Connect the power and Ethernet cables, or just the
Ethernet cable if you are using a PoE connection.
To adjust the camera's angle, pull the black inner cover
and remove it from the camera.
Loosen the adjustment screw on the side of the camera,
then retighten it after moving the camera to the desired
angle. You can also rotate the camera by grasping the
camera and turning it left or right.
When you are done adjusting the camera's angle, put the
inner cover back into place.
Note: The camera has a limited range of motion; if it stops
when you are adjusting it, do not attempt to rotate or tilt
the camera any further in that direction.
Reattach the camera cover.
If you are running the camera cables out the side of
the camera, guide the camera cables through the cable
channel on the base.
If you need to waterproof your installation, please continue to the next page.
