Gravely Compact Pro 34 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Compact Pro 34
Owner/Operator Manual
Manuel Du Propriétaire/Utilisateur
ENGLISH
FRANÇAIS
Model
991088 Compact Pro 34
04276200A 11/10
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact Pro 34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gravely Compact Pro 34

Summary of Contents for Gravely Compact Pro 34

  • Page 1 Compact Pro 34 Owner/Operator Manual Manuel Du Propriétaire/Utilisateur Model 991088 Compact Pro 34 ENGLISH 04276200A 11/10 FRANÇAIS Printed in USA...

  • Page 2: Table Of Contents

    English may be obtained from completely read your manuals. The contents your Dealer. Visit your dealer or will provide you with an understanding of www.gravely.com for a list of safety instructions and controls during normal languages available for your operation and maintenance.

  • Page 3: Product Registration

    PTO is engaged (On). See Safety Interlock System on PRODUCT REGISTRATION page 12. The Gravely dealer must register the product 3. Fill out Original Purchaser Registration at the time of purchase. Registering the Card and return the card to Gravely.

  • Page 4: Safety

    SAFETY WARNING: This cutting machine is DANGER: IMMINENTLY capable of amputating hands and HAZARDOUS SITUATION! If not feet and throwing objects. Failure to avoided, WILL RESULT in death or observe the safety instructions in serious injury. the manuals and on decals could result in serious injury or death.

  • Page 5: Safety Decals And Locations

    SAFETY DECALS AND LOCATIONS ALWAYS replace missing or damaged Safety Decals. Refer to Figure 2 for Safety Decal locations. Never fill tank when engine is running, hot or unit is indoors. Never overfill fuel tank. Replace fuel cap securely and clean up spilled fuel.

  • Page 6: Emission Control System

    • Never allow operation by untrained 5. ROTATING PARTS persons. AVOID INJURY. Stay clear of rotating parts. 2. DANGER! ROTATING PARTS Always keep feet and hands away OF3450 from rotating parts. 6. DANGER! OL3030 AVOID INJURY. Stay clear of Always stand clear of discharge rotating parts.
  • Page 7 ALWAYS remove key and/or wire from spark DO NOT wear loose clothing or jewelry and plug before assembly. Unintentional engine tie back hair that may get caught in rotating start up can cause death or serious injury. parts. Complete a walk around inspection of unit Wear adequate outer garments.
  • Page 8 Use care when approaching blind corners, Disengage PTO when attachment is not in shrubs, trees or other objects that may use. ALWAYS turn off power to attachment obscure vision. when travelling, crossing driveways, etc. Dust, smoke, fog, etc. can reduce vision and Operation on slopes may lead to loss of cause an accident.
  • Page 9 Keep unit free of debris. Clean up oil or fuel Explosive Gases from battery can cause spills. death or serious injury. Poisonous battery fluid contains sulfuric acid and its contact with This product is equipped with an internal skin, eyes or clothing can cause severe combustion type engine.

  • Page 10: Assembly

    ASSEMBLY WARNING: AVOID INJURY. Read WARNING: FAILURE OF and understand entire Safety INTERLOCK together with improper section before proceeding. operation can result in severe personal injury. UNIT ASSEMBLY 11. Lubrication - Lubricate all fittings per Package Contents: maintenance label under seat and check hydrostat oil level (See Lubricate Unit on Unit, Mower Deck and Literature Pack page 21).

  • Page 11: Controls And Features

    CONTROLS AND FEATURES Figure 4 OF3741 1. Fuel Tanks and Caps 2. Wing Knob 3. Steering Levers 4. Hydraulic Oil Reservoir 5. Ignition Switch 6. Hour Meter 7. Throttle Lever 8. Choke Control 9. Power Take Off (PTO) Switch 10. Battery 11.

  • Page 12: Operation

    Gravely dealer for repairs. D. To turn right, pull the right back or NOTE: When the parking brake is engaged, push the left steering control lever the steering levers are locked in neutral.
  • Page 13 Choke Control Cutting Height: Put cutting height adjustment pin in desired Push the choke lever hole. Push mower lift pedal forward and hold forward to start a cold it while pushing down on the lift lock. Slowly engine. Pull the choke lower mower lift pedal until deck lift contacts lever to the rear when the cutting height adjustment pin.

  • Page 14: Filling Fuel Tank

    Service Alert (Chg Oil, Chg H Oil & Filter, IMPORTANT: DO NOT OVERFILL! This equipment and/or its engine may include SVC Airfilter): reminds operators of the evaporative emissions control system maintenance interval for changing the engine components, required to meet EPA and/or oil, changing the hydraulic oil and filter and CARB regulations, that will only function servicing the air filter.
  • Page 15 Fuel Stabilizer STARTING AND SHUT OFF Gasoline left in the fuel system for extended CAUTION: Read entire periods without a stabilizer will deteriorate, Owner/Operator Manual, Clutch resulting in gum deposits in the system. Manual, and Engine Manual first. These deposits can damage the carburetor DO NOT attempt to start engine at and the fuel hoses, filter and tank.
  • Page 16 IMPORTANT: Never engage the PTO if the mower is plugged with grass or other material. This may cause damage to the electric clutch. 6. Move throttle control to fast. 7. Move the steering levers forward to obtain a slow ground speed. 8.

  • Page 17: Maintenance Schedule

    MAINTENANCE SCHEDULE More frequent service may be required due to WARNING: AVOID INJURY. Read working conditions (heavy loads, high and understand entire Safety ambient temperatures, dusty conditions, or section before proceeding. airborne debris). See the maintenance instructions in the Proper maintenance can prolong the life of Engine Manual for additional information.

  • Page 18: Service And Adjustments

    Gravely Dealers will provide any service which may be required to keep your unit operating at peak efficiency. Should engine service be required, it can be obtained from a Gravely Dealer or the engine manufacturer’s authorized service center. WARNING: AVOID INJURY. Read and understand entire Safety section before proceeding.

  • Page 19: Mower Blades

    Fluid in Extended Performance 15W50 Synthetic Oil hydraulic system can penetrate skin or equivalent for best component life (Gravely and result in serious injury or death. p/n 00057100). Be sure to stop the engine before NOTE: When changing the oil, only about 1.5...
  • Page 20 Sharpen the Mower Blades 3. Check mower blade balance. Slide mower blade on an unthreaded CAUTION: DO NOT sharpen mower bolt. A balanced blade should remain in blades while on unit. An unbalanced a horizontal position. If either end of mower blade will cause excessive mower blade moves downward, sharpen vibration and eventual damage to...
  • Page 21 4. Remove hold down and remove battery. Jump-Starting Gravely does not recommend jump-starting Replace Battery your unit. Jump-starting can damage engine 1. Replace battery and secure with battery and electrical system components. See your hold down. engine manual for more detailed information.

  • Page 22: Adjusting The Unit To Track Straight

    NOTE: The right and left hydraulic pumps are 5. Loosen tie rod jam nut and turn tie rod adjusted the same way. until steering levers are aligned. 7. If a wheel moves, adjust the return to 6. Tighten jam nut on tie rod, tighten brake neutral mechanism on the hydraulic interlock and tighten damper locknut.

  • Page 23: Adjusting The Parking Brake

    2. Remove the spacer, handle, and eccentric spacer from the steering lever. NOTE: Position the right and left handles at the same height position. 3. Install the spacer, handle, and eccentric spacer in the appropriate height position. Do not tighten the nut holding the eccentric spacer.
  • Page 24 There should be 3/8 in. – 1/2 in. (9.5 – PTO BELT 15.9 mm) between brake paddle and tire. WARNING: MOVING PARTS can cut or amputate body parts. 3. Tires – Adjust tire pressure for front tires; ALWAYS wait for moving parts to 20-25 PSI (138-172 kPa), rear tires;...
  • Page 25 Remove PTO Belt Replacing the Hydro Pump Belt (Figure 16) (Figure 17) 1. Properly stop and park unit (See CAUTION: Use care when Operation on page 12). releasing idler spring tension. Keep 2. Remove the PTO belt from the mower body parts well away from idlers clutch sheave (See Remove PTO Belt when performing this operation.
  • Page 26 MOWER DECKS (Figure 18) Removing the Mower Deck 1. Remove PTO belt (See Remove PTO Belt on page 25). WARNING: AVOID INJURY. Mower lift arms and mower lift pedal could cause severe injury if they are not locked before removing the mower deck.
  • Page 27 Leveling the Mower Deck Blade Side-to-Side Level These adjustments should be made on a level surface with the tires inflated to the correct air pressure. Check Blade Level and Pitch 1. Raise mower deck to a 3 in. (7.62 cm) cutting height.

  • Page 28: Storage

    Keep all nuts, bolts and screws properly To treat the fuel system for storage: tightened and know unit is in safe working 1. Add fuel stabilizer (Gravely p/n condition. 00592900) according to manufacturers’ Store unit in a cool, dry protected area.

  • Page 29: Accessories

    ACCESSORIES SERVICE PARTS Part No. Description Part No. Qty Description 78804300 Grass Catcher Kit 01554800 Battery 78804400 Leaf Collector Kit 21548200 Air Filter 79202300 Hitch Kit 21535800 Engine Oil Filter - Kawasaki 79203300 Bahia Baffle Kit 00669300 Hydraulic Oil Filter 79203400 Mulch Kit 21536100 Spark Plug - Kawasaki...

  • Page 30: Specifications

    SPECIFICATIONS Model Number 991088 Model Compact Pro 34 Engine Engine Kawasaki Engine Model Number FX481V Governed RPM (May be different from 3600 +/- 100 maximum RPM) Liquid or Air Cooled Cooling System Capacity Speed Forward Maximum – mph (km/h) 9 (14.5) Reverse Maximum –...
  • Page 31 Genuine Ariens or Gravely brand service parts and accessories are warranted to be free from defects in material and workmanship for a period of 90 days after the date of purchase. An authorized Ariens or Gravely dealer will repair or replace any such part or accessory free of charge, except for labor, during that period.
  • Page 32 Engines and engine accessories are covered only by the engine manufacturer’s warranty and are not covered by this warranty. • Parts that are not genuine Ariens or Gravely service parts are not covered by this warranty. • The following maintenance, service and replacement items are not covered by this warranty unless...

  • Page 33: Warranty Statement

    • You are responsible for presenting your small off-road equipment to an authorized Ariens, Gravely, or Parker service representative as soon as the problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
  • Page 34 (4.) Repair or replacement of any warranted part under the warranty provisions of this article must be performed at no charge to the owner at an authorized Ariens, Gravely, or Parker service representative. (5.) Notwithstanding the provisions of subsection (4) above, warranty services or repairs must be provided at authorized Ariens, Gravely, or Parker service representatives that are franchised to service the subject small off-road equipment.
