Instructions for myintercom

Appendix

3. APPENDIX
3.1. Technichal specifications
Technical features
▸
15V power supply
▸ Luminous ring comprising white LEDs
▸ Integrated loudspeaker and microphone
▸
1 call button and illuminated name plate
▸
12V ~ 1A output for supplying a door opener
▸
Potential-free relay output, max. load 24V, 2A
▸
Potential-free output for controlling an
external door bell, maximum load 20V, 2A
Optical
▸
¼" CMOS sensor
▸
Focal length 2.9mm, F2.0
▸
Horizontal angle of view 84°
▸ Vertical angle of view 48°
▸
Luminosity 1.2 – 100000 Lux, F2.0, 0 Lux
with LED activation
▸
Shutter speeds 1/24500s to 1/6s
▸
Potential-free output for controlling an
exter nal door bell, maximum load 20V, 2A
Naturally, our products are certified in
accordance with CE Guidelines, which apply
throughout the EU: EMC in accordance with
2004/108/EC and Low Voltage Directive as per
73/23/EEC amended by Directive 93/68/EEC.
42
Electromagnetic compatibility
Low-voltage directive
Video
▸
Motion JPEG, H.264 compression
▸
Resolution 160 x 90 to 1280 x 800 pixels
▸ 30 frames per second in all resolutions and
compression types
Audio
▸
Proprietary audio transmission to
myintercom App
▸ Integrated acoustic echo cancellation
▸
Full duplex
▸
Amplifier output 1 watt
Network
▸
IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS
Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP,
RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP,
DHCP, ARP, SOCKS.
*This product includes software developed
by the Open SSL Project for use in the Open
SSL Tool kit (www.openssl.org)
▸
Password-protected web interface
▸
HTTPS encryption
