Chapter 2 Configuring LDK24 System via Console

This chapter describes how to configure LDK24 ADSL Router System in typical Gateway
configurations by Console.

2.1 Introduction

This chapter describes how to configure the
configurations:

• Bridged configurations:

• Ethernet - RFC1483/RFC2684 bridged

• Routed configurations:
• Ethernet - IPoA routed
• Ethernet - RFC1483/RFC2684 routed
• Ethernet - PPP routed.
• Ethernet - PPPoE Client over RFC1483/RFC2684.
2.2 Bridged configurations
All of the configurations in this section use ISOS Bridge module to bridge between Ethernet and
an ATM protocol. These configurations are bridging at Layer 2.
2.2.1 Ethernet - RFC1483/RFC2684 bridged
Clear any existing Bridge interfaces and Ethernet and RFC1483/RFC2684 transports, by
1.
entering the following commands:
- - > bridge clear interfaces
- - > transports clear
Add an Ethernet device to the Bridge. In the following commands
2.
--> ethernet add transport <name> [<port>]
--> bridge add interface <name>
--> bridge attach {<name>|<number>} <transport>
Example)
- -> ethernet add transport eth1 ethernet
- -> bridge add interface bridge1
bridge attach bridge1 eth1
3. Add an RFC1483 device to the Bridge, with RFC1483 configured to run on port, using VCI
and LLC encapsulation.
- -> rfc1483 add transport <name> <port> <vpi> <vci> {llc|vcmux}
{bridged|routed}
LDK24 ADSL Router User's Manual
Version 1.0D
LDK24 ADSL Router
Copyright© 2002 LG Electronics Inc., LTD.
Page 8 of 67
System in various gateway
