- Page 1 4x4 4K HDBaseT™ Matrix HMXL44AB User Manual...
-
Page 2: Table Of Contents
HMXL44AB User ManUal Contents Thank you for purchasing this product. Introduction For optimum performance and safety, please read these instructions care- Features fully before connecting, operating or adjusting this product. Please keep this manual for future reference. Panel Descriptions 03/04... -
Page 3: Introduction
HMXL44AB User ManUal Introduction Our Essential 4x4 HDBaseT™ Matrix offers unprecedented performance and value for the custom installation market. The HMXL44-KIT is a 4K 4x4 matrix package, delivering HDMI, Bi-directional IR and PoH (PoE) up to lengths of 70m over a single CAT cable. The matrix also provides advanced features including Audio breakout, simultaneous HDMI outputs and RS-232 pass through to enable 3rd party control of displays. -
Page 4: Remote Control Descriptions
HMXL44AB User ManUal Rear Panel HMXL44AB ZONE IR inputs – 3.5mm stereo jack. RS232 port – For control of the POH Power port – Use supplied Transmits IR to the zone receiver matrix switcher from PC or control 12V/5A DC adaptor to power the (Displays). -
Page 5: Specifications
OUT1=Copy OUTPUT1 EDID to INPUTx • 4 x HEX70ED-RX OUT2 ALL=Set EDID to ALL INPUTs • 1x Rack mounting kit for HMXL44AB OUT2=Copy OUTPUT2 EDID to INPUTx • 4 x Mounting kit for HEX70B-RX OUT3 OUT3=Copy OUTPUT3 EDID to INPUTx •... -
Page 6: Application Diagram
HMXL44AB User ManUal ZONE 01 ZONE 02 ZONE 03 ZONE 04 SOURCE 01 SOURCE 02 SOURCE 03 SOURCE 04 70m max ZONE 01 ZONE 02 ZONE 03 ZONE 04 CONNECTION DIAGRAM www.blustream.co.uk... -
Page 7: Rs232 Pin Assignment
HMXL44AB User ManUal RS232 Pin Assignment RS232 and Telnet Commands MT0404-QFI reMOTe cOnTrOL cOnsOLe No. ComANd ACtioN Assignment Assignment Print Help Information HELP Print Help Information STATUS Print System Status And Port Status Power On, System Run On Normal State... - Page 8 www.blustream.co.uk www.blustream.com.au...
