Vacuum Cleaner
(Domestic use)
Operating Instructions
Contents
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . 3
(UK and Republic of Ireland only) . . . . . . . . . . . . . . . . . 6
Vacuum Cleaner Parts. . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to use the Vacuum Cleaner . . . . . . . . . . . . . . . . . . 8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Product Fiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Reminder for Customer . . . . . . . . . . . . . . . . . . . . . . . . 18
Thank you for purchasing the vacuum cleaner.
Please read these instructions carefully before using the
appliance and save these instructions for future reference.
MC-UL742
Model No.
MC-UL740
Advertisement
Table of Contents
Related Manuals for Panasonic MC-UL742
Summary of Contents for Panasonic MC-UL742
-
Page 1: Table Of Contents
Vacuum Cleaner (Domestic use) MC-UL742 Model No. MC-UL740 Operating Instructions Contents Disposal........2 IMPORTANT SAFETY INSTRUCTIONS . -
Page 2: Disposal
Disposal Disposing the appliance Disposing packaging Make sure that any package, for example, Before disposing the appliance, remove the dust bag and all the filters, and then dispose plastic bags, are kept out of the reach of children to avoid risk of suffocation. them with normal household waste. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before using the vacuum cleaner, please observe these basic safety instructions. Correct usage - This appliance is for indoor use with domestic purpose only and is not specifically designed for allergy sufferers. Use the appliance only in accordance with the instructions in this manual. - Page 4 - Hold the plug, when rewinding the mains lead. - Do not handle plug or the appliance with wet hands. - Do not use the appliance on people or animals. - Do not use wet filters after washing, make sure they are completely dry to avoid damaging the appliance.
- Page 5 - Do not sit on the appliance. - Be careful when using the appliance on staircases as the appliance may fall. - Use the appliance where the lighting is sufficient to avoid the risk of tripping.
-
Page 6: Caution For Ac Mains Lead (Uk And Republic Of Ireland Only)
Replace the fuse and close or attach the fuse cover. not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. Type A Type B WARNING - IF THE FITTED MOULDED PLUG IS... -
Page 7: Vacuum Cleaner Parts
Vacuum Cleaner Parts Model: MC-UL742 Dust bin Hose Dust bin handle Cord clip Handle (Quick draw handle) Mains lead hook Upper cord Mains lead storage hook Latch Handle release Cleaning Dust bin button plate brush Plug Connection pipe Carrying handle... -
Page 8: How To Use The Vacuum Cleaner
How to use the Vacuum Cleaner Operating the appliance Insert the connection pipe to suction Press the beater bar switch to turn it inlet. Ensure that the 2 hooks of the ON or OFF to suit the flooring being connection pipe are completely fitted cleaned. - Page 9 How to use the alternative Storing nozzles Perform the following before storing. When using the handle(quick draw handle), Turn off the appliance, and then please place the nozzle as shown. remove the plug from the socket outlet. Turn the upper cord storage hook in the upright position and wind the mains lead around the upper and 1) Before pressing the handle release...
- Page 10 How to empty the dust bin Close the dust bin plate until it clicks. Empty the dust bin in the following cases: - When dust level reached the “MAX” line. - When suction power has dropped. Grasp the dust bin handle on the top of the dust bin.
-
Page 11: Maintenance
Maintenance Cleaning the floor nozzle WARNING Cut off any carpet pile and lint entangled around the beater bar - The plug must be removed from inside of the floor nozzle with a pair of the socket outlet before cleaning or scissors. -
Page 12: Cleaning The Dust Bin
Cleaning the dust bin Disassembly Cleaning <Light care> Pull the buckles and take off the cover by pulling up the dust bin handle. Remove the dust by tapping the filter at the corner of garbage can. Buckle Cover Remove the filter. <Heavy care>... -
Page 13: Removing Clogs
Removing clogs Assembly When you feel the suction power is not adequate, check if the dust bin is full of Assemble the dust bin unit in reverse order dust or if the filters or the air passageway is of disassembly. clogged. -
Page 14: Trouble Shooting
- Check for clogs (see page 13). - Clogged hose or inlet - Check for clogs (see page 13). - Take to your nearest Panasonic Service Centre. - Hose not inserted correctly. - Check hose connection (see page 8). - Dirty filters... -
Page 15: Specifications
Specifications Specifications MC-UL742 MC-UL740 Power source 230 - 240 V ~ 50 Hz Max. Input 800 W Nominal input 690 - 750 W Dimensions (W x L x H) 303 mm x 280 mm x 1090 mm Net weight 5.8 kg 5.7 kg... -
Page 16: Product Fiche
Product Fiche General Purpose Vacuum Cleaner (EU)Nr.665/2013 Supplier’s name Panasonic Supplier’s model identifier MC-UL742 MC-UL740 Energy efficiency class kWh/year 25.4 Annual energy consumption 25.4 Indicative annual energy consumption (kWh per year), based on 50 cleaning tasks. Actual annual energy consumption will depend on how the appliance is used. -
Page 17: Vacuum Cleaner Consumables / Accessories (For Uk And Republic Of Ireland Customers Only)
Vacuum Cleaner Consumables / Accessories (For UK and Republic of Ireland customers only) DESCRIPTION MC-UL742 MC-UL740 Exhaust filter AMV72KCV000P (HEAP filter) Filter(washable) AMV95KD2100P Pre-motor filter AMV43KCV000P Beater bar AMV92RHB0R0P Cleaning brush AMC36P11020P Dusting brush AMV88R5E020P (Blinds brush) Upholstery nozzle AMV86RD2020P –... -
Page 18: Guarantee
Using dust bags which are not those of 0844 844 3899 Panasonic will make the guarantee invalid. - For customers within Ireland: Repairs should only be done by Panasonic 01289 8333 service persons or technicians. Otherwise - For further support on your product, the guarantee will be invalid. - Page 20 1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8501, Japan http://www.panasonic.net/ © Panasonic Corporation 2014 V01ZHB008 F0414-0 Issued in 04 2014 Printed in China...
