- Page 1 READ AND SAVE THESE INSTRUCTIONS P/N 35010042-D user manual...
-
Page 2: Dimensions/Legal
Dimensions/Legal All dimensions are in millimeters ™ ™ Dimensions/Legal... - Page 3 Martin™, Harman™ and all other trademarks in this document pertaining to services or products by Martin Professional or its affiliates and subsidiaries are registered as the property of Harman International Industries.
-
Page 4: Table Of Contents
Contents Dimensions/Legal ........................2 Contents ............................ 4 Safety information ........................5 Product overview ........................8 Product description ........................ 8 Features at a glance ......................8 Product details ........................9 Quick Start ..........................12 Setting up ..........................12 Making fog ........................... 12 Installation and Setting Up ...................... -
Page 5: Safety Information
If the machine or any cables connected to it are in any way damaged, defective, wet, or show signs of overheating, stop using the machine and contact Martin™ Service for assistance. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent. - Page 6 Do not spill fluid over or inside the machine. If fluid is spilled, disconnect AC power and clean with a damp cloth. If fluid is spilled onto electronic parts, take the machine out of service and contact Martin™ for advice. ...
- Page 7 If you have any questions about how to install, operate or service the fixture safely, please contact your Martin™ distributor (see www.martin.com/distributors for details) or call the Martin™ 24-hour service hotline on +45 8740 0000, or in the USA on 1-888-tech-180.
-
Page 8: Product Overview
Featuring a high efficiency heating block and accepting multiple weights of fluid, the JEM ZR series™ products can create anything from an ephemeral steam chase to a dense, long-lasting “whiteout”. -
Page 9: Product Details
P r o d u c t d e t a i l s Integral hanging ZR25™ bracket Fluid container Fluid pipe connection Integrated digital remote control DMX input Mains fuse and output Mains power Mains power switch connector If suspending overhead: Loop safety cable under hanging bracket and secure... - Page 10 ZR35™ Integral hanging bracket Fluid container Fluid pipe connection Integrated digital remote control Mains power DMX input switch and output Mains fuse Mains power connector If suspending overhead: Loop safety cable under hanging bracket and secure Fog output nozzle WARNING! High temperature vapor and surfaces Product overview...
- Page 11 ZR45™ Integral hanging bracket Fluid container Fluid pipe connection Integrated digital remote control Mains power DMX input switch and output Mains fuse Mains power connector If suspending overhead: Loop safety cable under hanging bracket and secure Fog output nozzle WARNING! High temperature vapor and surfaces...
-
Page 12: Quick Start
Locate the machine in a suitably large area with nothing in front of the fog output. Fill the fluid tank with an approved Martin™ fog fluid as shown on page 21. Connect the machine to a suitably rated power source. The power requirements... -
Page 13: Installation And Setting Up
“Safety information” on page 5. L o c a t i o n The JEM ZR series™ machines are designed to be located on the floor or may be suspended using the fitted hanging bracket. The machine can operate in any orientation from 45 degrees upwards to 45 degrees downwards. -
Page 14: Setting Up
S e t t i n g u p Fill the fluid tank with an approved Martin™ fog fluid as shown on page 21. If DMX control is being used, connect the machine to the DMX line (see page 19). -
Page 15: Control Settings
Control Settings O v e r v i e w The integrated digital remote control on the rear of the machine allows you to configure it using option menus. The integrated digital remote control may be removed from the unit and used as a handheld remote control by removing the two hand wheel bolts either side of the display. -
Page 16: Setting The Timer
If you want to temporarily change the fog density, do not press Enter. The fog setting will go back to its stored value next time the machine is powered up. This applies to all options. S e t t i n g t h e T i m e r Set the RUN TIME and OFF TIME values from the menu. -
Page 17: Priming The Machine After Fluid Out
Use the Up/Down buttons to select RECEIVE (slave unit) or SEND (master unit). Press the Enter button to store the link setting. The machine should be set to SEND only if it is running as a master. If running as a slave, stand-alone or DMX controlled it should be set to RECEIVE. If a machine set to SEND is connected to an active DMX system, the DMX will be corrupted causing flickering of lights and other strange symptoms. - Page 18 The factory settings are: option setting FOG LEVEL 50% TIMER ON 10 seconds TIMER OFF 20 seconds RUN MODE STANDBY 001 BACK LIGHT NORM LINK MODE RECEIVE PRIME NO TEMPERATURE* NORM *ZR45 Only Control Settings...
-
Page 19: Dmx Control
If the machine was set to CONTINUOUS, it will revert to this state. C o n n e c t i o n The JEM ZR series™ machine provides 5-pin XLR connectors on the rear of the machine for DMX connection. -
Page 20: Optional Plc Interface Control
(subject to the drive capability of the controlling system). Physical connection is via 3-pin and 4-pin male locking XLR. Please contact your Martin dealer for more detailed information on application and ordering. Optional PLC Interface Control... -
Page 21: Approved Fog Fluid Types
Approved Fog Fluid Types The JEM ZR series™ machines must only be used with the Martin™ fluids listed below. Martin™ supplies high quality fog fluids that are based on ultra-pure deionized water. No other fluid is suitable for use. P r o S m o k e S t u d i o F l u i d ( D X m i x ) In a studio or theatre environment, a lighter, faster dispersing fog is often preferred. -
Page 22: Temperature Menu
T e m p e r a t u r e M e n u The different fluid types listed require correct selection of the relevant temperature setting in the TEMPERATURE sub-menu of the SETTINGS menu. Select the required temperature and press Enter to store. The selected temperature setting will remain after power off and is indicated on the display whilst in standby (TEMP=NORM) and also shows during manual operation/DMX control (T=N). -
Page 23: Pro Clean Supreme Fluid
Using Pro Clean Supreme every 200 hours, or once a month (depending on usage), will prolong the life of the heat exchanger in Martin fog and haze machines. Connect Pro Clean Supreme fluid to the fogger or hazer, then allow the unit to heat. -
Page 24: Basic Service
EU model = 12.5 AT (slow-blow), 250V US model = 20 AT (slow-blow), 125V Replace fuse only with one of exactly the same size and rating. Contact Martin™ Service if the fuse blows repeatedly. To replace the internal fuse, disconnect the power cord from the supply, unscrew the screws holding the top cover of the unit and remove the cover. -
Page 25: Troubleshooting
Troubleshooting Problem Probable cause(s) Suggested remedy Machine not at operating Wait until HEAT message no temperature longer shown Machine will not produce fog FOG option set to 0 Increase setting when control panel set to Machine in timer mode and CONTINUOUS or fog button Increase setting TIMER ON set to 0... -
Page 26: Status Messages
SETTINGS menu CALIBRATION The machine has detected an error with its calibration ERROR settings and will not operate. Call Martin™ Service. SYSTEM The machine has detected an error in the temperature sensor ERROR and will not operate. Call Martin™ Service. -
Page 27: Technical Specifications
Technical Specifications P h y s i c a l ZR25 Length ..................485 mm (19.1 in.) Width ................... 335 mm (13.2 in.) Height .................... 242 mm (9.6 in.) Height with hanging bracket ............333mm (13.2 in.) Weight, dry ................... 11.2 kg (24.7 lb.) Weight, filled ................. - Page 28 DMX channels ...................... 1 DMX compliance ..........ANSI E1.11 - USITT DMX512-A RDM compliance ..............ANSI/ESTA E1.20 RDM C o n s t r u c t i o n Housing ..................Steel & aluminium Hanging bracket.......Integrated yoke with safety attachment point Color .......................
- Page 29 JEM™ i-Fog Fluid JEM™ Pro Steam Simulation (ZR45 only) JEM™ Pro Clean Supreme *Various sizes available – contact your dealer or see martin.com for details. Installation Hardware Half-coupler clamp ................P/N 91602005 G-clamp (vertical hanging suspension only) ........P/N 91602003 Quick trigger clamp (vertical hanging suspension only) ....
- Page 30 JEM ZR25™, EU ................. P/N 92215320 JEM ZR35™, US ................. P/N 92215350 JEM ZR35™, EU ................. P/N 92215340 JEM ZR45™, US ................. P/N 92215370 JEM ZR45™, EU ................. P/N 92215360 Specifications subject to change without notice. For the latest technical specifications, see www.martin.com Technical Specifications...
- Page 31 Parliament and of the Council of the European Union on WEEE (Waste Electrical and Electronic Equipment), as amended by Directive 2003/108/EC, where applicable. Help preserve the environment! Ensure that this product is recycled at the end of its life. Your supplier can give details of local arrangements for the disposal of Martin products.
- Page 32 • Olof Palmes Allé 18 • 8200 Aarhus N • Denmark Tel: +45 8740 0000 • Fax: +45 8740 0010...
