Qualcast
18V Lithium-Ion Cordless Hedge Trimmer
Instruction Manual
Important
- Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from
your mower, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline
on 0845 077 8888.
After Sales Support
UK/Ireland
Republic of Ireland
Web
www.homebasespares.co.uk
0845 077 8888
0124 77708
Aug 2012

Advertisement

loading

  Related Manuals for Qualcast CLHT1851D

  Summary of Contents for Qualcast CLHT1851D

  • Page 1 Qualcast 18V Lithium-Ion Cordless Hedge Trimmer Instruction Manual After Sales Support UK/Ireland 0845 077 8888 Republic of Ireland 0124 77708 www.homebasespares.co.uk Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your mower, ensuring it is assembled correctly and safely.
  • Page 2: Table Of Contents

    Contents Safety Information ............................3 Warnings Symbols ............................3 General Safety ..............................4 Personal Safety ............................6 Unpacking ..............................6 In the Box .................................7 Parts ................................7 Assembly ................................8 Front Handle Assembly ..........................8 Operating Instructions & Tips .........................9 Battery Location ............................9 Installing Battery In Charger........................10 Safety Features ............................11 Starting and Stopping..........................11 Shaping ...............................12...
  • Page 3: Safety Information

    Safety Information Important - Please read these instructions fully before starting assembly Warnings Symbols The following warning symbols appear throughout this instruction manual and indicate the appropriate safety measures you should take when assembling and operating the hedge trimmer. Take extra care, beware of hazards. Read instruction manual.
  • Page 4: General Safety

    Safety Information Important - Please read these instructions fully before starting assembly General Safety IMPORTANT! All operators must read these instructions before use. WARNING! Read all safety warnings and all instructions. Failure to follow all warnings, and instructions may result in electric shock, fire or serious injury. Save all warnings and instructions for future reference To use this tool properly, you must observe all safety warnings, assembly, operating and maintenance instructions in this manual.
  • Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Safety (continued) • Use safety accessories. Safety glasses and ear muffs should always be worn. • Do not overreach. Keep your footing secure and balanced at all times. •...
  • Page 6: Personal Safety

    Safety Information Important - Please read these instructions fully before starting assembly Personal Safety • Do not use the trimmer in the rain. • Keep hands and fingers well away from the blade. • Wear work gloves, eye protection, solid shoes and trousers when using this hedge trimmer. •...
  • Page 7: In The Box

    In the Box Parts Rear handle Front handle Battery pack release Battery charger latch Trigger switch Safety guard Blade sheath Battery Front switch bar Cutting blade It is important to know the features and safety requirements of the trimmer. The trimmer should only be used to trim soft, new growth.
  • Page 8: Assembly

    Assembly Front Handle Assembly 2a. The front handle needs to be assembled to the main body. Position it as illustrated 2b. Insert the bolt into the right hand side and tighten. 2c. Once assembled check that this bolt is tight on a regular basis. Customer Helpline 0845 077 8888...
  • Page 9: Operating Instructions & Tips

    Operating Instructions & Tips Battery Location The battery pack for this tool has been shipped in a low charge condition. You should charge the battery pack fully before use. • Press the battery pack release latch • Pull the battery out from its location below the handle. •...
  • Page 10: Installing Battery In Charger

    Operating Instructions & Tips Installing Battery In Charger Note! • Connect the plug of charger with battery (fig 5). • The red indicator light will come ON when the charger is connected to the mains supply. • The red light stays on when the battery is charging. •...
  • Page 11: Safety Features

    Operating Instructions & Tips Safety Features • The fixed blade teeth have extended points with rounded ends to reduce the chance of injury in case of accidental contact. • The fixed blade is longer than the moving blade to guard against kickback should you inadvertently make contact with a wall or fence.
  • Page 12: Shaping

    Operating Instructions & Tips Shaping • Trim a hedge so that it is wider at the bottom than the top. This improves penetration of light and promotes healthy growth. • Taper the hedge approximately 4 inches (100 mm) for every 40 inches (1 metre) in height. A bush can be round, or a column shape.
  • Page 13: Cutting

    Operating Instructions & Tips Cutting • Assume a secure position, using two hands to hold the trimmer and switch on. • Trim both sides of the hedge, starting at the bottom. This prevents cuttings falling into the area yet to be cut.
  • Page 14: Pruning

    Operating Instructions & Tips Pruning Your hedge trimmer is versatile. It can also be used for frequently pruning new growth on a wide variety of shrubs and hedges in your garden to encourage even growth and attractive shapes. Lubrication WARNING! Switch off and remove the battery before carrying out any maintenance on the tool. After each use, clean the blades and lightly lubricate with general purpose oil or spray lubricant.
  • Page 15: Troubleshooting

    Troubleshooting General Troubleshooting The following table provides solutions to common problems encountered with the hedge trimmer. Fault Possible Cause Solution Product does not start Battery pack not properly Insert properly inserted Battery pack discharged Remove and charge battery pack Battery pack damaged Check by a specialist electrician Other electrical defect Check by a specialist electrician...
  • Page 16: Disposal

    Disposal Disposal and Recycling Do not dispose with household waste. Recycle products and components according to local legal requirements. Getting Help After sales helpline number: 0845 077 8888 Spare parts purchases: www.homebasespares.co.uk Customer Helpline 0845 077 8888...
