HyperFlgiht Sky Series Assembly Guide
HyperFlight Ltd
Drybank Farm
Fosse Way
Ettington
Stratford-on-Avon
Warwickshire UK CV37 7PD
www.HyperFlight.co.uk
sales@HyperFlight.co.uk
© 2011 HyperFlight
Revision 1.0
Sky Series Assembly Guide 1.odt
HyperFlight Sky Series Assembly Guide
1
Advertisement
Related Manuals for Hyperflight sky series
Summary of Contents for Hyperflight sky series
- Page 1 HyperFlgiht Sky Series Assembly Guide HyperFlight Ltd Drybank Farm Fosse Way Ettington Stratford-on-Avon Warwickshire UK CV37 7PD www.HyperFlight.co.uk sales@HyperFlight.co.uk © 2011 HyperFlight Revision 1.0 Sky Series Assembly Guide 1.odt HyperFlight Sky Series Assembly Guide...
- Page 2 HyperFlight’s sole obligation shall be to replace those parts of the kit proven to be defective or missing. If you are not willing to agree to this binding condition of sale please return the model in as-received condition to Hyperflight for a refund.
- Page 3 Wrap the servo with a single layer of cling film to prevent the servo being bonded to the mount or wing. c. Place the mount on a flat surface and press the servo home until the servo and mount are flush on the underside. HyperFlight Sky Series Assembly Guide...
- Page 4 At the wing root solder on a 4 way socket e.g. Deans micro, and insulate the solder connections with heat shrink. Connect the cables in the following order- positive, aileron signal, negative, flap signal. j. Make up two leads to connect the wing wiring to the receiver. HyperFlight Sky Series Assembly Guide...
- Page 5 Give the bonding surfaces of both wing and horns a light coat of adhesive. I used micro fibre / epoxy mix to ensure a good bond with excellent gap filling properties. HyperFlight Sky Series Assembly Guide...
- Page 6 With the servos and control surfaces still centred, add a small drop of thick CA adhesive to each push rod to horn joint. Zap with a small amount of accelerator and the flex each joint. This removes all slop in the linkage. HyperFlight Sky Series Assembly Guide...
- Page 7 Put the two halves back into the jig and push the two halves together at the join. Align the hinge lines over the board front edge and the join on HyperFlight Sky Series Assembly Guide...
- Page 8 Make up two short push rods long enough to reach the V tail push rods and overlap by 20mm. Make L bends in the end of each f) Centre the servo horns and the V tail surface. g) Fit the short push rods into the servo horns. HyperFlight Sky Series Assembly Guide...
- Page 9 Elevator function - +/- 6mm travel at root of V tail c. Aileron function - +12mm, -8mm d. Flap function - 80 degrees down at full flap e. Centre of Gravity - usually 70mm from wing leading edge - see HyperFlight web site HyperFlight Sky Series Assembly Guide...
