Sharp HT-M700H Service Manual page 94

HT-M700H
NO. PARTS CODE
[12] OTHER CIRCUITRY PARTS
CFW301
QCNWNA483SJZZ
CFW501
QCNWNA470SJZZ
CFW701
QCNWNA471SJZZ
CNP301
QCNCM004DAFZZ
CNP302
QCNCM004KAFZZ
CNP305
QCNWNA472SJZZ
CNP505
QCNCM999BAFZZ
CNP505
QCNWNA473SJZZ
CNP508
QCNCM004CAFZZ
CNP601
QCNWNA423SJZZ
CNP801
QCNCM004DAFZZ
CNP901
QCNCM004BAFZZ
CNP903
QCNCM004CAFZZ
CNP904
QCNCM004HAFZZ
CNW1A
QCNWNA441SJZZ
CNW2A
QCNWNA444SJZZ
CNW3A
QCNWNA443SJZZ
CNW6A
QCNWNA442SJZZ
CNW303A
QCNWNA426SJZZ
CNW504
QCNWNA446SJZZ
CNW505A
QCNWNA425SJZZ
CNW506
QCNWNA447SJZZ
CNW508
QCNWNA421SJZZ
CNW601
QCNWNA420SJZZ
CNW701
QCNWNA413SJZZ
CNW702
QCNWNA417SJZZ
CNW703
QCNWNA418SJZZ
CNW704
QCNWNA414SJZZ
CNW705
QCNWNA415SJZZ
CNW706
QCNWNA416SJZZ
CNW707
QCNWNA419SJZZ
CNW708
QCNCM004FAFZZ
CNW901
QCNWNA422SJZZ
F1
QFS-D332CAWNI
!
FFC1
QCNWNA445SJZZ
FR
VHHVSR808//-1
!
J1
QCNCMA064SJ03
J2
QTANAA009SJZZ
J3
QCNWM999PAFZZ
J4
QCNWM999CAFZZ
J5
QCNWM999DAFZZ
JJ1
QCNCWA055SJ24
JK501
QJAKMA002SJZZ
JP1A
QCNWM999LAFZZ
JP1B
QCNWM999MAFZZ
JP2A
QCNWM999DAFZZ
JP2B
QCNWMA0655J03
JP3A
QCNWM999NAFZZ
JP3B
QCNWM999JAFZZ
JP4A
QCNWM999HAFZZ
JP4B
QCNWM999BAFZZ
JP5
QCNWM999CAFZZ
JP6A
QCNWM999MAFZZ
JP6B
QCNWM999BAFZZ
JP7
QCNWM999GAFZZ
JR1
QCNWM999DAFZZ
JR2
QCNWM999CAFZZ
M601
RMOTV0409AFZZ
P1
QSOCJ0003SJZZ
P2
QSOCJ0002SJZZ
PJ1
QCNWMA061SJ02
!
RLY
RRLYD0004SJZZ
!
S501
QSOCZA001SJZZ
SO301
QTANAA007SJZZ
SO302
QTANAA008SJZZ
SW501
QSW-K0002SJZZ
SW601
QSW-B0002SJZZ
SW701
QSW-K0002SJZZ
SW702
QSW-K0002SJZZ
SW703
QSW-K0002SJZZ
SW705
QSW-K0002SJZZ
SW706
QSW-K0002SJZZ
SW707
QSW-K0002SJZZ
SW708
QSW-K0002SJZZ
SW709
QSW-ZA002SJZZ
SW801
QSW-K0002SJZZ
U14
VHPBFTX1001-1
U801
VHLGP1UD261-1
VFD701
VVK42-1002F-1
PRICE NEW PART
RANK MARK RANK
N
Connector Ass'y,1Pin
N
Connector Ass'y,1Pin
N
Connector Ass'y,1Pin
AD
Plug,4Pin
N
Plug,10Pin
N
Connector Ass'y,3Pin
AD
Plug,2Pin
N
Connector Ass'y 2/2Pin with JP6
AB
Plug,3Pin
N
Connector Ass'y,2Pin
AD
Plug,4Pin
AB
Plug,2Pin
AB
Plug,3Pin
N
Plug,8Pin
N
Connector Ass'y,11/11Pin with CNW1B
N
Connector Ass'y,3/3Pin with CNW2B
N
Connector Ass'y,13/13Pin with CNW3B
N
Connector Ass'y,12/12Pin with CNW6B
N
Connector Ass'y,4/4Pin with CNW303B
N
Connector Ass'y,3/3Pin with CNS504
N
Connector Ass'y,8/8Pin with CNW505B
N
Connector Ass'y,4/4Pin with CNS506
N
Connector Ass'y,3/3Pin with CNS508
N
Connector Ass'y,3/3Pin with CNS601
N
Connector Ass'y,10/10Pin with CNS701
N
Connector Ass'y,4/4Pin with CNS702
N
Connector Ass'y,4/4Pin with CNS703
N
Connector Ass'y,9/9Pin with CNS704
N
Connector Ass'y,8/8Pin with CNS705
N
Connector Ass'y,7/7Pin with CNS706
N
Connector Ass'y,3/3Pin with CNS707
AC
Plug,6Pin
N
Connector Ass'y,2/2Pin with CNS901
N
Fuse,T3.15A L 250V
N
Flat Cable,24Pin
N
Resistor
N
Plug,3Pin
N
Terminal,Speaker
N
Plug,13Pin
N
Plug,3Pin
N
Plug,4Pin
N
Socket,24Pin
AE
Jack,Headphones
N
Plug,11Pin
N
Plug,12Pin
N
Plug,4Pin
N
Plug,3Pin
N
Plug,13Pin
N
Plug,9Pin
N
Plug,8Pin
N
Plug,2Pin
N
Plug,3Pin
N
Plug,12Pin
N
Plug,2Pin
N
Plug,8Pin
N
Plug,4Pin
N
Plug,3Pin
AL
Door Motor
AG
Jack,AUX IN
AH
Jack,Video/S-Video
N
Plug,2Pin
AG
Relay
AE
Socket,SCART Out
N
Terminal,FM Antenna
N
Terminal,AM Antenna
AC
Switch,Key Type [OPEN/CLOSE]
AE
Switch,Lever Type [Door]
AC
Switch,Key Type [PLAY]
AC
Switch,Key Type [STOP]
AC
Switch,Key Type [DISC TRAY OPEN/CLOSE]
AC
Switch,Key Type [TUNER (BAND)]
AC
Switch,Key Type [FUNCTION]
AC
Switch,Key Type [SKIP UP]
AC
Switch,Key Type [SKIP DOWN]
AF
Jog Volume
AC
Switch,Key Type [ON/STAND-BY]
AK
Terminal,Audio Digital Output
AK
Remote Sensor,GP1UD261
N
FL Display
16
DESCRIPTION
