  • Page 1 71-8470-250 1/03 Lionel Fire Car Owner’s Manual...
  • Page 2: Table Of Contents

    Lubricating the Pullmor motor armature bearings Replacing the lamp Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel®, TrainMaster®, Odyssey®, RailSounds™, CrewTalk™, TowerCom™, DynaChuff™, StationSounds™, Pullmor®, ElectroCoupler™, Magne-Traction®, CAB-1 Remote Controller®,...
  • Page 3: Installing Bumpers

    (available separately, 6-12717, 6-62283, or 6-12715). Having a bumper at each end of the track will cause a direction change in the Fire Car, so the unit will travel back and forth between the bumpers.
  • Page 4: Lubricating The Gears

    Lubricate your Fire Car when the parts illustrated in Figure 1 appear dry. Remove dirt and dust before lubricating, and always lubricate your locomotives when you bring them out of storage.
  • Page 5: Lubricating The Pullmor Motor Armature Bearings

    2. Remove the set screw from the top of the motor using a 3/64” Allen wrench. This screw is illustrated in Figure 2. 3. Add a small amount (two drops) of Lionel oil (available in the Lubrication and Maintenance Kit, no. 6-62927) to the set screw hole.
  • Page 6: Replacing The Lamp

    Replacing the lamp our Fire Car is illuminated by one flashing lamp, Lionel part no. 610-8470-009. During the course of normal operation, this lamp may require replacement. Replacement lamps are available from your authorized Lionel Service Center or from Lionel Service.
  • Page 7 Replacing the lamp (continued) Top of the car Lionel part no. 610-8470-009 The connector is mounted to the circuit board Inside the body Figure 3. Lamp replacement...
  • Page 8: Limited Warranty/Lionel Service

    Lionel product, including all to the nearest Authorized Lionel Service Center. mechanical and electrical components, Your nearest Lionel Service Center can be found by moving parts, motors and structural calling 1-800-4-Lionel, or by accessing our Website components, except for light bulbs, is warranted to at www.lionel.com.
