Thank you for purchasing the
Before removal and installation, be sure to thoroughly read these instructions.
Keep these instructions with your vehicle records for future reference.
FORD RANGER
Installation Instructions
This installation guide is for reference only. Polaris takes no responsibility for any damage
caused to any vehicle through incorrect installation, unsafe practices or poor workmanship.
Warranty for this product is 3 years from date of purchase, however warranty will be void if :
• The unit is tampered with, damaged or modified in anyway.
• Reverse camera cable is cut or modified in any way
• Reverse camera is subjected to over voltage
• The Navigation SD card is damaged or tampered with in any way
(this includes installing foreign mapping or software onto the SD card)
The Ford Ranger FR-1516 is covered for 3 years and includes:
• Defective Equipment
• Defective Cables
Not Covered under warranty:
• Abuse
• Improper installation
• Alteration to cables (this includes cutting of any cables)
• Accidents
If you have any questions concerning the installation, warranty or the operation of the unit,
Polaris
please contact
We hope that you enjoy the Ford Ranger FR-1516 in dash unit.
Polaris Ford Ranger FR-1516
Warranty Terms
1300 555 514.
on
in-dash unit.
FR-1516

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-1516 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Polaris FR-1516

Summary of Contents for Polaris FR-1516

  • Page 1 FR-1516 Installation Instructions This installation guide is for reference only. Polaris takes no responsibility for any damage caused to any vehicle through incorrect installation, unsafe practices or poor workmanship. Warranty for this product is 3 years from date of purchase, however warranty will be void if : •...

  • Page 2: Packing List

    Prior to installing the unit, please make sure that you have all the parts from the box and the necessary tools to complete the installation. Parts - Packing List 1. FR-1516 Head Unit 2. Wiring Harness 3. GPS Antenna 4. Rear Vision Camera with 7m cable 5.

  • Page 3: Section 1 - Removal Of The Dash Panel

    Section 1 - Removal of the dash panel 1.Use your trim tool to remove the 3. Remove air vent trim to the left 2. Remove passenger side air vent trim of steering wheel top dash board tray 4. Remove 2 x dash side panels (driver and passenger side) 5.
  • Page 4 19. Run the other end of the harness so in the top section so that you can feed the that it sits behind the OEM multimedia FR-1516 plug through unit section. Leave this section for now and run your forward vision camera and rear vision camera...

  • Page 5: Section 2 - Forward Vision Camera Installation Guide

    Section 2 - Forward vision camera installation guide 1. Push sides of glove box in to release 2. Disconnect camera from cable and pass the 3. Open front bonnet of Ford Ranger smaller 4 pin plug through large grommet (located to the left hand side of firewall). Important Make sure you leave enough cable inside the glove-box area...

  • Page 6: Section 3 - Reverse Camera Installation

    Section 2 - Forward vision camera installation guide continued Plug larger 4 pin plug into front camera connection on harness located in the section behind OEM multimedia unit. 9. Connect camera plug to cable that should be located inside front bonnet. Section 3 - Reverse camera installation 1.
  • Page 7 Section 3 - Reverse camera installation continued 9. Tap into reverse positive wire 11. Remove kick panel and scuff plate on 10. Reinstall tail light. passenger front side of vehicle (red with yellow stripe.) 14. Use cutters to make an incision in 12.

  • Page 8: Section 4 - Wiring Diagram

    Section 4 - Wiring Diagram GPS antenna plug Caravan camera Front camera Back camera Suggested areas to pick up power from Yellow (Batt+) tap into OEM CD/Radio plug Refer to section A. Black (Gnd -) tap into OEM CD/Radio plug Refer to section A. Red (Acc) tap into 12 volt from kick panel Refer to section B...
  • Page 9 Section 4 - continued Section A Black (ground) pick up from OEM CD/radio Yellow (batt +) pick up from OEM plug (black with purple stripe). CD/radio plug (white with brown stripe). Section B - How to tap into 12 volt power in kick panel 1.

  • Page 10: Section 5 - Gps External Antenna

    Section C - How to tap into OEM illumination via traction/diff lock button OEM plug 1. Use trim tool to remove trim around gear-stick. Pull out gently so that you can disconnect 2. Tap into illumination wire (brown) USB/AUX and plug from behind trim. via the traction control/diff lock button OEM plug Please note:...

  • Page 11: Section 6 - Mounting The Head Unit

    Section 6 - Mounting the head unit 1. Plug your GPS antenna plug 1. Grab the FR-1516 in-dash and plug in 3. Push FR-1516 into place. into FR-1516. the main harness. IMPORTANT Before putting the dash back together, power the unit up and test all features.
  • Page 12 Section 7 - Recommended order for putting the dash back together continued 11. Reinstall side panel trim - 12. Remove air vent trim to the right 10. Reinstall trim underneath steering driver’s side. of the steering wheel. wheel column. 15. Reinstall fuse cover trim. 13.
