Prior to installing the unit, please make sure that you have all
the parts from the box and the necessary tools to complete the
installation.
1
2
4
1. Trim tools
2. Cable ties
3. Soldering Iron & Solder
4. Electrical Tape
5. Heat shrink
6. Burner for Heat shrink
When the manual refers to 'OEM', this means original equipment manufacturer.
When the manual refers to 'OEM multimedia unit section' this is the area located where the
OEM 3.5" screen was originally mounted.
When the manual refers to the 'TOP SECTION' this is the area located where the top dashboard tray was originally
mounted.
Parts -

Packing List

3

Tools required

7. Step through drill
8. 7mm socket
9. Multi tip set
10. Side cutters
11. Drill/Philips head screwdriver
12. Split conduit
QUICK REFERENCE GUIDE
2
1. FR-1516 Head Unit
2. Wiring Harness
3. GPS Antenna
4. Rear Vision Camera with
7m cable
5. Forward Vision Camera
with 7m cable
6. User Manual
5
13. Yellow Tongue (long strike,
approx. 3-4 metres)
14. Short strike (approx. 1 metre)
15. Power cable
16. 10mm spanner
