x391) Ultrafine 15.7 x 15.7 pels/mm (400x400 dpi) (408x391) Coding...
Page 41: Tools Required For Service
Tools required for service Flat-blade screwdrivers, various sizes #1 Phillips screwdriver, magnetic #2 Phillips screwdriver, magnetic #2 Phillips screwdriver, magnetic short-blade 7/32 inch (5.5 mm) open-end wrench 7.0 mm nut driver Needlenose pliers Diagonal side cutters Spring hook Feeler gauges Analog or digital multimeter Parallel wrap plug 1319128 Flash light (optional)
Page 42: Acronyms
Acronyms. Alternating Current Autocompensator Mechanism (or paper feed) Automatic document feeder Analog front end All-In-One Automatic Paper Size ASIC Application Specific Integrated Circuit BLDC Brushless DC Motor Black Only Retract Belt up down Cyan Charge-Couple Device CCFL Cold Cathode Fluorescent Lamp Counter clockwise Command Descriptor Blocks CMYK...
Page 43 High voltage unit Hertz INTL International Internal Tray Card Image Transfer Unit Black (Key) Local area network LASER Light amplification by stimulated emission of radiation Liquid crystal display Liquid Crystal Module Laser Diode Light emitting diode Long edge feed Laser Scanning Unit Low Voltage LVPS Low voltage power supply...
Page 44 Random access memory RFID Radio frequency identification Relative humidity Raster image processor Read-only memory Read-only storage Revolutions Per Minute Scanner Control Card SDRAM Synchronous Dynamic Random Access Memory Short edge feed SIMM Single Inline Memory Module Solenoid Start of scan SRAM Static random access memory Toner Add Roll...
Page 45: Diagnostic Information
2. Diagnostic information Start CAUTION Unplug the power cord from the electrical outlet before you connect or disconnect any cable or electronic board or assembly for personal safety and to prevent damage to the printer. Disconnect any connections between the printer and PCs/peripherals. Begin here to locate the service error code, user status message, user error message, symptom table, service checks, and diagnostic aids in this chapter to determine the corrective action necessary to repair a malfunctioning printer.
Page 46: Por (Power-On Reset) Sequence
POR (Power-On Reset) sequence The following is an example of the events that occur during the POR sequence for the base machine with no paper-handling options installed. When you turn the printer on, it performs a Power-On Self Test. Check for correct POST functioning of the base printer by observing the following: The LED turns on.
Page 47: Symptom Tables
Symptom tables Printer symptom table Symptom Action Dead printer Go to “Dead printer service check” on page 2-35. Operator panel—one or more buttons do Go to “One or more operator panel buttons fail” on not work. page 2-42. Operator panel—display is blank. Printer Go to “Operator panel display blank, five beeps”...
Page 48: Scan / Fax / Copy Symptom Table
Symptom Action Unexpected page breaks occur • Increase the Print Timeout value on the operator panel (Settings–>General Settings–>Timeouts–>Print Timeout.) Scan / fax / copy symptom table Symptom Action 840.xx scanner error Go to “840.xx service check” on page 2-63. ADF won’t duplex (Duplex ADF only) Go to “ADF Duplex service check”...
Page 49: Print Quality Symptom Table
Print quality symptom table Symptom Action Background Go to “Print quality—background” on page 2-49. Blank page Go to “Print quality—blank page” on page 2-50. Blurred or fuzzy print Go to “Print quality—blurred or fuzzy print” on page 2-52. Half-color page Go to “Print quality—half-color page”...
Page 50: Error Codes And Messages
Error codes and messages User status and attendance messages User status and attendance messages User primary message Explanation Busy Wait for the message to clear. Calibrating The printer is performing a color adjustment. Close Door Message clears when upper and lower doors are closed. Check Config ID The printer configuration ID is invalid.
Page 51 User status and attendance messages (continued) User primary message Explanation Load <source> Printer does not detect media meeting the description <custom type> in <source>, <custom type> where <source> is Tray 1 or Tray 2, Tray 3. • Load the input source with the correct type and size media. •...
Page 52 User status and attendance messages (continued) User primary message Explanation Remove Paper ADF This posts when there is paper detected in the ADF upon POR or when the cover is closed (or any other situation that re-inits the scanner). Message clears when paper is removed.
Page 53 User status and attendance messages (continued) User primary message Explanation 31.xx Defective <color> The specified cartridge is defective. Try one of the following: cartridge • Open and close the top cover. • Remove and re-install the cartridge(s). Listen for the click to ensure the cartridge is installed properly.
Page 54 User status and attendance messages (continued) User primary message Explanation 37 Insufficient memory This message is displayed when insufficient printer memory is available to perform for flash defragment Flash Memory Defragment operation. operation This message appears prior to the actual start of the defragment operation. press Select ( ) to stop the defragment operation.
Page 55 User status and attendance messages (continued) User primary message Explanation 52 Flash Full • press Select ( to clear the message and continue printing. • Delete fonts, macros, and other data stored on the flash memory. • Install a larger capacity flash memory card. 53 Unformatted Flash press Select ( to clear the message and continue printing.
Page 56 User status and attendance messages (continued) User primary message Explanation 82.xx Waste toner The following actions can be taken: nearly full • Replace the waste toner bottle, and then press Select ( ) to clear the message and continue printing. See Go to “Waste toner bottle”...
Page 57: Paper Jam Messages
Paper Jam messages Paper jam messages (2xx) Error code Description Action 2xx paper jams 200.xx Paper Jam A single page of media jam at the input Remove the tray1 unit, open the front door, Check <area> sensor. and remove the print cartridge to access the jam area.
Page 58 Paper jam messages (2xx) (continued) Error code Description Action 250.xx Paper Jam A single page of media is jammed in Open tray 2 to access the jam area. Check Manual the multipurpose feeder. Remove the jammed page. See “250 Feeder paper jam”...
Page 59: Service Error Messages
Service error messages Service error messages (1XX, 8XX and 9xx) Error code Description Action 106.xx Service Yellow printhead error. Perform a POR. If the problem persists, go Yellow Printhead “Printhead service check” on page 2-57. 106.01 Service The yellow printhead lost HSYNC. Perform a POR.
Page 60 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 107.08 Service The cyan laser showed bad in EMS Perform a POR. If the problem persists, go Cyan Printhead testing. “Printhead service check” on page 2-57. 107.11Service Failure writing data to printhead Perform a POR.
Page 61 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 109.02 Service The black printhead failed to complete Perform a POR. If the problem persists, go Black Printhead servo. “Printhead service check” on page 2-57 109.03 Service The black printhead mirror motors Perform a POR.
Page 62 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 122.13 Service Fuser open thermistor check failed for Go to “Fuser service check” on Fuser Error second thermistor. page 2-39. 122.14 Service Fuser shorted thermistor check failed Go to “Fuser service check”...
Page 63 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 152.xx Service Go to “Main drive gear assembly (EP CMY Cartridge Motor drive) service check” on page 2-41. 152.01 Service Failed to achieve lock for motor within Go to “Main drive gear assembly (EP CMY Cartridge Motor allotted time.
Page 64 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action Rear scan module lamp level too low Rear Mono channel, Rear Color channels, Rear Red channel, Rear Green channel, 844.03 and/or Rear Blue channel is detected to have low lamp level. Go to “CCD service check”...
Page 65 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action Front calibration strip has excessive Front excessive variability for Mono, Red, 846.06 dark area Green, or Blue. Go to “CCD service check” on page 2-65 Front magnification exceeds limits Rear excessive variability for Mono, Red, 846.07 Green, or Blue.
Page 66 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 907.xx Service A general engine software error. Go to “90x.xx error” on page 2-31 Engine Software 908.01 Service Board level was not obtained. Engine Software? 908.02 Service Timeout waiting for bullet serial data to Engine Software be updated.
Page 67 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 950.xx Service There is a mismatch between controller Go to “950.xx NVRAM failure service NVRAM Failure EEPROM and mirror. check” on page 2-33. • 950.00 through 950.29 codes: mismatch between controller and mirror •...
Page 68 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 958.xx Service Printer has performed more than 100 NAND Failure “shift and reflash” operations as a result of ECC bit corrections. 959.01 Service Controller verification failure of pensive Update firmware or replace controller Invalid Firmware boot code...
Page 69 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 964.xx Service Download emulation cyclic redundancy The following actions may be taken: Emulation Error check (CRC) failure has occurred. A 1. Disable the Download Emulation. checksum failure detected in the 2.
Page 70 Service error messages (1XX, 8XX and 9xx) (continued) Error code Description Action 990.xx Service This error message indicates that an <device> equipment check condition has occurred in the specified device, but the device is unable to identify the exact component failure. Note: <device>...
Page 71: Fax Error Log Codes
Fax error log codes Fax error log codes Error code Description Action No error occurred during fax No action needed transmission Error occurred when transmitting • Check line quality. • Select a lower ‘Max Speed’. training. • value under Fax Send settings •...
Page 72 Fax error log codes (continued) Error code Description Action T5 Timeout occurred when transmitting • Check line quality. image data to remote fax device. • Adjust ‘Transmit Level’. • Select a lower ‘Max Speed’value under Fax Send settings. Too many errors when transmitting in •...
Page 73 Fax error log codes (continued) Error code Description Action Failure to transmit training successfully • Select a lower “Max Speed” under Fax in V17, V29 terminal modulation Send settings. schemes. • Adjust the “Transmit Level”. • Check line quality. Failure to transmit training successfully •...
Page 74 Fax error log codes (continued) Error code Description Action Modem detected a digital line Verify the MFP is connected to an analog connection. line. See“Fax transmission service check” on page 2-72. Phone line was disconnected Restore phone line connection. Received request for unsupported No action needed.
Page 75: Service Checks
Service checks 90x.xx error Step Questions / actions Turn the printer off, and remove the rear Replace the controller Securely make all the shield. See “Rear shield removal” on board. See “Controller connections. POR the page 4-7. Check the cable connections. board removal”...
Page 76: Printhead Service Check
Printhead service check Error code Color 106.xx Yellow 107.xx Cyan 108.xx Magenta 109.xx Black Step Questions / actions Turn the printer off, and remove the rear Replace the printhead. See Go to step 2. shield. See “Rear shield removal” on “Printhead removal”...
Page 77: 950.Xx Nvram Failure Service Check
950.xx NVRAM failure service check Warning: Replace one of the following components, and perform a POR before replacing a second component. Never replace both of the components without performing a POR after installing each one, or the printer will be rendered inoperable: •...
Page 78: Bin Full Sensor Service Check
Step Questions / actions Turn the printer on, and then verify the Replace the Replace the controller following approximate values at JSP1: autocompensator board. See “Controller mechanism. See board removal” on JSP1 “Autocompensator page 4-18. mechanism (ACM)— Value standard tray removal” on page 4-12.
Page 79: Dead Printer Service Check
Dead printer service check A dead printer is a condition where the display is blank, the LED on the operator panel is off, the fan does not turn, no motors turn, and the fuser does not heat. If a 650-sheet Duo Drawer is installed, remove the option and check the base printer for correct operation. If the base printer operates correctly, replace the 650-sheet Duo Drawer.
Page 80: Duplex/Manual Feed Sensor (S1) Service Check
Duplex/manual feed sensor (S1) service check Note: Before performing this service check, ensure that the printer is on a hard level surface. Step Questions / actions Enter Diagnostics Menu (turn the printer off, Go to step 2. Go to step 4. press and hold , turn the printer on, and then release the buttons when the...
Page 81: Front Door Sensor Or Switches Service Check
Front door sensor or switches service check Step Questions / actions Enter Diagnostics Menu (turn the printer off, press Sensor, toner door, and Go to step 2. and hold , turn the printer on, and then right doors are OK. release the buttons when the installed memory and processor speed displays).
Page 82: Fuser Exit Sensor Service Check
Fuser exit sensor service check Step Questions / actions Enter Diagnostics Menu (turn the printer off, Correct the sensor or Go to step 2. press and hold , turn the printer on, replace it. See “” on and then release the buttons when the page 4-28.
Page 83: Fuser Service Check
Fuser service check Step Questions / actions Some low-voltage power supply FRUs have a Check the switch on the Go to step 2. voltage selector switch. If it does, the switch side of the LVPS to verify needs to be set to the correct voltage for your the correct voltage is set.
Page 84: Input Sensor (S2) Service Check
Step Questions / actions Replace the fuser. See “Fuser assembly Problem resolved. Replace the controller removal” on page 4-25. board. See “Controller board removal” on Does the error clear? page 4-18. Input sensor (S2) service check The Input sensor (S2) is part of the autocompensator FRU and is not available otherwise. Step Questions / actions Enter Diagnostics Menu (turn the printer off,...
Page 85: Main Drive Gear Assembly (Ep Drive) Service Check
Main drive gear assembly (EP drive) service check Step Questions / actions Turn the printer off, and remove the rear Replace the JCARTB1 Go to step 2. shield. See “Rear shield removal” on cable. page 4-7. Check the cable at JCARTB1 for proper connection to the controller board, the cable for pinch points, and the cable or connector for any other damage.
Page 86: Operator Panel Service Check
Operator panel service check Warning: Replace one of the following components, and perform a POR before replacing a second component. Never replace both of the components without performing a POR after installing each one, or the printer will be rendered inoperable: •...
Page 87: Operator Panel Display Blank, Printer Beeps Five Times And Pauses
Step Questions / actions Turn the printer off, and remove the rear Go to step 3. Replace the controller shield. See “Rear shield removal” on board. See “Controller page 4-7. Disconnect the operator panel board removal” on assembly cable at JOPP1 on the controller page 4-18.
Page 88: Operator Panel Displays All Diamonds, No Beeps
Operator panel displays all diamonds, no beeps Step Questions / actions Turn off the printer, and remove the rear Go to step 2. Replace the controller shield. See “Rear shield removal” on board. See “Controller page 4-7. Disconnect the cable at JOPP1 on board removal”...
Page 89: Operator Panel Display Is Dim And Unchanging
Operator panel display is dim and unchanging Step Questions / actions Turn off the printer, and remove the rear Go to step 2. Replace the controller shield. See “Rear shield removal” on board. See “Controller page 4-7. Disconnect the cable at JOPP1 on board removal”...
Page 90: Networking Service Check
Have the network administrator verify that the device is using the correct SSID, and wireless security protocols. For more network troubleshooting information, consult the Olivetti Network Setup Guide. Step...
Page 91 Step Questions / actions Try using a different ethernet cable. Problem resolved Go to step 14. Did this remedy the situation? Have the network administrator check the Replace the controller Contact the network network drop for activity. board. Go to “Controller administrator.
Page 92: Print Quality Service Check
Print quality service check Note: This symptom may require replacement of one or more CRUs (Customer Replaceable Units) designated as supplies or maintenance items, which are the responsibility of the customer. With the customer's permission, you may need to install a developer (toner) cartridge or photo conductor unit. Service tip Before troubleshooting any print quality problems, do the following: Print a menu settings page, and check the life status of all supplies.
Page 93: Print Quality-Background
Print quality—background Service tip: Some background problems can be caused by rough papers, non-Olivetti toner cartridges or if the media texture is set to the rough setting. Some slick or coated papers may also cause background problems. Some problems occur with printers that run a large amount of graphics in a humid environment.
Page 94: Print Quality-Blank Page
Step Questions / actions Clean the printhead. Problem resolved. Replace the printhead. See “Printhead removal” on Does this fix the problem? page 4-56. Print quality—blank page Step Questions / actions Is all the packing material for the imaging unit Go to step 2. Remove the packing in question removed? material.
Page 95 Step Questions / actions 1. Remove the image unit and waste toner Go to step 5. Replace the Main drive gear bottle. assembly. See “Main drive gear assembly with motor 2. Replace the right cover and close the front removal” on page 4-53.
Page 96: Print Quality-Blurred Or Fuzzy Print
Print quality—blurred or fuzzy print Run the automatic alignment. The TPS sensor may be damaged. To run Reset Color Cal: Enter the Diagnostics Menu. (Turn the printer off, press and hold , turn the printer on, and release the buttons when installed memory and processor speed displays.
Page 97: Print Quality-Horizontal Line
Print quality—horizontal line Either the photoconductor unit or one of the developer units that make up the imaging unit is defective. Remove and inspect the imaging unit. Replace the damaged part of the imaging unit. See “Imaging unit (IU) removal” on page 4-40.
Page 98: Print Quality-Narrow Vertical Line
Print quality—narrow vertical line ABCDE ABCDE ABCDE Step Questions / actions Replace the photoconductor unit. See Problem solved. Replace the developer unit. “Developer unit “Imaging unit (IU) removal” on page 4-40. removal” on page 4-42 Print quality—random marks Service tip: The primary cause of random marks is due to loose material moving around inside the printer and attaching to the photoconductor unit, developer roll, or transfer belt.
Page 99: Print Quality-Residual Image
Print quality—residual image Service tip: Install a new print cartridge, if available, before doing this service check. Residual image can be caused by the photoconductor, cleaning blade, and other parts ABCDE inside the print cartridge. ABCDE ABCDE Step Questions / actions Check the condition of the imaging unit using Go to step 2.
Page 100: Print Quality-Solid Color Page
Print quality—solid color page Service tip: A solid color page is generally caused by a problem in the high-voltage controller or an incorrect high voltage in the printing process resulting in toner development on the entire photoconductor drum. Step Questions / actions Replace the photoconductor unit (part of the Problem resolved.
Page 101: Printhead Service Check
Printhead service check This service check includes the following errors: Error codes Color 106.xx Yellow 107.xx Cyan 108.xx Magenta 109.xx Black Step Questions / actions Turn the printer off, and remove the rear Replace the printhead. See Go to step 2. shield.
Page 102: Toner Meter Cycle (Tmc) Card
Toner meter cycle (TMC) card Step Questions / actions Perform the Base Sensor Test: Replace the toner cartridge. Replace the toner meter cycle (TMC) card. See 1. Enter Diagnostics menu (turn off the “Toner meter cycle (TMC) printer, press and hold and Select ( card removal”...
Page 103: Transfer Roll Service Check
Transfer roll service check Step Questions / actions Remove the ITU. See “Image transfer unit Replace the ITU. See Problem resolved. (ITU)” on page 4-35. Check the contacts “Image transfer unit (ITU)” between the HVPS and the ITU. Clean the on page 4-35.
Page 104: Tray (X) Sensor Service Check
Tray (x) sensor service check Step Questions / actions When the printer is in Ready state, pull the Go to step 2. Go to step 4. standard tray out. The display should indicate Tray (x) Missing. Insert the tray. Does the message remain on the display? Check the vertical well at the right rear of the Replace the tray.
Page 105: Option Trays 2 And 3 Service Check
Option trays 2 and 3 service check Step Questions / actions Are two option trays being used? Go to step 2. Go to step 4. If two option trays are being used, is the 550 Go to step 4. Go to step 3. sheet tray on the bottom? Switch the order of the trays so the 500 sheet Problem resolved...
Page 106 Step Questions / actions Turn off the printer, and remove the rear Consult your second level Replace the controller shield. “Rear shield removal” on page 4-7. support. board. See Disconnect the cable at JOPT1 on the controller board. Turn the printer on, and measure the voltages below.
Page 107: 840.Xx Service Check
Scanner / Copy / Fax service checks 840.xx service check Step Questions / actions POR the machine into configuration mode. Go to step 2. Stop. Problem resolved. Go to the disable scanner menu item. See “Disable Scanner” on page 3-36. Select “Enable ADF/FB -Enabled and press save the change.
Page 108 Step Questions / actions Replace the ADF unit. See “Duplex ADF Go to step 8. Stop. Problem solved. removal” on page 4-83or “Simplex ADF removal” on page 4-84. POR the machine into configuration mode. Go to the disable scanner menu item. See “Disable Scanner”...
Page 109: Black Or Blank Page Copy Service Check
Black or blank page copy service check Step Questions / actions Print a menu page, or a page from the host. “Print quality—solid Go to step 2. Is the page black? color page” on page 2-56 Is the copy an ADF scan? Go to step 3.
Page 110: Flatbed Home Position Service Check
Flatbed home position service check Step Questions / actions POR the MFP. Does the CCD move and Problem solved. Go to step 2. return to the home position? Perform the home position sensor test. Go Go to step 3. Go to step 5. “Scanner Tests”...
Page 111: Adf Cover Open Service Check
ADF cover open service check Step Questions / actions Is the ADF cover properly closed Go to step 3. Go to step 2. Close the ADF cover. Issue resolved Go to step 3. Does the problem go away? Perform the ADF cover open sensor test. Go to step 4 Go to step 8.
Page 112: Adf Paper Jam Service Check
ADF paper jam service check Note: This service check should be used if the paper feeds and jams in the ADF. If the paper is not feeding into the ADF see “ADF feed errors service check” on page 2-69. Step Questions / actions If the ADF is multi-feeding, check for dirt on Clean them with a lint free...
Page 113: Adf Feed Errors Service Check
ADF feed errors service check Step Questions / actions If the ADF is multi-feeding, check for Clean them with a lint free Replace the separator pad and dirt on the ADF separator pad and cloth and isopropyl alcohol. ADF pick roll. ADF separator rollers.
Page 114: Adf Duplex Service Check
ADF Duplex service check Step Questions / actions Perform sensor 1, and sensor 2 Go to step 2. Go to step 3. sensor tests. Go to “Scanner Tests” on page 3-25. Are the sensors working properly? Check the ADF sensor actuators to Go to step 3.
Page 115: Modem / Fax Card Service Check
Modem / fax card service check Step Questions / actions Is the phone line properly connected to the Go to step 2. Go to step 3. modem card and the wall jack? Properly connect the phone line to the Problem resolved. Go to step 3.
Page 116: Fax Transmission Service Check
Fax transmission service check Note: Before performing this service check, verify that the correct country code for the MFP is selected. This setting must match the country in which the MFP is used to transmit and receive faxes. If the setting is wrong, the modem settings can be changed in the Fax/SE menu.
Page 117 Step Questions / actions Adjust the “Transmit Level” setting in the SE Stop. Problem resolved. Go to your second-level of menu. press **411 to enter the SE menu, support. See “Escalating a enter Modem settings, and select “Transmit fax issue to second-level Level”.
Page 118: Fax Reception Service Check
Fax reception service check Step Questions / actions Is the phone line properly connected to the Go to step 2. Go to step 3. modem card and the wall jack? Properly connect the phone line to the Problem resolved. Go to step 3. modem card and wall jack.
Page 119 Step Questions / actions Go to the Administrator menu. Enter the Fax Go to step18 Go to step 19. settings - Analog Fax Settings submenu. Verify the remote device number is not in the Banned Fax List user setting. Is the remote device number in the banned fax list? Remove the remote number from the Problem resolved.
Page 120: Escalating A Fax Issue To Second-Level Support
Escalating a fax issue to second-level support Before contacting the second-level support, go to the SE menu on the MFP.and generate a Fax error file. This file contains machine settings information and debug information that will help second-level support determine the cause of a failure.
Page 121: User Operator Panel, Menus And Messages
User operator panel, menus and messages Understanding the operator panel The printer operator panel has a four-line, back lit, grayscale display that can show both graphics and text. The Mode selection, job setup, Back, and Menu buttons are located to the left of the display, the navigation buttons are located below the display, and the start buttons, stop button, and numeric pad are located to the right of the display.
Page 122 Button or indicator Function Start / Black and White press to start a job in black and white. Stop/Cancel Stops all printer activity. A list of options is offered once Stopped appears on the display. Operating modes Copy Selecting this option enables copy mode. Scan / E-mail Selecting this enables scan and scan to E-mail mode.
Page 123: Menu Map
Menu map This menu map identifies menus available to customers. The diagram shows the menus on the operator panel and items available under each menu. Some menu items or values are displayed only if a specific option or feature is installed on your printer. Other menu items may be effective only for a particular printer language.
Page 124 2-80 Y112730-2 Service Manual...
Page 125: Diagnostic Aids
3. Diagnostic aids This chapter explains the tests and procedures to identify printer failures and verify repairs have corrected the problem. Menu key combinations. There are different test menus that can be accessed during POR to identify problems with the printer. Configuration Menu 1.
Page 126: Diagnostics Menu (Diag Menu)
Diagnostics Menu (Diag Menu) Note: Tray 2 refers to the 650-sheet tray located in the 650-sheet Duo Drawer assembly. Diagnostics menu structure When the Diagnostics mode is entered, each Diagnostics main menu item displays on the operator panel. When a diagnostic test is selected from the main menu, a sub menu displays, and each individual test displays in the order shown.
Page 127 Diagnostics mode tests (continued) INPUT TRAY TESTS (if Tray 2 is installed) Feed Tests “Feed Tests” on page 3-17. Sensor Tests “Sensor Test” on page 3-17. BASE SENSOR TEST “Base Sensor Test” on page 3-18. Front Door Input S1 Input S2 Fuser Exit Standard Bin C TMC Sensor...
Page 128: Registration
Diagnostics mode tests (continued) Print Log “Print Log” on page 3-23. Clear Log “Clear Log” on page 3-24. Development Menu Do not use. For development use only. Scanner Tests ASIC Test “ASIC Test” on page 3-25. Feed test “Feed Test” on page 3-25.
Page 129: Skew
Description Value Direction of change Right margin -50 to +50 A positive change moves the image to the left, and a negative change moves the image to the Each increment corresponds to an right. approximate shift of 4 pixels at 600 dpi.
Page 130: Quick Test
Horizontal lines to check for skew • General printer information, including current page count, installed memory, serial number, and code level. Olivetti MF92x series To print the Quick Test page: Note: Print the Quick Test Page on letter or A4 paper.
Page 131: Alignment
Alignment Aligns each of the color planes to the black plane. Print the Quick Test under each color, Cyan, Yellow, and Magenta, and adjust the Top Margin, Left Margin, Right Margin, Skew, and Bow. Prints the Print Alignment Pages and requires that the best line in each set of lines must be selected. To get started: Select Alignment Menu from the Diag Menu, and press Select ( Select a color (Cyan, Yellow, or Magenta), and press Select (...
Page 132 Select Top Margin, and press Select ( Select the best choice for fine or coarse adjustment in Step 1 (first page), and add it to the current value for the Top Margin. to enter the sum of the numbers, and press Select ( Submitting changes…...
Page 133 Select the Skew value in the same way, enter the value, press Select ( ), and print the Quick Test to see if the observed values and the current values are the same. On the second page of the latest Quick Test you printed, proceed to Step 2; adjust the left, right,and bow settings.
Page 134: Factory Scanner
Factory Scanner Note: This setting is not used by field service. Factory Manual Note: This setting is not used by field service. Miscellaneous Tests Motor Detect This test initiates an automatic motor detection process that should be performed whenever the controller board is replaced.
Page 135: Print Tests
The print quality test consists of five pages. Pages one and two contain a mixture of graphics and text. The remainder of the pages contain only graphics. The test prints on the media in tray 1. Olivetti MF92x series Y112730-2...
Page 136 This test may be printed from either Configuration Menu or the Diagnostics Menu. To run the print quality pages from the Diagnostics Menu: Select PRINT TESTS, and press Select ( Select Print Quality Pgs, and press Select ( The message Printing Quality Test Pages is displayed. Note: Once the test is started, it cannot be cancelled.
Page 137: Hardware Tests
Hardware Tests Panel Test This test verifies the operator panel LCD function. To run the Panel Test: Select Hardware Tests from Diag Menu, and press Select ( Select Panel Test, and press Select ( The Panel Test continually executes. press Stop ( ) to cancel the test.
Page 138: Cache Test
To stop the test early, turn off the printer. CACHE Test The CACHE Test is used to verify the processor cache is functioning properly. Select Hardware Test in Diag Menu, and press Select ( Select CACHE Test, and press Select ( The printer displays: CACHE Test Testing…...
Page 139: Duplex Tests
This test prints a duplex version of the Quick Test that can be used to verify the correct placement of the top margin on the back side of a duplex page. Olivetti MF92x series Note: Before you set the duplex top margin, be sure to set the registration. See “Registration”...
Page 140: Top Margin (Duplex)
Hold the page to the light to see whether the left margin of the back aligns with the left margin of the front. Select Left Margin from DUPLEX TESTS. to select the margin setting you need to change. • Each increment shifts the duplex left margin by 4 pixels at 500 dpi (0.0067 inches or 0.1693 mm). •...
Page 141: Input Tray Tests
Input Tray tests Feed Tests This test allows you to observe the paper path of media as it passes through the printer. Any installed input tray can be tested. The pages fed through the printer are blank. To run the Feed Test: Select INPUT TRAY TESTS from Diag Menu, and press Select ( Select Feed Tests, and press Select ( Select the tray to be tested.
Page 142: Base Sensor Test
Base Sensor Test These tests allow you to verify the correct functioning of the front door, input, and output sensors. Select Base Sensor Test from Diag Menu, and press Select ( Select the sensor you want to test, and press Select ( The following test are available: Sensor Value...
Page 143: Printer Setup
Printer Setup Defaults US/Non-US defaults changes whether the printer uses the US factory defaults or the non-US factory defaults. The settings affected include paper size, envelope size, PCL symbol set, code pages, and units of measure. Warning: Changing this setting resets the printer to factory defaults, and data may be lost. It cannot be undone. Page Counts You can view, but not change any of the three counts displayed under PAGE COUNTS.
Page 144: Itu Barcode
Unless the menu is in DIAGNOSTICS, Check Config ID displays. • To set the configuration ID: Select PRINTER SETUP from DIAGNOSTICS, and press Select ( Select Configuration ID, and press Select ( The current value for Configuration ID 1 appears with the left character or digit underlined. Enter the Configuration ID 1.
Page 145: Reset Fuser Count
Reset Fuser Count Resets the fuser count value to zero. The Event Log records each time that a user executes the Reset Fuser Count operation. See “Event Log” on page 3-32 for more information. This setting appears only if the Maintenance Warning and Intervention function is enabled in the printer Configuration ID.
Page 146: Tps Setup
TPS Setup Right or Left TPS The value of the TPS sensor is set at manufacturing. If a sensor is replaced, enter the 32-digit hexadecimal TPS value from the barcode next to the sensor. To enter the value: Select TPS SETUP from Diag Menu, and press Select ( Select Right or Left, and press Select ( TPS Right 1-16 or TPS Left 1-16 appears above a blinking 0 in the left position.
Page 147: Event Log
• Time and date stamps • Page counts for most errors • Additional debug information in some cases Model and Serial number Olivetti MF92x series Printer information Panel display when error occurred Page count Earliest error code Y112730-2 3-23 Diagnostic aids...
Page 148: Clear Log
The printed event log can be faxed to your next level of support for verification or diagnosis. To print the event log: Select EVENT LOG from DIAGNOSTICS, and press Select ( Select Print Log, and press Select ( press Back ( ) to return to EVENT LOG.
Page 149: Scanner Tests
Scanner Tests ASIC Test This test initiates a scan of the scanner ASIC’s memory. While this test is executing ASIC Test Running is displayed. When the test is complete, ASIC Test Passed is displayed if the ASIC memory is ok. ASIC Test Failed is displayed if the test fails. press the Back or Stop buttons to clear the display message Feed Test This test executes a continuous feed test from ADF or flatbed.
Page 150 ADF paper present sensor test This test should be used if the ADF fails to feed paper when a scan is performed. To test this sensor perform the following steps: In the sensor test menu, press to scroll to the ADF paper present test. ).Starting Test displays.
Page 151 FB Cover closing sensor test This test verifies the functionality of the FB cover closed sensor. To test this sensor. perform the following steps: In the sensor test menu, press to scroll to the FB Cover closing sensor test. ). Starting Test displays. FB Cover: Closed displays. press Select ( Lift the flatbed cover, and depress the FB cover actuator (A).
Page 152 Sensor 1 test This test verifies the functionality of scan sensor 1. To test this sensor. perform the following steps: In the sensor test menu, press to scroll to the Sensor1 test. ). Starting Test displays. Sensor 1: Closed displays. press Select ( Lift the ADF top cover, and close the ADF cover sensor by pressing down on the ADF sensor actuator (A) with a small flat blade screwdriver.
Page 153 Sensor2 test This test verifies the functionality of scan sensor 2. To test this sensor. perform the following steps: In the sensor test menu, press to scroll to the Sensor 2 test. ). Starting Test displays. Sensor 2: Closed displays. press Select ( Lift the ADF top cover, and close the ADF cover sensor (A) by pressing down on the ADF sensor actuator with a small flat blade screwdriver.
Page 154: Exit Diags
EXIT Diags press Select ( ) to exit Diag Menu. The printer performs a power-on reset and returns to normal mode. 3-30 Y112730-2 Service Manual...
Page 155: Configuration Menu
Configuration Menu Available tests The tests display on the operator panel in the order shown for all models. Configuration menu USB Scan to Local “USB Scan to Local” on page 3-31. Prt Quality Pgs “Prt Quality Pages” on page 3-31. Color Trapping “Color Trapping”...
Page 156: Reports
Color Trapping Uses an algorithm to compensate for mechanical incorrect registration in the printer. When small black text or fine black lines are being printed, the printer checks to see if they are being printed on top of a colored background.
Page 157: Demo Mode
Demo Mode Lets marketing personnel or merchandisers demonstrate the printer to potential customers by printing the demo page. Selections include Deactivate (default) and Activate. Select Deactivate to turn Demo Mode off; or select Activate to turn Demo Mode on. Factory defaults Sets the majority of printer values back to their factory default settings.
Page 158: Min Copy Memory
Min Copy Memory This setting allocates the amount of DRAM memory to be used for storing copy jobs in the queue. 25, 35,50,80 and 100 MB are the available settings. To adjust the minimum copy memory, perform the following steps: In the configuration menu, scroll to the MinCopy Memory item, and press Use the to increase or decrease the setting’s value.
Page 159: Fb Edge Erase
FB Edge Erase This menu item sets the size, in millimeters, of the no print are around a flatbed scan job. Copy jobs will use the setting or two millimeters, whichever is larger. To adjust the flatbed edge erase setting, perform the following steps: In the Configuration menu, select the FB Edge Erase menu item.
Page 160: To Manually Register The Flatbed, Perform The Following Steps
Use the to increase or decrease the settings value. Note: Each button press moves the margin values one pixel in the respective direction. Press to accept the value. Scroll to Top Edge, and press Use the to increase or decrease the settings value. Note: Pressing moves the margin up, and pressing moves the margin down.
Page 161: Font Sharpening
Font Sharpening This setting is used to set a text point size value below which the high frequency screens will be used when printing data. This setting affects only PCL, PostScript and PDF emulators. Settings are in the range of 0–150 (24 is the default). For example, if the value is set to 24, then all fonts sized 24 points or less use the high frequency screens.
Page 162: Se Menu
SE Menu Note: This is not the Fax SE menu. To enter the Fax SE menu, press **411 from the Ready screen. Note: This menu should be used as directed by second-level support. Print SE Menus General Copyright - Displays copyright information. Optra Forms mode - On or off Code Revision Info Network Code Level - Displays network code level...
Page 163: Paper Jams
Paper jams Avoiding jams The following hints can help you avoid jams: • Use only recommended paper or specialty media. For more information, see the Card Stock & Label Guide available at http://www.olinet.biz. • Do not load too much paper. Make sure the stack height does not exceed the indicated maximum height. •...
Page 164: Understanding Jam Numbers And Locations
Understanding jam numbers and locations When a jam occurs, a message indicating the jam location appears. The following illustration and table list the paper jams that can occur and the location of each jam. Open doors and covers, and remove trays to access jam locations.
Page 165: 200 Paper Jams
200 paper jams Remove the standard 250-sheet tray (tray 1). Remove the jam. Note: Make sure all paper fragments are removed. Insert the tray. press Select ( 201 paper jam Grasp the front door at the side handholds, and then pull it toward you to open it. Remove the jammed paper.
Page 166 202 paper jam Raise the scanner assembly to the up position. Grasp the front door at the side handholds, and then pull it toward you to open it. Grasp the green lever, and pull the fuser cover toward you. Hold the fuser cover down, and then remove the jammed paper. The fuser cover closes when released.
Page 167: 230 Paper Jam
230 paper jam Grasp the front door at the side handholds, and pull it toward you to open it. Remove the jam. press Select ( ) to continue printing. 235 paper jam Load the tray with the correct paper size. Insert the tray.
Page 168: 29X Adf Paper Jam
29x ADF paper jam Remove all original documents from the ADF input tray. Open the ADF top cover. Remove the jammed paper. Close the ADF cover. Open the flatbed cover. Remove any jammed pages. Close the scanner lid. Press 3-44 Y112730-2 Service Manual...
Page 169: 291.Xx Adf Paper Jams
291.xx ADF paper jams Remove all original documents from the ADF input tray. Remove the ADF input tray. See “ADF input tray” on page 4-84. Remove the original from the ADF by pulling the lower of the two sheets (A) from the ADF exit. Replace the ADF input tray.
Page 170: Updating Printer Firmware
Updating printer firmware The latest firmware can be found by going to http://www.olinet.biz. Warning: Before performing a firmware update on the printer, contact the technical service center or second level of support to verify the correct firmware and keycode. The wrong firmware or wrong level of firmware could lead to a malfunction or render the printer inoperable.
Page 171 Open the USBFlash utility. This window will display. Click the Browse Files button. The file browse dialog displays. In the file browse dialog, browse to the fullnet.fls (also called 1.fls) file. The fullnet.fls file is the RIP firmware file. Warning: It is critical that the RIP firmware gets updated first. Failure to do so, can render the printer inoperable.
Page 172 Select the printer needing the firmware update from the “Select Printer From List” dropdown menu. Click Start. The printer will start the update process. Various status and progress messages will appear on the printer’s operator panel. Warning: Do not turn the machine off until the update is complete. When the firmware update is completed, the printer will automatically reboot and return to a Ready state.
Page 173 0pen the USBFlash utility. This window will display. Click the Browse Files button. The file browse dialog displays. In the file browse dialog, browse to the updeng.fls (also known as 2.fls) file. The fullnet.fls file is the engine firmware file. This is the second file to be updated. Click Open.
Page 174 Select the printer needing the firmware update from the “Select Printer From List” dropdown menu. Click Start. The printer will start the update process. Various status and progress messages will appear on the printer’s operator panel. Warning: Warning: Do not turn the machine off until the update is complete. When the firmware update is completed, the printer will automatically reboot and return to a Ready state.
Page 175 Open the USBFlash utility. This window will display. Click the Browse Files button. The file browse dialog displays. In the file browse dialog, browse to the scanner.fls (also known as 3.fls) file. The scanner.fls file is the scanner firmware file. This is the last file to be updated. Click Open.
Page 176 Select the printer needing the firmware update from the “Select Printer From List” dropdown menu. Click Start. The printer will start the update process. Various status and progress messages will appear on the printer’s operator panel. Warning: Warning: Do not turn the machine off until the update is complete. When the firmware update is completed, the printer will automatically reboot and return to a Ready state.
Page 177: Updating The Firmware Using A Usb Thumb Drive
Updating the firmware using a USB thumb drive If a USB thumbdrive is available, it can be used to update the printer firmware. Before updating the firmware, download the zip file containing the firmware files from http://www.olinet.biz. Warning: Before performing a firmware update on the printer, contact the technical service center or second level of support to verify the correct firmware and keycode.
Page 178: Updating The Firmware Using A Networked Computer
Warning: DO NOT TURN THE MACHINE OFF until the update is complete. When the update is completed, the printer will automatically reboot and return to Ready. Updating the firmware using a networked computer Using FTP Before updating the firmware, download the zip file containing the firmware files from http://www.olinet.biz. Note: To update the printer using FTP, you should have an understanding of how to use an FTP client.
Page 179: Using The Printer's Internal Web Server
Using the printer’s internal Web server Before updating the firmware, download the zip file containing the firmware files from http://www.olinet.biz. Note: You will need the IP address of the printer on the network. This can be obtained from the Network Settings page found under Network Setup menu under Reports, in the Administrative menu.
Page 180 Scanner firmware update On a computer attached to the network, open a Web browser. Enter the printers IP address in the Web browsers address bar. Press Enter. The printers homepage opens. Click Settings. The settings page opens. Click the Update Firmware link. The update firmware page opens. Click the Browse button.
Page 181: Theory Of Operation
Theory of operation Print engine theory Electrophotographic Process (EP Process) The method that all laser and LED printers use to print is called the electrophotographic process. These machines use differences in charge to manipulate and move toner from the toner cartridge to the printed page. Even though the basic EP process is the same for every laser and LED printer, the specifics for each printer are different.
Page 182: Step 1: Charge
Step 1: Charge During the charge step, voltage is sent from the high-voltage power supply to the charge roller (A) beside each of the four photoconductors. The charge roller is part of the photoconductor unit. The charge roller (A) puts a uniform negative charge over the entire surface of the photoconductor to prepare it for the laser beam.
Page 183: Step 2: Expose
Step 2: Expose During the expose step, the laser fires a focused beam of light at the surface of each photoconductor (B) and writes an invisible image called a latent image or electrostatic image for each color. The laser beam actually discharges the surface only where the beam hits the photoconductor. This creates a difference in charge potential between the exposed area and the rest of the photoconductor surface.
Page 184: Step 3: Develop
Step 3: Develop Once the laser exposes the photoconductor, the high-voltage power supply sends charge to the developer roll (C). For each color, the toner cartridge engages the photoconductor so it is in contact with the surface. Because of the charge difference between the toner on the developer roller and the electrostatic image created by the laser, the toner will attract to the photoconductor only where the laser exposed the surface.
Page 185: Step 4A: First Transfer
Step 4a: First transfer When the latent images are developed on each Photoconductor, the high-voltage power supply sends voltage to the 1st Transfer Rollers inside the ITU (D). The charge difference between the developed toner image on the Photoconductor surface and the 1st Transfer Roller causes the images to transfer to the surface of the ITU belt for each color.
Page 186: Step 4B: Second Transfer
Step 4b: Second transfer Once the four planes of color are transferred to the transfer belt from the photoconductors, the image is carried towards the transfer roll (E). This transfer roll is also part of the ITU. Based on the speed of the transfer belt, the proper time to send the signal to pick the media from an input source is determined.
Page 187: Step 5: Fuse
Step 5: Fuse Once the image has been fully transferred to the media, the transfer roll helps move the paper into the fuser area. The fuser (F) applies heat and pressure to the page to melt the tiny toner particles and bond them permanently to the media.
Page 188: Step 6: Clean/Erase
Step 6: Clean/Erase There are two main cleaning processes that take place during the EP Process. One process cleans the transfer belt, and the other cleans the photoconductors. Transfer Unit Clean Once the toner image on the transfer belt has been transferred to the page, the transfer belt rotates around and is cleaned by the cleaning blade (G).
Page 189 Photoconductor Clean/Erase After each plane of color has been transferred to the transfer belt from the photoconductors, a cleaning blade (H) scrapes the remaining toner from the surface of each photoconductor. This is the clean/erase process. Now the photoconductor surface is prepared to begin the EP cycle once again. This cleaning/erasing cycle happens after each plane of color is transferred to the transfer belt.
Page 190: Paper Path, Transport Components
Paper path, transport components In order for an image to be printed, the media has to be moved from an input source (such as a tray) into the printer and eventually exit into an output source. The most important component in this process is this media itself. Old, damaged, or out-of-specification media can and will cause feed and transport problems.
Page 191: Transport Components
Transport components In summary, the media is fed from the tray into the printer by a feed roll and carried to the transfer roll (ITU). The pick rollers time the media to enter the EP process at just the right moment. The pick rollers push the media to the ITU where the image is transferred to the page.
Page 192 When the trailing edge of the media clears the fuser, the fuser engine rotates forward to prepare the fuser for the page travelling through the duplexer. As the media reaches the gate aligner, a sensor (S1) is triggered indicating the presence of the leading edge. When the S1 sensor is triggered, the paper continues to the S2 sensor.
Page 193: Scanner Theory
Scanner theory Duplex ADF The following illustration shows the paperpath, rollers and sensors used in the MF923 duplex ADF. The MF923 duplex ADF enables the user to create duplex scans automatically, eliminating the need to stop the scanning process to flip the media being duplicated over. The ADF uses a step motor, and a series of sensors to determine the media’s position in the paper path during the scan process.
Page 194 with the ADF scan sensor ensure that the media is travelling at the correct speed through the scan area. The speed the document travels through the ADF scan area is dependent on the image DPI specified by the user. 7. After a predetermined number of counts, the media reaches the scan area and the image acquisition process is initiated.
Page 195: Color Theory
Color theory What is RGB color? Red, green, and blue light can be added together in various amounts to produce a large range of colors observed in nature. For example, red and green can be combined to create yellow. Televisions and computer monitors create colors in this manner.
Page 196: My Color Transparencies Seem Dark When They Are Projected. Is There Anything I Can Do To Improve The Color
My color transparencies seem dark when they are projected. Is there anything I can do to improve the color? This problem most commonly occurs when projecting transparencies with reflective overhead projectors. To obtain the highest projected color quality, transmissive overhead projectors are recommended. If a reflective projector must be used, then adjusting the Toner Darkness setting to 1, 2, or 3 will lighten the transparency.
Page 197: How Can I Match A Particular Color (Such As A Corporate Logo)
How can I match a particular color (such as a corporate logo)? From the printer Quality menu, nine types of Color Samples sets are available. These are also available from the Color Samples page of the Embedded Web Server. Selecting any sample set generates a multiple-page printout consisting of hundreds of colored boxes.
Page 198 3-74 Y112730-2 Service Manual...
Page 199: Repair Information
4. Repair information Warning: Read the following before handling electronic parts. Handling ESD-sensitive parts Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power before removing logic boards: •...
Page 200: Removal Procedures
Removal procedures CAUTION Remove the power cord from the electrical outlet before you connect or disconnect any cable or electronic board or assembly for personal safety and to prevent damage to the printer. Disconnect any connections between the printer and PCs/peripherals. Notes: •...
Page 201 Remove the five screws (A) from the cable cover. Remove the cable cover. Remove the screw (B) securing the right restraining strap to the front cover. Note: Support the door with one hand after removing the screw holding the restraining strap. This is the longest screw of the eight.
Page 202: Front Middle Cover Removal
Front middle cover removal Open the front cover. Remove the five screws (A) attaching the front middle cover to the lower front cover. Pull the front middle cover away from the front cover. Left cover removal Remove the media tray. Open the front cover.
Page 203 Remove the three screws (A) on the rear side of the left cover. Y112730-2 Repair information...
Page 204 Remove the screw (B) on the bottom of the cover. With a hand on the bottom of the cover, ease the cover over the off/on switch, and rotate the cover away from the printer. Warning: Be careful not to damage the rear tab at the upper rear side of cover. Installation note: When replacing the left cover, flex the cover slightly to engage the tab near the power switch.
Page 205: Right Cover Removal
Right cover removal Remove the media tray. Lift and lock the flatbed assembly to the raised position. Open the front cover. Release the green latches securing the door. Lower the right cover and remove it from the hinges. Rear shield removal The rear shield is not a field replaceable unit (FRU).
Page 206: Aio Back Cable Cover Removal
AIO back cable cover removal Remove the two screws (A) which secure the AIO back cable cover to the MFP. Place a small flat-blade screwdriver under the bottom of the cover, and gently pry the cover upward. Y112730-2 Service Manual...
Page 207: Top Cover Assembly Removal
Top cover assembly removal Remove the flatbed assembly. Go to “Flatbed removal” on page 4-72. Remove the AIO toner cover. Go to “AIO toner cover” on page 4-97. Remove the five screws (A) from the left front side. Remove one screw (B) from the top right side of the cover. Y112730-2 Repair information...
Page 208 Remove the four screws (C) on the right side of the top cover. Remove the toroid holder (D) and two screws (E) from the rear. The toroid holder will be used on the new top cover. 4-10 Y112730-2 Service Manual...
Page 209: Installation
Detach the re-drive belt (F) from the pulley on the fuser exit roll shaft. Disconnect the fan power cable from JFAN1 on the controller board. Disconnect the bin full sensor cable from JPJ1 on the controller board. Remove the top cover, being careful to route the bin full sensor cable through the top of the controller board cage.
Page 210: Autocompensator Mechanism (Acm)-Standard Tray Removal
Autocompensator mechanism (ACM)—standard tray removal Remove the toner bottles, the waste toner container, and the imaging unit (IU). See “Imaging unit (IU) removal” on page 4-40 and see “Waste toner bottle” on page 4-67. Remove the rear shield. See “Rear shield removal” on page 4-7.
Page 211 Remove the two springs (D). Remove the two screws (E) on the bottom. Y112730-2 4-13 Repair information...
Page 212 On the right side, loosen the screw (F) with a screwdriver, and hold the ACM in place as you use your fingers to remove the screw. Move the right side of the ACM out to free the shaft from the hole in the frame. Note: Observe the location of the shaft and hole for reinstallation.
Page 213: Bin Full Sensor
Bin full sensor Remove the flatbed unit. See “Flatbed removal” on page 4-72. Using a small flatblade screwdriver, gently depress the tabs (A) which secure the sensor to the top cover assembly. Pull the sensor away from the top cover assembly. Disconnect the sensor from the cable.
Page 214: Narrow Media Sensor Flag Removal
Narrow media sensor flag removal Open the front cover. Remove the narrow media sensor flag. Remove the cable from the retainer. Note: Be sure to note the routing for re-installation. Disconnect the cable (A) from the narrow media sensor. 4-16 Y112730-2 Service Manual...
Page 215 If there is a sensor retaining plate (B), remove the plate. Pinch the retainers on the rear of the sensor, and gently remove the sensor from the bracket by hand. Installation note: Clean the contact surface where you removed the sensor retaining plate, or where you need to install the new one.
Page 216: Controller Board Removal
Controller board removal Warning: Observe all ESD precautions while handling electrostatic-discharge sensitive parts. See “Handling ESD-sensitive parts” on page 4-1. Warning: When replacing any one of the following components: • Operator panel assembly • Controller board Replace only one component at a time. Replace the required component, and perform a POR before replacing a second component listed above.
Page 217 Print a few pages to verify the installation. If the pages are blank, confirm that the high-voltage power supply cable is properly seated. The connector may have been loosened at the HVPS. A blank page that should have toner on it could be an indication that toner is applied to the ITU belt but not transferred.
Page 218: Duplex Reference Edge Removal
Duplex reference edge removal Open the front door. Remove the four short screws (A) in front, and the four longer screws (B) in the back of the duplex aligner. Lift the duplex aligner on the right side, and disengage the gears (C) on the left. 4-20 Y112730-2 Service Manual...
Page 219 Remove the four screws (D) from the duplex reference guide, and remove the guide. Installation notes: Align the duplex reference guide so the tabs (A) are inserted into the slots, and the top of the reference guide fits under the door ridges (B). Replace the four screws in the duplex reference guide.
Page 220 Be sure the shaft and bearing have not shifted out of the guide, and that the bearing on the left is aligned with the slot (C) facing down (towards the front door). Note: Improperly aligned bearings or shafts incorrectly seated may cause vibration and noise in the front door.
Page 221: Duplex Sensor Removal
Duplex sensor removal Remove the waste toner container. See “Waste toner bottle” on page 4-67. Remove the two screws (A) from the cable channel cover. Pull the corner of the cable channel cover (B) away from the right side to access the sensor posts (C). Y112730-2 4-23 Repair information...
Page 222 If there is a plate on the side the latches of the sensor connected, remove the old adhesive plate (D). Unlatch the sensor by pushing on the latches. Remove the sensor, and disconnect the cable (E) from the duplex sensor. Note: Close the front cover, and slightly lift the front of the printer to get better access.
Page 223: Fuser Assembly Removal
Fuser assembly removal Remove the right cover. See “Right cover removal” on page 4-7. Remove the left cover. See “Left cover removal” on page 4-4. Disconnect the two-wire fuser cable (A) from the LVPS. Position the fuser cable so that it can be pulled through from the front of the printer, and guide the cable to the front.
Page 224 Unhook the springs (D) from either side of the fuser. Detach the geared belt (E) from the drive pulley on the fuser exit roll shaft. Note: Do not remove the pulley or spacer from the shaft. Rotate the top of the fuser toward the front, slide it to the left to align the fuser side frame with the flat areas of the shaft (F) and lift to remove the fuser.
Page 225 Installation notes: • Make sure the springs are resting on the top so they can be reached once the fuser is in place. • When reinstalling on the right, make sure the gears mesh. • Be careful not to interfere with the exit sensor on the left side. •...
Page 226: Fuser Drive Motor Assembly Removal
Fuser drive motor assembly removal Open the front cover. Remove the right cover. See “Right cover removal” on page 4-7. Disconnect the cable (A) from the fuser drive motor assembly. Note: If you remove the toroid (B) from the cable, be sure to return the toroid to the cable when you re- install.
Page 227: Fuser Exit Sensor Removal
Fuser exit sensor removal Open the front cover. Remove the right cover assembly. See “Right cover removal” on page 4-7. Remove the left cover. See “Left cover removal” on page 4-4. Disconnect the two-wire fuser cable (A) from the LVPS. Note: You do not have to extract the cable.
Page 228 Unhook the springs (D) from both sides of the fuser. Rotate the fuser toward the front of the printer until the screw (E) can be accessed, and removed. Disconnect the cable (G) from the fuser exit sensor. Remove the screw (F) securing the fuser exit sensor. Remove the lower end of the sensor with a flat blade screwdriver, and gently pull the sensor from the frame.
Page 229: High-Voltage Power Supply (Hvps) Assembly Removal
High-voltage power supply (HVPS) assembly removal Remove the left cover. Is there a leaf spring (A) biasing the HVPS upward? • Go to “High-voltage power supply (HVPS) with spring” on page 4-33 • If there is no spring, go to “High voltage power supply (HVPS) with no spring removal”...
Page 230: High Voltage Power Supply (Hvps) With No Spring Removal
High voltage power supply (HVPS) with no spring removal Note: This removal requires a magnetized, long-shank Phillips screwdriver at least 8 in. or 200 mm long. Remove the top cover assembly. See “Top cover assembly removal” on page 4-9. Remove the rear shield. See “Rear shield removal”...
Page 231: High-Voltage Power Supply (Hvps) With Spring
Remove the screw (B) securing the HVPS. Carefully slide the HVPS out. Installation notes: CAUTION After disconnecting the high-voltage power cable from the controller board, always check that the HVPS connection was not loosened. Make this check anytime you are working near the HVPS cable.
Page 232 Remove the screw (A) securing the HVPS. Press down on the spring mount and carefully slide the HVPS out. Release the pressure on the spring mount when the LVPS slides out about 25mm. Installation notes: CAUTION After disconnecting the high-voltage power cable from the controller board, always check that the HVPS connection was not loosened.
Page 233: Image Transfer Unit (Itu)
Image transfer unit (ITU) Write down the number on the new ITU before installing it. You will need the 16-digit numeric value from the barcode after the installation, and it is easier to see at this point. Remove the right cover. See “Right cover removal”...
Page 234 Snap the new gear onto the shaft (D). The installation is the same as the old gear. 4-36 Y112730-2 Service Manual...
Page 235 Continuing the removal (with or without the spring clamp kit) Disconnect the one spring (A) from the side frames, leaving them attached to the ITU or spring clamp. Rotate the left spring (B) and pivot the cam away from the ITU so the spring is held out of the ITU path. Y112730-2 4-37 Repair information...
Page 236 Rotate the release lever (C) in a counter clockwise direction with a spring hook or needlenose pliers to decouple the ITU while pulling the ITU toward the front. Hold the release lever while removing the ITU. 4-38 Y112730-2 Service Manual...
Page 237 Installation note: • Write down the 16-digit numeric value of the new FRU before you begin to install it. • You may have to rotate the release lever again to install the new ITU. • Rotate the spring clamp so it hooks over the new ITU (E). Note: The spring should be on the right side of the gear shaft.
Page 238: Imaging Unit (Iu) Removal
Imaging unit (IU) removal The Imaging unit is customer-replaceable unit and is not a FRU. Open the front cover. Lift the toner cover by sliding the latch to the left. Remove the waste toner bottle. See “Waste toner bottle” on page 4-67.
Page 239 Press and hold the release lever (B), and pull the imaging unit straight out. Warning: When pulling the imaging unit out, Only grab the release levers (B) of the imaging unit.Do not touch the photoconductors in the bottom of the imaging unit. Y112730-2 4-41 Repair information...
Page 240: Developer Unit Removal
Developer unit removal The developer units are not FRUs. Raise the scanner unit, and remove the toner cartridges. Remove the imaging unit. See “Imaging unit (IU) removal”. Warning: Do not touch the underside of the imaging unit. This could damage the developer units. Remove the developer unit you need.
Page 241: Low-Voltage Power Supply (Lvps) Assembly
Low-voltage power supply (LVPS) assembly Remove the left cover. See “Left cover removal” on page 4-4. Disconnect the three cables (A) from the LVPS. Remove the six screws (B) and the ground cable connected to the LVPS cage. Remove the LVPS. Y112730-2 4-43 Repair information...
Page 242 Warning: If you receive a new low-voltage power supply with a voltage selector switch (C), be sure to set the switch to the correct setting for your voltage requirements before installing the low-voltage power supply. The switch can be set for either 115 V or 230 V. Failure to do so will result in damage to the power supply.
Page 243: Lower Frame Removal, Right And Left
Lower frame removal, right and left The right and left lower frames are in the same FRU. Left lower frame Remove the media tray, and remove the screw (A) in front. Remove the waste toner bottle. See “Waste toner bottle” on page 4-67.
Page 244 At the rear of the printer, remove the two screws (C) from the AC receptacle, and the ground screw (D). Remove the three screws (E) securing the left lower frame. Remove the LVPS. See 4-46 Y112730-2 Service Manual...
Page 245 Remove the screw (F) on top of the frame. Swing the left lower frame away from the printer, and remove. Y112730-2 4-47 Repair information...
Page 246: Right Lower Frame
Right lower frame Note: Remove the duplex sensor, the tray present sensor, the spring, spring holder, and the wireless antenna plate which are not part of the right and left lower frames. The cable cover is part of the right lower frame FRU. Note: To properly reinstall the duplex sensor and the tray present sensor, also order two sensor retaining plates.
Page 247 Remove the screw (C) securing the wireless antenna (Wireless models only) to access the right frame. Do not remove the antenna. Remove the duplex sensor. See “Duplex sensor removal” on page 4-23. Remove the three screws (D) securing the lower right frame to the printer. Remove the screw (E) close to the front of the printer.
Page 248 Swing the rear part away from the printer to access the spring, and remove the spring (F) from the right lower frame. Next to screw (E), lift the right lower frame pin (F) out of the hole in the printer frame. 4-50 Y112730-2 Service Manual...
Page 249 Swing the rear part away from the printer to access the spring (G), and remove the spring (G) from the right lower frame. Disconnect the cable (H) from the tray present sensor. Swing the rear of the lower frame away from the printer, and remove the right lower frame. Note: There are parts in the right lower frame that are not included in the frame.
Page 250 Remove the screw (L) and remove the spring bracket. Note: For non-wireless models—Remove the screw (M), and remove plate from your printer if it does not have a wireless antenna. Installation notes: Reinstall the spring bracket, and the wireless antenna plate (or the blank plate, if this is not a wireless model).
Page 251: Main Drive Gear Assembly With Motor Removal
Main drive gear assembly with motor removal Remove the left cover. See “Left cover removal” on page 4-4. Remove the LVPS. See “Low-voltage power supply (LVPS) assembly” on page 4-43 Remove the screws (A) on the top cover. Remove the two screws (B) from the inside left side. Disconnect the cable from the fuser exit sensor.
Page 252 Remove the screws securing the LVPS shield. Unplug the cables (C) from the motors, and remove all cables from the retainer (D). Note: Observe the cable routing for reinstallation. Remove the two screws (E) from the rear. Remove the two screws (F) from below the main drive gear assembly. Remove the two screws (G) from the right of the main drive gear assembly.
Page 253: Pick Tires Removal-Integrated 250-Sheet Media Tray
Pick tires removal—integrated 250-sheet media tray Note: You will need to have a soft, padded work surface. Warning: Remove only the rubber tires and not the paper pick tire assembly to avoid losing small parts. The paper pick tires are located in the base printer. There are also tires in the optional 550-page media tray. If you have this additional option, and you are having problems with media picking, replace these tires also.
Page 254: Printhead Removal
Printhead removal Remove the scanner assembly. See“Flatbed removal” on page 4-72. Remove the top cover. See “Top cover assembly removal” on page 4-9. Disconnect the cables. Remove the toroid (A) from the ribbon cable. Remove the three screws (B). Remove the printhead. Installation note: When the printhead is replaced, perform the registration (black planes) and alignment (color planes).
Page 255: Imaging Unit (Iu) Removal
Imaging unit (IU) removal The imaging unit is customer replaceable unit and is not a FRU. Note: The imaging unit contains: • Photoconductor unit • Developer units To remove only the photoconductor, remove the entire imaging unit, remove the developer units, place the original developer units in the new photoconductor, and re-install the imaging unit.
