Audiovox APS-596C Installation Manual

Remote control vehicle security system platinum
Hide thumbs Also See for APS-596C:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual

Table Of Contents:

Rev B: New Format
PATENTED: www.voxxintl.com/company/patents
Page 1
Model APS-596C
Installation Manual
Remote Control Vehicle
Security System
Page 2
Page 3
Page 4
Page 5 - 6
Page 6 - 7
Page 8
Page 8
Page 8 - 10
Page 10
Page 10
Page 10
Page 10 - 11
Page 11
Page 11
Page 12
Page 12
Page 13
Page 14
Page 15-16
128-8804b
1 of 16

Advertisement

Table of Contents
loading

Related Manuals for Audiovox APS-596C

Summary of Contents for Audiovox APS-596C

  • Page 1: Table Of Contents

    Model APS-596C Installation Manual Remote Control Vehicle Security System Table Of Contents: Before You Begin Page 2 Wire Harnesses Quick View Page 3 Mounting Of The Major Components Page 4 8 Pin Power Harness Wiring Page 5 - 6 Wiring the 11 Pin Accessory Input/Output Connector...

  • Page 2: Before You Begin

    Before You Begin PROFESSIONAL INSTALLATION IS STRONGLY RECOMMENDED Roll down window to avoid locking the keys in the vehicle during installation. Avoid mounting components or routing wires near hot surfaces or near moving parts like the steering wheel as it may prevent proper operation of the vehicle. Tape or loom wires under the hood and dash for protection as well appearance.

  • Page 3: Wire Harnesses Quick View

    11 Pin Main Wiring Harness Part # 1122916 Green / Black Channel 4 Output (-) 300mA Blue / Black Alternate Channel 3 Output (-) 300mA Black / White Horn Output (-) 300mA Orange / White Gnd. Output When Disarmed (-) 300mA Dark Green Negative Hood / Trunk Trigger Input Brown...

  • Page 4: Mounting Of The Major Components

    MOUNTING OF THE MAJOR COMPONENTS Control Module: Part # 1365043 Select a mounting location inside the passenger compartment ( up behind the dash ), and secure using the two screws provided. The control module can also be secured in place using cable ties. Do Not mount the control module in the engine compartment, as it is not waterproof.

  • Page 5: Pin Power Harness Wiring

    Note: This is a normally closed starter cut arrangement and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.

  • Page 6: Wiring The 11 Pin Accessory Input/Output Connector

    Note: This is a normally opened starter cut arrangement, and when power is removed from the security system, the starter disable feature will remain operational, and the vehicle will not start. Audiovox does not recommend using the Orange w/ White trace wire to interrupt anything but the starting circuit of the vehicle.
  • Page 7 Dark Green Wire: ( - ) Instant Trigger Zone This is an instant on ground trigger wire. It must be connected to the optional previously installed hood and trunk pin switches when used. Brown Wire: - Door Trigger If the vehicle’s courtesy light switches have a ( - ) ground output when the door is opened (GM and most Imports), you must connect this wire to the negative output from one of the door switches.

  • Page 8: Pin White Connector Shock Sensor Harness

    WARNING: Connecting the light blue/green to the high current switched output of trunk release circuits, some remote start trigger inputs, will damage the control module. Connect the light blue/green to terminal 86 of a 30 A automotive relay, connect terminal 85 to a + 12 volt source, and wire the remaining relay contacts to perform the selected function of channel 5.
  • Page 9 Connect the door side of the cut wire to terminal 30 of the optional relay added. Connect the vehicle side of the cut wire to terminal 87a of the optional relay added. Connect the green wire of the 3 pin harness to terminal 86 of the optional relay added. Connect terminal 85 of the optional relay added to a fused constant + 12 volt source.

  • Page 10: Pin Upgrade Telematic Module

    These applications require the use of additional components which may include relays, fixed resistors, or for convenience, the AS 9159a Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supplement and or the Audiovox fax back service for information on your particular vehicle for properly connecting to these types of circuits.

  • Page 11: Final Steps Wire Dressing And Operation Explanation

    (Connector Port) The 4 pin port located on the side of this module is for proprietary Audiovox data bus interface modules. These modules are used to access a variety of features in the vehicle which can be as simple as door trigger inputs, to more complex door locks outputs, or transponder interfaces for remote starting.

  • Page 12: Programming Transmitters

    The transmitters are pre-programmed from the factory. If you find you need to program new or additional transmitters follow the instructions below. PROGRAMMING BANK 1 (TRANSMITTERS): 1) Turn the ignition key to the on position. 2) Press and release the valet/programming switch 3 times (Siren Chirps). 3 Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren.

  • Page 13: Selectable Features

    Page 13 128-8804b 13 of 16...

  • Page 14: Circuit Wiring Layout

    For technical support go to www.prestigecarsecurity.com or call 1 800 225 6074. © 2013 Audiovox Electronics Corp., Hauppauge, N.Y. 11788 128-8804b Page 14 128-8804b 14 of 16...

  • Page 15: Notes

    NOTES Page 15 128-8804b 15 of 16...
  • Page 16 NOTES Page 16 128-8804b 16 of 16...
