- Page 2 ZOTAC ZBOX nano XS ZOTAC ZBOX nano XS User’s Manual No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ZOTAC.
-
Page 3: Table Of Contents
Setting up the ZOTAC ZBOX nano XS ------------------------------------------------------ 13 Positioning the ZOTAC ZBOX nano XS ---------------------------------------------------- 14 Mounting the ZOTAC ZBOX nano XS to an LCD monitor --------------------------- 14 Installing drivers and software --------------------------------------------------------------- 16 Installing an operating system -------------------------------------------------------------- 16... -
Page 4: Product Specifications
ZOTAC ZBOX nano XS Product specifications Processor • Intel Core i3-4030U Processor (dual core, 1.9GHz) Product Dimensions • 106mm x 106mm x 45mm Onboard graphics • Intel HD Graphics 4400 • HDMI 1.4a (max resolutions: 4096×2160 @24Hz) • Mini DP 1.2 (max resolutions: 3840x2160 @30Hz) Memory support •... -
Page 5: Safety Information
ZOTAC ZBOX nano XS Safety information Your ZOTAC ZBOX nano XS is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. -
Page 6: Welcome
ZOTAC ZBOX nano XS Welcome Congratulations on your purchase of the ZOTAC ZBOX nano XS mini-PC. The following illustration displays the package contents of your new ZOTAC ZBOX nano XS. Please contact your retailer If any of the below items are damaged or missed. -
Page 7: Getting To Know Your Zotac Zbox Nano Xs
It also supports SPDIF output with the headphone/SPDIF adapter included in the package. The optical SPDIF output enables connecting the ZBOX nano XS to digital audio receivers and speakers for crystal clear digital audio and surround sound from compatible soundtracks. -
Page 8: Rear View
ZOTAC ZBOX nano XS Rear view Refer to the diagram below to identify the components on this side of the system. 1. HDMI output The HDMI (High Definition Multimedia Interface) output supports Full HD 1080p displays such as an HDTV or monitor. -
Page 9: How To Disable The Ring Led Indicator
ZOTAC ZBOX nano XS How to disable the ring LED indicator Turn on the ZBOX nano XS mini-PC, then press <Delete> to enter the BIOS SETUP UTILITY. Use the arrow keys to navigate to the Power menu and select Logo indicator. -
Page 10: Customizing The Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Customizing the ZOTAC ZBOX nano XS Please follow the instructions below to remove the cover of the ZOTAC ZBOX nano XS before customizing. 1. Loosen the 4 screws securing the bottom cover into place. 2. Gently remove the cover. -
Page 11: Installing A Memory Module
ZOTAC ZBOX nano XS Installing a memory module 1. Locate the SO-DIMM memory slot and insert a SO-DIMM memory module into the slot at a 45 degree angle. 2. Gently press down on the memory module until it locks into place by the arms... -
Page 12: Installing An Msata
ZOTAC ZBOX nano XS Installing an mSATA 1. Insert the mSATA into the slot and gently slide into the connector. 2. Gently press down on the mSATA module until it locks into place. -
Page 13: Connecting A Spdif Cable
ZOTAC ZBOX nano XS Connecting a SPDIF cable 1. Connect the SPDIF cable to the headphone/SPDIF adapter correctly. 2. Locate the front panel and connect the headphone/SPDIF adapter to the headphone/SPDIF jack. -
Page 14: Setting Up The Zotac Zbox Nano Xs
5. Connecting the Wi-Fi antenna Connect the Wi-Fi antenna to the Wi-Fi antenna connector. 6. Connecting the power adapter and turning on the ZBOX nano XS Connect the supplied AC adapter to the DC IN jack on the system rear panel and... -
Page 15: Positioning The Zotac Zbox Nano Xs
ZOTAC ZBOX nano XS Positioning the ZOTAC ZBOX nano XS • Do not cover or block the ventilation holes on ZOTAC ZBOX nano XS. To ensure proper operation and reliability, leave aproximately 4 inches (10 cm) of spacing in front of the ventilation holes. - Page 16 ZOTAC ZBOX nano XS Connect the ZOTAC ZBOX nano XS to your LCD monitor with an HDMI cable.
-
Page 17: Installing Drivers And Software
Installing system drivers Before you can use the full features of the ZOTAC ZBOX nano XS, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ZBOX nano XS driver DVD and USB flash drive: •... -
Page 18: Using Your Zotac Zbox Nano Xs
Select the driver you want to install. The driver installer should launch. Follow the onscreen instructions to install the drivers. Restart the system. Using your ZOTAC ZBOX nano XS Configuring wireless connection Please follow the instructions below to connect to a wireless network: Double-click the crossed wireless network icon (pic) in the notification area. -
Page 19: Using A Dynamic Ip (Pppoe Connection)
Note: Contact your internet Service Provider (ISP) if you have problems connecting to the network. Configuring audio output via an HDMI device Follow the steps below to enable audio output via HDMI when connecting the ZOTAC ZBOX nano to a TV or receiver via HDMI. Access the Sound settings via the system Control Panel. - Page 20 ZOTAC ZBOX nano XS...
- Page 21 ZOTAC ZBOX nano XS 291-MB235-00...
