TRANSMITTER PROGRAMMING GUIDE
The transmitters included with the system have been pre-programmed
at the factory, with each button pre-assigned to control a specific
function of the system. Although the system in the vehicle has either
a 2 or 3 channel receiver, depending on the model, the transmitters
included with the system are capable of transmitting 3 distinct signals.
This allows you to program each transmitter to more than one vehicle
in two car families, and also allows you to change which button(s)
control certain functions of the system.
( Example: Transmitter channel 3 can be programmed to activate
Receiver channel 2. ) Refer to the chart below for access to each of the
transmitter channels, and for the standard factory button assignments.
TRANSMITTER
CHANNEL BUTTONS
1
ARM
DISARM
2
OPTION
3
ARM
DISARM
& OPTION
Some of the more common accessories for these additional channels
are;
*AS 9154
*AS 9075
*AS 9153
*AS 9256
** Only Available With Some Systems
Released 9-24-99
Rev A: References to the APS-33, 3-6-02.
Model : APS-OE2B
SYSTEM RECEIVER
CHANNEL
FUNCTION
1
Remote Arm/Disarm
& or **Remote Lock/Unlock
**Remote Emergency Panic
2
* Pulsed Output for Accessories
3
* Switched Output for Accessories
* Second Vehicle Control
Remote Garage Door Interface
Remote car starter
Remote window roll up
Remote trunk release relay
128-5544A
1 OF 4
