CHAPTER 5.
CIRCUIT DESCRIPTION

[1] Notes on schematic diagram

• Resistor:
To differentiate the units of resistors, such symbol as K and M are
used: the symbol K means 1000 ohm and the symbol M means
1000 kohm and the resistor without any symbol is ohm-type resis-
tor. Besides, the one with "Fusible" is a fuse type.
• Capacitor:
To indicate the unit of capacitor, a symbol P is used: this symbol P
means pico-farad and the unit of the capacitor without such a sym-
bol is microfarad. As to electrolytic capacitor, the expression
"capacitance/withstand voltage" is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
• Schematic diagram and Wiring Side of P.W.Board for this model
are subject to change for improvement without prior notice.

[2] Types of transistor and LED

FRONT
VIEW
E C B
(S)(G)(D)
(1)(2)(3)
2SA1015
2SA562
2SC380 O
2SC1815 GW
C2001 SG
CMT20N15
KRA107 M
KRC104 M
KRC107 M
KTA1266 GR
KTA1271 Y
KTC3199 GR
KTC3203 y
RHC1815 GR
RF640B
Service Manual
•
•
SW501
SW601
SW701
SW702
SW703
SW705
SW706
SW707
SW708
SW709
SW801
B
(3)
TOP
C
VIEW (2)
E
(1)
2N2904
2N2907
2N3904
2N3906
2N8050
2SC3326
5 – 1
The indicated voltage in each section is the one measured by Digi-
tal Multimeter between such a section and the chassis with no sig-
nal given.
1. In the tuner section,
indicates AM
indicates FM stereo
2. In the CD section, the CD is stopped.
Parts marked with " " (
maintaining the safety of the set. Be sure to replace these parts
with specified ones for maintaining the safety and performance of
the set.
REF NO. DESCRIPTION
OPEN/CLOSE
DOOR
PLAY
STOP
DISC TRAY OPEN/CLOSE
TUNER (BAND)
FUNCTION
NEXT
PREV
JOG VOLUME
ON/STAND-BY
TOP
VIEW
B C E
2SB1132 Q LPBB73VQ
) are important for
POSITION
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
FRONT
VIEW
