Table 4-3: Blt-Ism-Connector Interface Description (X13) - Blue Technix CM-i.MX27-C-C-Q26S128F32N512 Hardware User Manual

Pin No. SignalName Type
10 CSI1.PCLK I
11 CSI1.VSYNC I
12 CSI1.HSYNC I
13 GPIO3.5 O
14 STROBE I
15 NC NC
16 NC NC
17 CSI1.DO I
18 CSI1.D1 I
19 VCAMIO PWR
20 GND PWR
21 CSI1.D2 I
22 CSI1.D3 I
23 CSI1.D4 I
24 CSI1.D5 I
25 GND PWR
26 CSI1.D6 I
27 CSI1.D7 I
28
CSI1.D8 I
29 CSI1.D9 I
30 CSI1.PWDN O
EXT-SBC-i.MX51-COMM_HUM_V1.2.docx
Power Domain
P_SW4
P_SW4
P_SW4
P_SW4
P_SW4
P_SW4
1V8
GND
P_SW4
P_SW4
P_SW4
P_SW4
GND
P_SW4
P_SW4
P_SW4
P_SW4
P_SW4

Table 4-3: BLT-ISM-Connector interface description (X13)

Description
Pixel Clock
VSYNC
HSYNC
Camera Trigger
Strobe Signal from Camera (available only on solder pad)
Not Connected
Not Connected
Pixel Data
Pixel Data
Camera IO Power Supply
Power Ground
Pixel Data
Pixel Data
Pixel Data
Pixel Data
Power Ground
Pixel Data
Pixel Data
Pixel Data
Pixel Data
Output Enable (Active Low)
19
