- Page 1 UOVISION Panoramic UV572 12MP HD Wide Angle Scouting Camera User’s Manual...
-
Page 2: Quick Start
www.uovisioneurope.com Quick Start 1. Load 12pcs of new 1.5V AA size batteriees or connect 6V external power supply. If external power supply connected, the batteries can remain inside the camera 2. Insert the SD card (32GB or smaller) Please note if you don’t insert the SD card, the camera will not work. - Page 3 www.uovisioneurope.com review the image and then press the “DEL” button to delete the image. Key Notes a. “MENU”: enter the program menu in preview mode. b. “▲”“▼”“◄”“►”: for parameter settings as described in the user’s manual. “▲” is the shortcut to choose “Video”, while “▼” for the “Photo”. c.
-
Page 4: General Description
1 Instruction Instruction 1.1 General Description Congratulations on your purchase of UV572 panoramic infrared scouting camera. UV572 is a powerful and reliable performance Panoramic game camera. Features: 12MP panoramic hunting camera 3 motion sensors cover 100°detection Wide Angle lens: Field of view of 130° 1080P/720P day/night HD video with sound 1 second trigger speed Three camera mode: photo, video, photo+video... - Page 5 1 Instruction Display Screen Lock Hole Operation Panel Power Switch Battery Depot Fig 2: Operation Interface Mounting Holes DC In SD-card Slot Bottom Screw Fig 3: Bottom view Page 2...
- Page 6 1 Instruction Key Notes： a. “MENU”: enter the program menu in preview mode. b. “▲”“▼”“◄”“►”: for parameter settings as described in the user’s manual. “▲”is the shortcut to choose “Video”, while “▼”for the “Photo”. c. “OK”: save parameter settings. d. “ ”: exchange between playback and preview.
-
Page 7: Power Supply
2 Quick Introductions 2. Quick Start Guide Power Supply To supply power for the camera, 12 size AA batteries are needed. The following batteries with 1.5V output can be used: 1. High-density and high-performance alkaline batteries (Recommended) 2. Rechargeable alkaline batteries 3. -
Page 8: Power Off
2 Quick Introductions 2. The height from the ground for placing the camera should vary with the object size appropriately. In general, four to six feet is preferred. Slide the power switch to the ON position to power on the camera and enter into the ON mode. -
Page 9: Advanced Operations
3 Advanced Operations 3 Advanced Operations To view the camera settings, switch the camera to SETUP mode and press MENU, the main menu and the default settings are under below charts: Setting Items Description Choose Photo, Video, or Photo+Video. The default setting is Photo. If you Camera Mode choose Photo+Video, the camera will take a 5MP photo and a 10s video. - Page 10 3 Advanced Operations Time lapse function defines the camera records/captures automatically every preset time period (5seconds~8hours), Time Lapse which doesn’t work if it is set to Off. The default setting is Off. Start-stop “On” means that the camera works only during that preset time; Start-stop “Off”...
-
Page 11: Viewing Photo Or Video
3 Advanced Operations Restore all customer settings to default Default Set values. Press LEFT or RIGHT and UP or DOWN to select the desired options，And then press OK to save. 4 Playback 4.1. Viewing Photo or Video a) Switch to SETUP mode; b) Press to view the latest picture (or video) in LCD screen on camera;... -
Page 12: Appendixⅰ : Technical Specifications
AppendixⅠ: Technical Specifications AppendixⅠ : Technical Specifications Picture Resolution 12MP, 8MP, 5MP, 3MP Wide Angle Lens FOV(Field of View)=130° IR-Flash 50% = 6m, 100% = 12m Display Screen 3.0” 16:9 LCD Memory Card Up to 32GB Video Resolution HD: 1080P, 720P, WVGA PIR Sensor 100°detection angle Trigger Time... -
Page 13: Appendixⅱ : Parts List
Appendix Ⅱ: Parts List AppendixⅡ : Parts List Part Name Quantity Digital Camera Belt User Manual WARRANTY The camera manufacturer provides 12 months of warranty service for this product against manufacturing defects or malfunctions. If your camera fails to function under normal use within 1 year, the camera manufacturer will repair or replace the camera at no charge.
