4.3 Display Power Supply Connector X3

Pin No. Signal Name Type
1 12V PWR
2 NC NC
3 GND PWR

4.4 Touch Panel Connector X4 (Toshiba LT084AC3711)

Pin No. Signal Name Type
1 ADIN1 AI
2 ADIN2 AI
3 ADIN3 AI
4 ADIN4 AI

4.5 Display Connector X5 (ET0500G0DH6)

Pin No. Signal Name Type
1 DISP.nRESET O
2 GND PWR
3 DISP2.D4 O
4 DISP2.D3 O
5 DISP2.D2 O
6 DISP2.D1 O
7 DISP2.D0 O
8 DISP2.D4 O
9 GND PWR
10 DISP2.D10 O
11 DISP2.D9 O
12 DISP2.D8 O
13 DISP2.D7 O
14 DISP2.D6 O
15 DISP2.D5 O
16 GND PWR
17 DISP2.D15 O
18 DISP2.D14 O
19 DISP2.D13 O
20 DISP2.D12 O
21 DISP2.D11 O
22 DISP2.D15 O
23 GND PWR
24 TFT.CLK O
25 GND PWR
26 TFT.HSYNC O
27 TFT.VSYNC O
28 TFT.DE O
29
TFT.PWRCTRL O
30 P_3V3 PWR
EXT-SBC-i.MX51-COMM_HUM_V1.2.docx
Power Domain
V_LED
GND

Figure 4-1: Display Power Supply Connector description (X3)

Figure 4-2: Touch Panel Connector description (X4)

Power Domain
P_3V3
GND
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
GND
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
GND
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
P_VIOHI
GND
P_VIOHI
GND
P_VIOHI
P_VIOHI
P_3V3
P_VIOHI
P_3V3
Description
External Backlight Power Supply
Not Connected
External Power Ground
Description
Touch Panel XR Terminal
Touch Panel YU Terminal
Touch Panel XL Terminal
Touch Panel YD Terminal
Description
Display Reset
Power Ground
Blue Data Bit 5
Blue Data Bit 4
Blue Data Bit 3
Blue Data Bit 2
Blue Data Bit 1
Blue Data Bit 0
Power Ground
Green Data Bit 5
Green Data Bit 4
Green Data Bit 3
Green Data Bit 2
Green Data Bit 1
Green Data Bit 0
Power Ground
Green Data Bit 5
Green Data Bit 4
Green Data Bit 3
Green Data Bit 2
Green Data Bit 1
Green Data Bit 0
Power Ground
Dot Data Clock
Power Ground
Horizontal Sync
Vertical Sync
Data Enable
Power Control
Power Supply
