Essailec Connections
This pinout drawing details the various pins
on the meter side of the connector. The
table below maps the pins to their
corresponding inputs and outputs in the
meter.
© 2007 Power Measurement. All rights reserved.
Voltage, current, power supply, I/O and communication connections are
made via the Essailec connector on the rear of the meter. Meters can be
ordered with multiple connector configurations.
Order Options B/C Circuit & Pinout Diagrams
9
