Table of Contents i.MX Core Modules..................................... 6 Core Module naming information ..............................7 i.MX Development Boards ..................................8 Introduction ....................................... 9 Overview ....................................10 Key Features ................................... 10 Applications .................................... 11 General Description ..................................12 Functional Description ............................... 12 2.1.1 Powering ..................................
Page 4
Ordering Information ................................... 21 Related products for EXT-SBC-i.MX51-COMM ......................21 Dependability ....................................22 MTBF ......................................22 Product History ....................................23 Version Information ................................23 Anomalies ....................................23 Document Revision History ............................... 24 List of Abbreviations ................................25 List of Figures and Tables ................................26 EXT-SBC-i.MX51-COMM_HUM_V1.2.docx...
Core Modules CM-i.MX27-C-C-Q26S128F32N512 The Core Module CM-i.MX27 is powered by Freescales' SoC i.MX27 (ARM 926 core, up to 400MHz). It addresses 128MB DDR-RAM, has an onboard NOR-flash of 32MByte and a NAND-flash with 512MByte at a size of 55x45mm.
Core Module naming information The idea is to put more Core Module specific technical information into the product name. New Core Module names will have following technical information covered in their names. • Product Family, • CPU-Type, • Connection-Type, • Operating Temperature Range, •...
i.MX Development Boards DEV-i.MX27 The DEV-i.MX27 development board is an extendable development platform for the CM-i.MX27 processor modules. With display connector and keypad it can be used as a reference design for a low power mobile handheld device powered by a single Lithium Ion battery. The development board provides all interfaces of the connector version on dedicated expansion connectors.
1 Introduction The EXT-SBC-i.MX51-COMM is the best equipped extender board for the SBC-i.MX51. It offers GPS, GSM/GPRS, a camera (BLT-ISM-CONNECTOR) as well as a display interface. Antenna connectors for GSM and GPS are available for external antennas. Possible applications are wireless communication, mobile Navigation, surveillance, locating and industrial applications.
• Touch Panel Connector 4 pin Connector for connection of a resistive Touch Panel • Power Supply LVDS Backlight supplied via separate external power supply (not included) EXT-SBC-i.MX51-COMM is powered via SBC-i.MX51 • Camera Connector (BLT-ISM-Connector) 30 pin ZIF connector Compatible with all Bluetechnix Image Sensor Modules 1.3 Applications...
2 General Description 2.1 Functional Description 2.1.1 Powering The EXT-SBC-i.MX51-COMM is supplied by the SBC-i.MX51. Please consider the chapter Electrical Specifications. If an LVDS display is used (e.g. LT084AC3711) an external 12V power supply must be connected to the connector X3. 2.2 PCB Placement Figure 2-1: Connector positions EXT-SBC-i.MX51-COMM_HUM_V1.2.docx...
2.3 Mechanical Outline This section shows the position of all connectors and mounting holes. All dimensions are given in mm. Figure 2-2: EXT-SBC-i.MX51-COMM top view Figure 2-3: EXT-SBC-i.MX51-COMM bottom view EXT-SBC-i.MX51-COMM_HUM_V1.2.docx...
3 Specifications 3.1 Electrical Specifications 3.1.1 Digital I/O Characteristics Parameter Power Domain Symbol Typ. Unit High-Level Output Voltage P_VIOHI 2.625 2.775 3.075 High-Level Output Voltage P_SW4 1.65 Low-Level Output Voltage all domains 0.15 High Level Output Current all domains Low-Level Output Current all domains High-Level Input Voltage P_VIOHI...
3.1.4 ESD Sensitivity ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
4 Connector Description 4.1 Display Data Connector X1 (Toshiba LT084AC3711) Pin No. Signal Name Type Power Domain Description Not Connected Not Connected P_3V3 P_3V3 Display Power Supply Power Ground TxCLK_N P_3V3 LVDS clock TxCLK_P P_3V3 LVDS clock P_3V3 P_3V3 Display Power Supply Power Ground Tx0_N P_3V3...
4.3 Display Power Supply Connector X3 Pin No. Signal Name Type Power Domain Description V_LED External Backlight Power Supply Not Connected External Power Ground Figure 4-1: Display Power Supply Connector description (X3) 4.4 Touch Panel Connector X4 (Toshiba LT084AC3711) Pin No. Signal Name Type Description...
Pin No. SignalName Type Power Domain Description CSI1.PCLK P_SW4 Pixel Clock CSI1.VSYNC P_SW4 VSYNC CSI1.HSYNC P_SW4 HSYNC GPIO3.5 P_SW4 Camera Trigger STROBE Strobe Signal from Camera (available only on solder pad) Not Connected Not Connected CSI1.DO P_SW4 Pixel Data CSI1.D1 P_SW4 Pixel Data VCAMIO...
5 Support 5.1 General Support General support for products can be found at Bluetechnix’ support site https://support.bluetechnix.at/wiki 5.2 Board Support Packages Board support packages, boot loaders and further software downloads can be downloaded at the products wiki page at https://support.bluetechnix.at/wiki 5.3 i.MX Software Support 5.3.1 Linux Linux BSP and images of derivates can be found at Bluetechnix’...
6 Ordering Information 6.1 Related products for EXT-SBC-i.MX51-COMM Article Number Name Description 100-2524-1 EXT-SBC-i.MX51-COMM Communication extender board for SBC-i.MX51 100-9910-1 EDT-TFT-5.0"-WVGA-G-ET0500G0DH6 EDT Display TFT 5.0" WVGA, 300cd/m² LED, TTL, touch 100-4110-2 SBC-i.MX51-S-C-Q24S512N2048 Single-Board Computer SBC-I.MX51 based on i.MX51 (SBC-i.MX51) Table 6-1: Ordering information NOTE: Custom hard and software developments are available on request! Please contact Bluetechnix (office@bluetechnix.com) if you are interested in custom hard- and software developments.
7 Dependability 7.1 MTBF Please keep in mind that a part stress analysis would be the only way to obtain significant failure rate results, because MTBF numbers just represent a statistical approximation of how long a set of devices should last before failure.
8 Product History 8.1 Version Information Version Date Changes 2011-05-30 Changed layout of Image Sensor Connector X13 2011-04-20 First release V1.1 of the Hardware. Table 8-1: Overview product changes 8.2 Anomalies Version Date Description 2011-04- 20 No anomalies reported yet. Table 8-2: Overview product anomalies EXT-SBC-i.MX51-COMM_HUM_V1.2.docx...
9 Document Revision History Version Date Document Revision 2011-12-06 Removed Bluetooth support since BT module is not available any more. 2011-09-06 Changed product photo. 2011-08-03 Update for Board Revision 1.2 2011-04- 20 First release V1.0 of the Document Table 9-1: Revision History EXT-SBC-i.MX51-COMM_HUM_V1.2.docx...
10 List of Abbreviations Abbreviation Description Analog Devices Inc. Analog Input Asynchronous Memory Select Analog Output Core Module Direct Current Digital Signal Processor Enhanced Core Module External Bus Interface Electrostatic Discharge GPIO General Purpose Input Output Input I²C Inter-Integrated Circuit Input/Output Image Sensor Module Low Drop-Out regulator...
