Remote Vehicle Alarm System
With Channel 2 Auxiliary Output
Installation Instructions
This Unit Is Intended For Installation In Vehicles With
12 Volt Negative Ground Electrical Systems Only
(1) - EX-6000 Control Module
2 Channel Code Learning Receiver
(2) - Three Button Transmitters
(1) - Multi Pin Input/Output Harness
(1) - Two Pin Door Lock Harness
(1) - Two Pin LED Indicator
(1) - Two Pin Valet / Programming Switch
(1) - Single Tone Siren
(1) - Installation Manual
(1) - Operator's Manual
(1) - Limited Warranty
Kit Contents:
Model EX-6000
Installation Manual
Advertisement
Table of Contents
Related Manuals for Audiovox Exclusive EX-6000
Summary of Contents for Audiovox Exclusive EX-6000
- Page 1 Remote Vehicle Alarm System With Channel 2 Auxiliary Output Installation Instructions This Unit Is Intended For Installation In Vehicles With 12 Volt Negative Ground Electrical Systems Only Kit Contents: (1) - EX-6000 Control Module 2 Channel Code Learning Receiver (2) - Three Button Transmitters (1) - Multi Pin Input/Output Harness (1) - Two Pin Door Lock Harness (1) - Two Pin LED Indicator...
-
Page 2: Before Beginning The Installation
The EX-6000 Vehicle Alarm System is designed to provide a basic deterrent to vehicle theft, and a convenient electronic means to gain access to the vehicle by providing RF remote control over the vehicle's power door lock system. The unit also includes outputs to control the vehicle's parking lights, and an additional auxiliary output designed to allow for control over an optional device such as a power trunk release or engine starting device. -
Page 3: Wiring Connections
area that may be seen from the driver’s seat as well as from outside the vehicle. Try to choose a location close enough to the Control Module so that the LED's wires will reach. Carefully inspect the area behind your chosen location to insure that the drill will not penetrate any existing factory wiring or fluid lines. Drill a 1/4"... - Page 4 to connect to only one door switch in order to detect the opening of all doors. In a few cases this will not be true, making it necessary to connect to the vehicle dome light, or isolate door trigger wires. Locate the vehicle's negative door trigger wire in the vehicle's kick panel, under-dash or the vehicle's pin-switch.
- Page 5 to the start (crank) position and will have 0 volts in all other key positions. Connect one side of the cut wire to terminal #87a of the relay. Connect the other side of the cut wire to terminal #30 of the relay. DARK BLUE Wire: Delayed 300mA Pulsed, Channel 2 Output The Dark Blue wire supplies a 300mA ground pulsed output whenever channel two of the receiver is accessed.
-
Page 6: Transmitter Programming
PLUG-IN CONNECTIONS AND COMPLETING THE INSTALLATION: Now that all the other components have been installed, and most of the main connections completed, it is time to finish connecting the remaining plug-in components and completing the installation. Even though these are plug-in connections, and the plugs have been shaped such that they cannot be plugged in wrong, please read and follow the instructions below for each connection to make certain each component is properly installed. - Page 7 Programmable Features: Features First Passive Arming Second Ignition D/L ON Third Ignition D/UL ON Fourth Passive D/L Fifth Chirps ON To Program These Features: Entering the Programming Mode involves operating the Ignition Switch and the Valet/Program/Manual Over- ride Switch in a particular sequence. This sequence is very time dependent, in other words it must be performed quickly in order for you to enter the mode.
-
Page 8: Completing The Installation
FEATURE ACTION TO PERFORM Turn the Ignition Switch ON Enter Toggle the Valet/Program/Manual Override Switch ON then OFF 3 Times Programmin Within 3 seconds, Mode turn the Ignition Switch OFF, then ON You have now engaged the Programming Mode, and are set to adjust the First feature This mode will time out automatically in 15 seconds, or can be cancelled by turning the Ignition Switch OFF First Press Transmitter Lock/unlock Button to Adjust Feature 1 Chirp = Passive Arming ON... - Page 9 © 2002 Audiovox Electronics Corporation 128-6187...
