Prestige APS-20B Installation Instructions Manual

Vehicle alarm system with auxiliary output

Advertisement

Quick Links

Model APS-20B
Installation Manual
Vehicle Alarm System
With Auxiliary Output
Installation Instructions
This Unit Is Intended For Installation In Vehicles With
12 Volt Negative Ground Electrical Systems Only

Kit Contents:

APS-20B Control Module
(2) - Three Button Transmitters
3 Channel Code Learning Receiver
(1) - Multi Pin Input/Output Harness
(1) - Two Pin Door Lock Harness
(1) - Two Pin LED Indicator
(1) - Two Pin Valet / Programming Switch
Multi-tone Siren
(1) - Installation Manual
(1) - Operator's Manual
(1) - Limited Warranty
(2) - Window Decals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige APS-20B and is the answer not in the manual?

Questions and answers

Summary of Contents for Prestige Prestige APS-20B

  • Page 1 Model APS-20B Installation Manual Vehicle Alarm System With Auxiliary Output Installation Instructions This Unit Is Intended For Installation In Vehicles With 12 Volt Negative Ground Electrical Systems Only Kit Contents: APS-20B Control Module (2) - Three Button Transmitters 3 Channel Code Learning Receiver (1) - Multi Pin Input/Output Harness (1) - Two Pin Door Lock Harness (1) - Two Pin LED Indicator...
  • Page 2 The APS-20B Vehicle Alarm System is designed to provide a basic deterrent to vehicle theft and a convenient electronic means to gain access to the vehicle by providing RF remote control over the vehicle's power door lock system. The unit also includes outputs to control the vehicle's parking lights and an additional auxiliary output designed to allow for control over an optional device such as a power trunk release or engine starting device.
  • Page 3 open), it will supply a ground to the input wire thus activating the alarm. Mount the switch in the hood or trunk locations away from water drain paths. If necessary, the included bracket may be used to move the switch away from rain gutters or allow mounting to the firewall behind the hood seal.
  • Page 4 DARK GREEN Wire: Negative (-) Hood/Trunk Trigger Input Wire This input is designed to connect to a grounding hood, trunk, or rear hatch pin-switch, to allow the system to trigger should those entry points be violated. To provide protection for the hood, the Dark Green negative hood/trunk trigger wire should connect to the existing factory hood pin-switch (if one exists) or to a suitable aftermarket installed hood pin-switch.
  • Page 5 In these applications, the AS-9159 Door Lock Interface (or equivalent 30 Amp. automotive type relays) must be used. Refer to the Audiovox Door Lock Wiring Supplement for proper connection to these types of circuits. PLUG-IN CONNECTIONS AND COMPLETING THE INSTALLATION: Now that all the other components have been installed and most of the main connections completed, it is time to finish connecting the remaining plug-in components and completing the installation.
  • Page 6 VALET/PROGRAM/MANUAL OVERRIDE SWITCH 2-PIN Blue Plug w/2 Wires; Black and Gray The Black & Gray wires in the 2-PIN blue connector are the ground supply and Valet/Program input of the APS20B unit. When the Gray wire is grounded, under certain conditions, the unit will enter the valet mode. When the Gray wire is sequentially grounded under other conditions, the unit will enter the various program modes.
  • Page 7 mode and toggle the Valet/Program/Manual Override Switch 3 times in order to adjust the Fourth programmable feature. The system would respond with 1 Chirp and the LED would begin to flash 4 Flashes, pause and repeat. This has told you that the system is ready for you to adjust the Fourth programmable feature, and that it is currently programmed for Chirps ON.
  • Page 8: Wiring Diagram

    © 2003 Audiovox Electronics Corporation 128-6187B...
