Note: The method of manual override can either be selected to operate from the valet switch or operate as custom
code. Be certain to place a check mark indicating the method used in the box located on the last page of the
owner's manual.
Note: When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin
switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Headlights
5th Passive Locks
6th Passive/Active Arm
7th Voltage Sense
8th Siren/Horn
9th Horn Chirp
10th Override Method
11th Two Step Unlock
12th Chirp Delete From Tx On
To program these selectable features;
Action
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Second Press and release the valet switch
Press transmitter Lock button to change
or
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Revision A: 3-23-04 Changed 1st Door L/UL specification
1 Chirp
2 Chirps
1 Sec.
3.5 Sec.
Auto Lock On
Auto Lock Off
Auto UL Dr
Auto UL All
On Arm
On Disarm
Passive
Active
Passive Arm
Active Arm
Voltage Sense Hardwire
Siren/Horn
Siren Only
10mS
16mS
Custom Code
Valet
On
Off
Off
Model AX-500
Installation Manual
3 Chirps
4 Chirps
1 Sec L/Dbl. U/L
350mSuL/1SL 1 Sec.
Auto UL Off
On Both
Off
Horn Only
30mS
System Response
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock drivers door only
2 chirps = auto unlock all doors
3 chirps = headlight output when arming and disarming
4 chirps = headlight output off
1 chirp = headlight output when arming
2 chirps = headlight output when disarming
Default
Auto Lock Off
Auto UL Off
Both
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
Off
128-6999A
1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox 1286999A
Summary of Contents for Audiovox 1286999A
- Page 1 Model AX-500 Installation Manual Note: The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
- Page 2 Fifth Press and release the valet switch 2 chirps = active locks Press transmitter Lock button to change 1 chirp = passive locks Sixth Press and release the valet switch 2 chirps = active arming Press transmitter Lock button to change 1 chirp = passive arming Seventh Press and release the valet switch 2 chirps = hardwire...
- Page 3 Note: This is a normally closed starter cut arrangement, and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.
- Page 4 Red/White Wire: DELAYED 300 mA PULSED OUTPUT / CHANNEL 2 This wire pulses to ground via an independent RF channel from the keychain transmitter. This is a transis- torized, low current output, and should only be used to drive an external relay coil. WARNING: Connecting the white/blue wire to the high current switched output of trunk release circuits, some remote start trigger inputs, will damage the control module.
- Page 5 Yellow Wire: + 12 VDC IGNITION SOURCE Connect this wire to a source that is live when the key is in the on and crank positions. Be sure that this source is off when the key is in the off position. Green/Orange Wire: Low Current (-) Ground Headlight Output The green/orange wire is provided to operate the optional headlamp illumination feature of the system.
- Page 6 a fused constant + 12 volt source. Most vehicles door lock/unlock motor legs rest at ground, and switch +12 volts to the door lock/unlock motor legs for operation, if this is the case in the vehicle you are working on, connect the remaining terminal, 87, to a fused + 12 volt source.
- Page 7 Antenna Wire: Be sure to extend the thin black antenna wire to it’s full length, and cable tie into place where it cannot be damaged. Avoid wrapping this wire around major, high current wire looms. Adjusting the Shock Sensor: If used, the sensitivity of the pre - detect circuit is automatically set 30% less sensitive than the full trigger circuit.
- Page 8 © 2003 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-6999A 128-6999A 8 of 8...
