USER MANUAL
CSW-VG440A
Table of Contents
C a b l e a n d C o n n e c t i v i t y C o m p a n y
Advertisement
Related Manuals for Comprehensive CSW-VG440A
Summary of Contents for Comprehensive CSW-VG440A
- Page 1 USER MANUAL CSW-VG440A Table of Contents 1.0 Introduction................1 2.0 Specifications...............1 3.0 Package Contents..............2 4.0 Panel Descriptions...............2 5.0 Connection and Operation..........3 C a b l e a n d C o n n e c t i v i t y C o m p a n y...
-
Page 2: Specifications
VGA S WITCH S PLITTER 4 4 ! matrix" VGA SWITCH SPLITTER Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1.0 INTRODUCTION The VGA Switch Splitter routes high quality VGA video and stereo audio from any of four VGA and audio sources to any of four VGA displays and audio receivers. -
Page 3: Panel Descriptions
VGA SWITCH SPLITTER 4×4 （matrix） 0 ℃ to +70℃ Operating Temperature Operating Humidity 10% to 85 % RH (no condensation) Storage Temperature -10℃ to +80℃ Storage Humidity 5% to 90 % RH (no condensation) Power Requirement External Power Supply 5V DC@2A Power Consumption(max) Regulatory Approvals Converter Unit... - Page 4 VGA SWITCH SPLITTER 4×4 （matrix） 1) Connect all source devices to the video and audio inputs on the VGA Switch Splitter 2) Connect the VGA displays and audio receivers to the outputs on the VGA Switch Splitter. 3) Connect the 5VDC power supply to the VGA Switch Splitter. 4) Turn on the Power Note: 1) Please make sure to cut off the power before insert IR Extender into the unit.
-
Page 5: Conection Diagram
VGA SWITCH SPLITTER 4×4 （matrix） will appear. “wrong The input instruction should be right, or you will be rejected with the instruction” If the input or output that you chose is not connected to devices or not in “ineffective power-on mode, instruction”... - Page 6 VGA S WITCH S PLITTER 4 4 ! matrix" 55 Ruta Ct. South Hackensack, NJ 07606 Toll Free: 800 526-0242 Email: sales@comprehensivecable.com customerservice@comprehensivecable.com www.comprehensivecable.com...
