3 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
FEATURES:
2 Three Button Programmable RF Transmitters
Three Channel Code Learning Receiver
Anti Code Grabbing Technology
Remote Panic In All Modes
Protected Valet/Override
Remote Start Safety Control Switch
Safe Start RF Control (Double Push Of RF Transmitter)
Selectable Automatic Timed Start Mode
7 Function LED, Arming, Armed, Disarmed, Valet, Zones 1, 2, & 3
Intrusion Alert With Memory
Audible Arm, Disarm, Defect Zone, And Intrusion Indications
Instant Siren Activation All Entry Points
Starter Disable When Armed
True Last Door Arming
Defective Zone By-Pass
On Command RF Chirp Delete
Mini Six Tone Siren
Two Stage Shock Sensor
Selectable Run Time 10 or 15 Minutes
OPTIONS:
Remote Trunk Release
Remote Keyless Entry
Illuminated entry
Remote Power Window Control
Remote Garage Door Interface
Multiple Vehicle Capable
CAUTION ! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
Model APS-775
Owner's Manual
Page 1
Advertisement
Table of Contents
Related Manuals for Audiovox Prestige Platinum APS-775
Summary of Contents for Audiovox Prestige Platinum APS-775
- Page 1 CAUTION ! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if it is garaged. Model APS-775 Owner's Manual Page 1...
-
Page 2: Arming The System - Active
Your APS-775 Remote Start Alarm System has many features and available options some of which are selected at time of installation. For your reference, the list on page 7 of this manual shows what features and options have been installed. Consult your installing dealer for options that may have been installed and are not listed. -
Page 3: Disarming The System
will sound for six 30 second cycles then shut down, isolate the triggered zone and continue to protect all other zones. Whenever the system is armed, the dash mounted LED will slowly flash. This serves as a visual deterrent to a potential thief. This LED is a very low current light emitting diode, and will not cause the battery to drain even if left unattended for long periods of time. -
Page 4: Valet/System Override Switch
INTRUSION WARNING SIGNAL This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. Upon disarm, the siren will chirp 4 times and the parking lights will flash 3 times. Enter the vehicle and before turning on the ignition switch, observe the LED flash pattern. If the LED flashes one time...pause, one time...pause etc., then an intrusion attempt was made by impact or a strong vibration that the shock sensor detected. -
Page 5: Remote Panic Operation
The control switch allows you to temporarily disable the remote starting function of your APS-775. To disable the unit, move the red handled control switch to the off position. The control switch also allows you to select between 2 hour start up and 4 hour start up when using the automatic start up timer mode. -
Page 6: Operating On Automatic Start Up Timer Mode
OPERATING ON AUTOMATIC START UP TIMER MODE The APS-775 has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine. -
Page 7: Featureand Function Settings
ADDITIONAL REMOTE FUNCTION CHANNEL 2 The system has an additional feature, ( Channel 2) ,that can be connected to a number of different optional accessories. Some of the more common uses for this channel are: Remote Trunk Release Remote Window Close Remote Garage Door Interface To operate the accessory associated with channel 2, press and hold the channel 2 button(s) of your keychain transmitter for four seconds. - Page 8 2 FLASH 3 FLASH CONTINUOUS FLASH REMOTE START SIREN INDICATIONS 1 LONG/1SHORT REMOTE START PARKING LAMP INDICATIONS 1 FLASH CONTINUOUS FLASH © 1998 Audiovox Corp., Hauppauge, N.Y. 11788 APS-775 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2...
