  • Page 1 Install & User Guide TP-2010-IUG-V02...
  • Page 2 Please note that the content in this guide is protected under copyright law. Although every care has been taken in the compilation of this guide, Promethean Limited accepts no responsibility for errors or omissions, or for damages resulting from the...

  • Page 3: Table Of Contents

    Contents Safety Information Box Contents Installation Interfaces Setup Controls Operation Touch Cleaning Troubleshooting Compliance Statement...

  • Page 4: Safety Information

    • To avoid electric shock, avoid handling the power cable during electrical or thunder storms. • Unplug the ActivPanel during a lightning storm or when it will not be used for a long period of time. This will protect the device from damage due to power surges.

  • Page 5: Environmental Considerations

    • Do not insert hands or any other objects into the ventilation holes or signal joints of the ActivPanel. • Never place, spill or pour any liquid on any part of the ActivPanel. The device could short circuit causing a fire or electric shock.

  • Page 6: Box Contents

    Box Contents AP-STY 603-2001-9878_A 603-0001-9878_X1 Q-572-CTR-01 DR-7152001 603-0001-9879_X1 890103G00-937-G DR-6281013 AP-PEN-2 603-1001-9878_A 603-0001-9877_X1 TP2010 Carton Dimensions 70” • 1856mm x 307mm x 1150mm 80” • 2068mm x 307mm x 1268mm ActivPanel Installation Guide...

  • Page 7: Installation

    Installation ActivPanel Installation Guide...
  • Page 8 Installation ActivPanel Installation Guide...
  • Page 9 Installation 150mm (6”) Use applicable device to detect hidden pipework in the wall ActivPanel Installation Guide...
  • Page 10 1630.0mm (64.2in) 990.0mm (39.0in) 1230.0mm (48.4in) 230.0mm (9.1in) 400.0mm (15.8in) 122.0mm (4.8in) 80” 1860.0mm (73.2in) 1128.0mm (44.1in) 1230.0mm (48.4in) 212.0mm (8.3in) 800.0mm (31.5in) 136.5mm (5.4in) Note: If using a Mini PC, Install applicable device before installing the ActivPanel. See relevent device instructions. support.prometheanworld.com prometheankb.com ActivPanel Installation Guide...
  • Page 11 Installation 65kg 143lbs 70” 80kg 176.4lbs 80 ” Mounting the ActivPanel onto the APTASBB400-70 OR APTASBB400-90 (sold separately) ActivPanel Installation Guide...
  • Page 12 Installation support.prometheanworld.com prometheankb.com www.prometheanworld.com ActivPanel Installation Guide...

  • Page 13: Interfaces

    Interfaces ActivPanel Installation Guide...
  • Page 14 Audio Out USB2.0 (OPS PC) USB Touch 1 USB Touch 2 USB3.0 HDMI (Touch 2) USB2.0 x 2 SPDIF SD Card HDMI (Touch 1) VGA In (Touch 1) RS232 VGA Out Component Input Audio In Audio In ActivPanel Installation Guide...

  • Page 15: Setup

    Set Up Before You Start Install the latest firmware from support.prometheanworld.com/product/activdriver Connections The diagrams in this section show how to connect the ActivPanel to external devices. HDMI & USB-Touch HDMI Cable USB Cable ActivPanel Installation Guide...
  • Page 16 Set Up Connections HDMI HDMI HDMI DVI-HDMI DVI-HDMI AUDIO Ø 3.5 mm AUDIO1 AUDIO2 ActivPanel Installation Guide...
  • Page 17 Set Up Connections AUDIO Ø 3.5 mm AUDIO Amplifier (HDMI Cable) HDMI HDMI1 HDMI OUT HDMI OUT HDMI(ARC) HDMI HDMI HDMI HDMI ActivPanel Installation Guide...
  • Page 18 Set Up Connections SPDIF SPDIF Cable SPDIF SPDIF Audio Ø 3.5 mm AUDIO1 AUDIO2 ActivPanel Installation Guide...
  • Page 19 Component Video Cable L-AUDIO-R Y/VIDEO Component Video COMPONENT OUT AV Cable AUDIO-L (W) VIDEO (Y) AUDIO-R (R) L-AUDIO-R Y/VIDEO Inserting Batteries Remove the battery cover. Insert two AAA batteries into the remote control. Replace the battery cover. ActivPanel Installation Guide...
  • Page 20 Set Up Switching On 70” 80” P.MODE SOUND ZOOM SLEEP MENU BACK SPEED PREV NEXT PLAY STOP PAGE HDMI MEDIA MENU EXIT ActivPanel Installation Guide BLANK SOURCE OPS PC...

  • Page 21: Controls

    Controls You can control the ActivPanel in two ways: • With the buttons on the control panel on the side of the device. • With the buttons on the remote control. You can access basic controls, as well as On-Screen Display (OSD) menus for adjusting audio and visual settings.

  • Page 22: Remote Control

    Lock all panel functions PC POWER Freeze the screen Increase/decrease volume Blank the screen Open OSD menu Toggle between HDMI sources FREEZE LOCK Toggle between VGA sources Select the desired picture mode Select the desired sound mode Power/Standby ON/OFF ActivPanel Installation Guide...

  • Page 23: Operation

    SLEEP BACK SPEED PREV NEXT PC POWER PLAY STOP PAGE Touch Open OSD Select Input Power /Standby Freeze Volume Up Volume Down BLANK SOURCE LockOn/Off Menu Source ActivPanel Installation Guide HDMI MEDIA FREEZE LOCK OPS PC MENU EXIT FREEZE LOCK...
  • Page 24 Saturation Color Temperature Standard Zoom Mode Full Image Noise Reduction Middle Move Switch /Menu:Exit OK/Source:Select Picture Contrast FREEZE LOCK Brightness Sharpness Saturation Color Temperature Standard Zoom Mode Full Image Noise Reduction Middle Move Switch /Menu:Exit OK/Source:Select MENU ActivPanel Installation Guide...
  • Page 25 Move to left/right to increase the left- speaker/right- and right speaker speaker volume Low pitch Adjust the bass The bigger value (0-100), the higher bass High pitch Adjust the treble The bigger value (0-100), the higher treble SPDIF output Digital output Off/RAW/PCM ActivPanel Installation Guide...
  • Page 26 NEXT PLAY STOP PAGE HDMI MEDIA MENU EXIT BLANK SOURCE OPS PC PC POWER P.MODE SOUND ZOOM SLEEP BACK SPEED PREV NEXT PLAY STOP PAGE HDMI MEDIA MENU EXIT FREEZE LOCK BLANK SOURCE OPS PC ActivPanel Installation Guide PC POWER...
  • Page 27 STOP PAGE HDMI MEDIA MENU EXIT FREEZE LOCK BLANK SOURCE OPS PC PC POWER P.MODE SOUND ZOOM SLEEP BACK SPEED PREV NEXT PLAY STOP PAGE HDMI MEDIA FREEZE LOCK MENU EXIT BLANK SOURCE OPS PC ActivPanel Installation Guide PC POWER...
  • Page 28 Operation Touch to go to Settings Menu Adjust Brightness Adjust Sound Change the output Source ActivPanel Installation Guide...

  • Page 29: Touch

    Touch Moving Objects Rotating Objects Enlarging Objects ActivPanel Installation Guide...

  • Page 30: Cleaning

    Cleaning Unplug the power cable from the socket before cleaning the ActivPanel. Do not use volatile solvents (such as alcohol, rosin, and toluene) to clean the ActivPanel. These types of chemicals might damage the housing. Cleaning the Bezel And Remote Control Use a 100% cotton cloth or micro-fiber cloth for cleaning.

  • Page 31: Troubleshooting

    Troubleshooting If your ActivPanel is not operating correctly, please check the following table before contacting Technical Support. Problems Solutions No sound • Try increasing the volume of the speaker. • Check that the ActivPanel is not turned off. • Check the ActivPanel volume level.

  • Page 32: Compliance Statement

    This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Promethean hereby declare that the equipment is in compliance with the Low Voltage Directive 2006/95/ EC and the Electromagnetic Compatibility Directive 2004/108/EC.
