Summary of Contents for W Audio DSR-10A

  • Page 1 Order Code: SPEA34 - DSR-10A Order Code: SPEA35 - DSR-12A Order Code: SPEA36 - DSR-15A ENGLISH...
  • Page 2: Safety Instructions

    WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! CAUTION! Keep this equipment away from rain, moisture and liquids. SAFETY INSTRUCTIONS Every person involved with the installation, operation & maintenance of this equipment should: Be competent Follow the instructions of this manual CAUTION! TAKE CARE USING THIS EQUIPMENT!
  • Page 3: Operating Determinations

    IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment. • Never let the power-cable come into contact with other cables. Handle the power-cable and all mains voltage connections with particular caution! •...
  • Page 4 • 10”, 12” or 15” Mid-Low frequency transducers • 1” Compression high frequency driver • 80˚ x 60˚ Coverage pattern • Smooth response with high power • 5 Integral suspension points • Complete mounting solutions Specifications: DSR-10A DSR-12A DSR-15A Freq. Range(-10dB): 60Hz~19kHz 56Hz~19kHz 45Hz~19kHz Freq.
  • Page 5: Specifications

    Specifications: DSR-10A Freq. chart: Dimensions: Block diagram: DSR-12A Freq. chart: Dimensions: Block diagram: DSR-15A Freq. chart: Dimensions: Block diagram:...
  • Page 6 Installation on a Speaker Stand The speakers may only be installed on a speaker stand if the original speaker is equipped with an appropriate stand adaptor. Stands must only be installed on a plane area with a maximum inclination angle of 5˚. CAUTION: Speakers installed under the influence of horizontal forces, e.g.
  • Page 7 Overhead Installation If the speaker is to be installed with a mounting height of more than 1 meter (e.g. on a stage or framework), the speaker must always be secured with an appropriate secondary securing attachment. The installation must always be secured with a secondary safety attachment. e.g. an appropriate catch net.
  • Page 8 Secondary Attachment Please note: The Speaker(s) must always be secured with three appropriate eye bolts and three appropriate safety ropes. The eyelets and the safety ropes must always hold at least 12 times the weight of the speaker. Please note: Before installing the eye bolts, make sure that the thread is is always in perfect condition and free from dirt.
  • Page 9: Suspended Installation

    Wall Installation The speaker can only be installed on a wall, if the original speaker is equipped with an appropriate mounting point. Before attaching the speaker, make sure that the installation area can hold a minimum point load of 10 times the installations weight. (e.g.
